The 8-bit LTC1665 and 10-bit LTC1660 integrate eight accurate, serially addressable digital-to-analog converters (DACs) in tiny 16-pin narrow SSOP packages. Each buffered DAC draws just 56?A total supply current, yet is capable of supplying DC output currents in excess of 5mA and reliably driving capacitive loads to 1000pF. Sleep mode further reduces total supply current to 1?A.Proprietary, inherently monotonic voltage interpolation architecture provides excellent linearity while allowing for an exceptionally small external form factor.Ultralow supply current, power-saving Sleep mode and extremely compact size make the LTC1665 and LTC1660 ideal for battery-powered applications, while their ease of use, high performance and wide supply range make them excellent choices as general purpose converters.Applications Mobile Communications Remote Industrial Devices Automatic Calibration for Manufacturing Portable Battery-Powered Instruments Trim/Adjust Applications

TPS57160-Q1EVM: EMC Optimized EVM featuring the TPS57160-Q1 Step-down DC/DC Converter

MicroFJ-30035 J-SERIES SIPM Light, Silicon Photomultiplier (SiPM) Sensor Evaluation Board

Daughter Cards & OEM Boards Microphone coupon board based on the MP23ABS1 analog MEMS

TPA3100D2 Evaluation Module (EVM)

The AD9172 is a high performance, dual, 16-bit digital-to-analog converter (DAC) that supports DAC sample rates to 12.6 GSPS. The device features an 8-lane, 15 Gbps JESD204B data input port, a high performance, on-chip DAC clock multiplier, and digital signal processing capabilities targeted at single-band and multiband direct to radio frequency (RF) wireless applications.The AD9172 features three complex data input channels per RF DAC that are bypassable. Each data input channel includes a configurable gain stage, an interpolation filter, and a channel numerically controlled oscillator (NCO) for flexible, multiband frequency planning. The device supports up to a 1.5 GSPS complex data rate per input channel and is capable of aggregating multiple complex input data streams up to a maximum complex data rate of 1.5 GSPS. Additionally, the AD9172 supports ultrawide bandwidth modes bypassing the channelizers to provide maximum data rates of up to 3.08 GSPS (with 16-bit resolution) and 4.1 GSPS (with 12-bit resolution).The AD9172 is available in a 144-ball BGA_ED package.PRODUCT HIGHLIGHTS Supports single-band and multiband wireless applications with three bypassable complex data input channels per RF DAC at a maximum complex input data rate of 1.5 GSPS. One independent NCO per input channel. Ultrawide bandwidth channel bypass modes supporting up to 3 GSPS data rates with 16-bit resolution and 4 GSPS with 12-bit resolution. Low power dual converter decreases the amount of power consumption needed in high bandwidth and multichannel applications.APPLICATIONS Wireless communications infrastructure Multiband base station radios Microwave/E-band backhaul systems Instrumentation, automatic test equipment (ATE) Radars and jammers

BOARD EVALUATION

The ADF7020-1 is a low power, highly integrated FSK/ GFSK/ ASK/ OOK/ GOOK transceiver designed for operation in thelow UHF and VHF bands. The ADF7020-1 uses an externalVCO inductor that allows users to set the operating frequencyanywhere between 135 MHz and 650 MHz. Using the divide-by-2circuit allows users to operate the device as low as 80 MHz.The typical range of the VCO is about 10% of the operatingfrequency. A complete transceiver can be built using a smallnumber of external discrete components, making the ADF7020-1 very suitable for price-sensitive and area-sensitiveapplications.The transmit section contains a VCO and low noisefractional-N PLL with output resolution of <1 ppm. Thisfrequency agile PLL allows the ADF7020-1 to be used infrequency-hopping spread spectrum (FHSS) systems. The VCOoperates at twice the fundamental frequency to reduce spuriousemissions and frequency pulling problems.The transmitter output power is programmable in 63 steps from?20 dBm to +13 dBm. The transceiver RF frequency, channelspacing, and modulation are programmable using a simple 3-wire interface. The device operates with a power supply range of2.3 V to 3.6 V and can be powered down when not in useA low IF architecture is used in the receiver (200 kHz),minimizing power consumption and the external componentcount and avoiding interference problems at low frequencies.The ADF7020-1 supports a wide variety of programmablefeatures, including Rx linearity, sensitivity, and IF bandwidth,allowing the user to trade off receiver sensitivity and selectivityfor current consumption, depending on the application. Thereceiver also features a patent-pending automatic frequencycontrol (AFC) loop, allowing the PLL to compensate forfrequency error in the incoming signal.An on-chip ADC provides readback of an integrated temperaturesensor, an external analog input, the battery voltage, or theRSSI signal, which provides savings on an ADC in someapplications. The temperature sensor is accurate to ?10?C overthe full operating temperature range of ?40?C to +85?C. Thisaccuracy can be improved by doing a 1-point calibration atroom temperature and storing the result in memory.Applications Low cost wireless data transfer Wireless medical applications Remote control/security systems Wireless metering Keyless entry Home automation Process and building control

Acceleration Sensor Development Tools Eval board for KX022

ADS5560 16-Bit; 40-MSPS Analog-to-Digital Converter Evaluation Module
