Evaluation Board for the LMP8358

TCA8424EVM-038

PCM4202 Evaluation Module (EVM)

TPS92602EVM: 2 Channel High Side Current Sense LED Driver Evaluation Module

TPS6274x Ultra Low Iq Step-Down Converter Evaluation Module

The AD5412/AD5422 are low cost, precision, fully integrated12-/16-bit digital-to-analog converters (DAC) offering a programmable current source and programmable voltage output designed to meet the requirements of industrial process control applications.The output current range is programmable at 4 mA to 20 mA, 0 mA to 20 mA, or an overrange function of 0 mA to 24 mA.The LFCSP version of this product has a CAP2 pin so that the HART signals can be coupled onto the current output of the AD5412/AD5422.Voltage output is provided from a separate pin that can be configured to provide 0 V to 5 V, 0 V to 10 V, ?5 V, or ?10 V output ranges; an overrange of 10% is available on all ranges.Analog outputs are short and open-circuit protected and can drive capacitive loads of 1 ?F.The device operates with an AVDD power supply range from 10.8 V to 40 V. Current loop compliance voltage is 0 V to AVDD ? 2.5 V.The flexible serial interface is SPI- and MICROWIRE?-compatible and can be operated in 3-wire mode to minimize the digital isolation required in isolated applications.The device also includes a power-on-reset function, ensuring that the device powers up in a known state. The part also includes an asynchronous clear pin (CLEAR) that sets the outputs to zero-scale/midscale voltage output or the low end of the selected current range.The total output error is typically ?0.01% in current mode and ?0.01% in voltage mode.Applications Process controls Actuator controls PLC HART network connectivity (LFCSP package only)

The AD5424?/?AD5433?/ AD5445 are CMOS 8-, 10-, and 12-bitcurrent output digital-to-analog converters (DACs), respectively.These devices operate from a 2.5 V to 5.5 V power supply,making them suitable for battery-powered applications andmany other applications. These DACs utilize data readback,allowing the user to read the contents of the DAC register viathe DB pins. On power-up, the internal register and latches arefilled with 0s and the DAC outputs are at zero scale.As a result of manufacturing with a CMOS submicron process,they offer excellent 4-quadrant multiplication characteristics,with large signal multiplying bandwidths of up to 10 MHz.The applied external reference input voltage (VREF) determines thefull-scale output current. An integrated feedback resistor (RFB)provides temperature tracking and full-scale voltage outputwhen combined with an external I-to-V precision amplifier.While these devices are upgrades of the AD5424 / AD5433 /AD5445 in multiplying bandwidth performance, they have alatched interface and cannot be used in transparent mode.The AD5424 is available in a small, 20-lead LFCSP and a small,16-lead TSSOP, while the AD5433 and AD5445 DACs are availablein a small, 20-lead LFCSP and a small, 20-lead TSSOP.The EVAL-AD5445SDZ evaluation board is available forevaluating DAC performance. For more information, see theUG-333 evaluation board user guide.APPLICATIONS Portable battery-powered applications Waveform generators Analog processing Instrumentation applications Programmable amplifiers and attenuators Digitally controlled calibration Programmable filters and oscillators Composite video Ultrasound Gain, offset, and voltage trimming

The AD5590 is a 16-channel input and 16-channel output analog I/O port with eight uncommitted amplifiers, operating from a single 4.5 V to 5.25 V supply. The AD5590 comprises 16 input channels multiplexed into a 1 MSPS, 12-bit successive approximation ADC with a sequencer to allow a preprogrammed selection of channels to be converted sequentially. The ADC contains a low noise, wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 1 MHz.The conversion process and data acquisition are controlled using ASYNC and the serial clock signal, allowing the device to easily interface with microprocessors or DSPs. The input signal is sampled on the falling edge of ASYNC and conversion is also initiated at this point. There are no pipeline delays associated with the ADC. By setting the relevant bits in the control register, the analog input range for the ADC can be selected to be a 0 V to VREFA input or a 0 V to 2 ? VREFA with either straight binary or twos complement output coding. The conversion time is determined by the ASCLK frequency because it is also used as the master clock to control the conversion.The DAC section of the AD5590 comprises sixteen 12-bit DACs divided into two groups of eight. Each group has an on-chip reference. The on-board references are off at power-up, allowing the use of external references. The internal references are enabled via a software write.The AD5590 incorporates a power-on reset circuit that ensures that the DAC outputs power up to 0 V and remain powered up at this level until a valid write takes place. The DAC contains a power-down feature that reduces the current consumption of the device and provides software-selectable output loads while in power-down mode for any or all DAC channels. The outputs of all DACs can be updated simultaneously using the LDAC function, with the added functionality of user-selectable DAC channels to simultaneously update. There is also an asynchronous CLR that updates all DACs to a user-programmable code: zero scale, midscale, or full scale.The AD5590 contains eight low noise, single-supply amplifiers. These amplifiers can be used for signal conditioning for the ADCs, DACs, or other independent circuitry, if required.APPLICATIONS Optical Line Cards (Monitoring and Control) Base Stations General Purpose Analog I/O Monitoring and control

The AD5593R has eight input/output (I/O) pins, which can beindependently configured as digital-to-analog converter (DAC)outputs, analog-to-digital converter (ADC) inputs, digital outputs,or digital inputs. When an I/O pin is configured as an analogoutput, it is driven by a 12-bit DAC. The output range of theDAC is 0 V to VREF or 0 V to 2 ? VREF. When an I/O pin isconfigured as an analog input, it is connected to a 12-bit ADCvia an analog multiplexer. The input range of the ADC is 0 V toVREF or 0 V to 2 ? VREF. The I/O pins can also be configured tobe general-purpose, digital input or output (GPIO) pins. Thestate of the GPIO pins can be set or read back by accessing theGPIO write data register and GPIO read configuration registers,respectively, via an I2C write or read operation.The AD5593R has an integrated 2.5 V, 20 ppm/?C reference thatis turned off by default and an integrated temperature indicatorthat gives an indication of the die temperature. The temperaturevalue is read back as part of an ADC read sequence.The AD5593R is available in 16-lead TSSOP and LFCSP, as wellas a 16-ball WLCSP, and operates over a temperature range of?40?C to +105?C.Applications Control and monitoring General-purpose analog and digital I/O

The AD5668 device is a low power, octal, 16-bit, buffered voltage-output DAC. All devicesoperate from a single 2.7 V to 5.5 V supply and are guaranteedmonotonic by design. The AD5668 and AD5628 are available inboth a 4 mm ? 4 mm LFCSP and a 16-lead TSSOP, while theAD5648 is available in both a 14-lead and 16-lead TSSOP.The AD5628/AD5648/AD5668 have an on-chip reference withan internal gain of 2. The AD5628-1/AD5648-1/AD5668-1 havea 1.25 V 5 ppm/?C reference, giving a full-scale output rangeof 2.5 V; the AD5628-2/AD5648-2/AD5668-2 and AD5668-3 havea 2.5 V 5 ppm/?C reference, giving a full-scale output range of5 V. The on-board reference is off at power-up, allowing the useof an external reference. The internal reference is enabled via asoftware write.The part incorporates a power-on reset circuit that ensures that theDAC output powers up to 0 V (AD5628-1/AD5648-1/AD5668-1,AD5628-2/AD5648-2/AD5668-2) or midscale (AD5668-3) andremains powered up at this level until a valid write takes place.The part contains a power-down feature that reduces the currentconsumption of the device to 400 nA at 5 V and provides software-selectable output loads while in power-down mode for any or allDAC channels. The outputs of all DACs can be updated simultaneouslyusing the LDAC function, with the added functionalityof user-selectable DAC channels to simultaneously update. Thereis also an asynchronous CLR that updates all DACs to a userprogrammablecode?zero scale, midscale, or full scale.The AD5628/AD5648/AD5668 utilize a versatile 3-wire serialinterface that operates at clock rates of up to 50 MHz and iscompatible with standard SPI?, QSPI?, MICROWIRE?, andDSP interface standards. The on-chip precision output amplifierenables rail-to-rail output swing.Product Highlights Octal, 12-/14-/16-bit DAC. On-chip 1.25 V/2.5 V, 5 ppm/?C reference. Available in 14-lead/16-lead TSSOP, 16-lead LFCSP, and 16-ball WLCSP. Power-on reset to 0 V or midscale. Power-down capability. When powered down, the DAC typically consumes 200 nA at 3 V and 400 nA at 5 V. Applications Process control Data acquisition systems Portable battery-powered instruments Digital gain and offset adjustment Programmable voltage and current sources Programmable attenuators
