DC1545A-A: Demo Board for LT5578 0.4GHz to 2.7GHz High Linearity Upconverting Mixer.

The LTC3553 is a micropower, highly integrated power management and battery charger IC for single-cell Li-Ion/Polymer battery applications. It includes a PowerPath manager with automatic load prioritization, a battery charger, an ideal diode and numerous internal protection features. Designed specifically for USB applications, the LTC3553 power manager automatically limits input current to a maximum of either 100mA or 500mA. Battery charge current is automatically reduced such that the sum of the load current and the charge current does not exceed the selected input current limit. The LTC3553 also includes a synchronous buck regulator, a low dropout linear regulator (LDO), and a pushbutton controller. With all supplies enabled in standby mode, the quiescent current drawn from the battery is only 12?A. The LTC3553 is available in a 3mm ? 3mm ? 0.75mm 20-pin QFN package. Option LDO PGOOD Hard Reset Time LTC3553 ON/OFF Control No 5 Seconds LTC3553-2 Always On Yes 14 Seconds Applications USB-Based Handheld Products Portable Li-Ion/Polymer Based Electronic Devices Wearable Electronics Low Power Medical Devices

The LTC4365 protects applications where power supply input voltages may be too high, too low or even negative. It does this by controlling the gate voltages of a pair of external N-channel MOSFETs to ensure that the output stays within a safe operating range.The LTC4365 can withstand voltages between ?40V and 60V and has an operating range of 2.5V to 34V, while consuming only 125?A in normal operation.Two comparator inputs allow configuration of the overvoltage (OV) and undervoltage (UV) set points using an external resistive divider. A shutdown pin provides external control for enabling and disabling the MOSFETs as well as placing the device in a low current shutdown state. A fault output provides status of the gate pin pulling low. A fault is indicated when the part is in shutdown or the input voltage is outside the UV and OV set points.The LTC4365 has a 36ms turn-on delay that debounces live connections and blocks 50Hz to 60Hz AC power. For fast recovery after faults, the LTC4365-1 has a reduced 1ms turn-on delay.Applications Portable Instrumentation Industrial Automation Laptops Automotive Surge Protection

Demo circuit 1560A is an isolated flyback μModule® DC/DC converter with LDO post regulator featuring LTM8048. The demo circuit is designed for a 6V flyback output and a 5V post regulator output from a 4.5V to 30V input. The typical current capability of the 6V flyback output varies with input voltage from about 110mA at VIN = 4.5V to about 370mA at VIN = 30V. The circuit provides 725VDC isolation.

Demonstration circuit 1562B is an engineering tool to design and evaluate the LTC699X-X family of TimerBlox® circuits. The center section of the board contains a preconfigured TimerBlox function. DC1562B comes in twelve timing function variations as outlined in Table 1.

DC1563A-C: Demo Board for the LTC2312-12 - 12-Bit, 500ksps Serial Sampling ADC in TSOT.

The LTC2157-14/LTC2156-14/LTC2155-14 are 2-channel simultaneous sampling 250Msps/210Msps/170Msps 14-bit A/D converters designed for digitizing high frequency, wide dynamic range signals. They are perfect for demanding communications applications with AC performance that includes 70dB SNR and 90dB spurious free dynamic range (SFDR). The latency is only five clock cycles.DC specs include ?0.85LSB INL (typ), ?0.25LSB DNL (typ) and no missing codes over temperature. The transition noise is 1.82LSBRMS.The digital outputs are Double-Data Rate (DDR) LVDS.The ENC+ and ENC? inputs can be driven differentially with a sine wave, PECL, LVDS, TTL, or CMOS inputs. An optional clock duty cycle stabilizer allows high performance at full speed for a wide range of clock duty cycles. Bits LTC2156-12 12 LTC2156-14 14 Applications Communications Cellular Basestations Software Defined Radios Medical Imaging High Definition Video Testing and Measurement Instruments

The LTC2157-12/LTC2156-12/LTC2155-12 are a family of dual 250Msps/210Msps/170Msps 12-bit A/D converters designed for digitizing high frequency, wide dynamic range signals. They are perfect for demanding communications applications with AC performance that includes 68.5dB SNR and 90dB spurious free dynamic range (SFDR). The 1.25GHz input bandwidth allows the ADC to achieve high undersampling ratio with very low attenuation. The latency is only five clock cycles.DC specs include ?0.26LSB INL (typ), ?0.16LSB DNL (typ) and no missing codes over temperature. The transition noise is 0.54LSBRMS.The digital outputs are double data rate (DDR) LVDS.The ENC+ and ENC? inputs can be driven differentially with a sine wave, PECL, LVDS, TTL, or CMOS inputs. An optional clock duty cycle stabilizer allows high performance at full speed for a wide range of clock duty cycles. Bits LTC2156-12 12 LTC2156-14 14 Applications Communications Cellular Basestations Software Defined Radios Medical Imaging High Definition Video Testing and Measurement Instruments

The LTC2158-14 is a 2-channel simultaneous sampling 310Msps 14-bit A/D converter designed for digitizing high frequency, wide dynamic range signals. It is perfect for demanding communications applications with AC performance that includes 68.8dB SNR and 88dB spurious free dynamic range (SFDR). The 1.25GHz input bandwidth allows the ADC to undersample high frequencies with good performance. The latency is only five clock cycles.DC specs include ?1.2LSB INL (typ), ?0.35LSB DNL (typ) and no missing codes over temperature. The transition noise is 2.11LSBRMS.The digital outputs are double data rate (DDR) LVDS.The ENC+ and ENC? inputs can be driven differentially with a sine wave, PECL, LVDS, TTL, or CMOS inputs. An optional clock ? Bits LTC2158-12 12 LTC2158-14 14 Applications Communications Cellular Basestations Software Defined Radios Medical Imaging High Definition Video Testing and Measurement Instruments

The LT3663 is a current mode step-down switching regulator with programmable output current limit. The current limit accurately controls the system power dissipation and reduces the size of the power path components. The wide operating input voltage range of 7.5V to 36V (60V transient) suits the LT3663 to a variety of input sources, including unregulated 12V wall adapters, 24V industrial supplies, and automotive power. The LT3663 includes a low current shutdown mode, input overvoltage and undervoltage lockout, and thermal shutdown. Internal compensation and boost diode minimize the number of external exponents. 3.3V and 5V fixed output voltage versions are available. The LT3663 is available in 8-lead DFN and MSOP packages with exposed pads for low thermal resistance.Applications Distributed Supply Regulation Automotive Battery Regulation Industrial Supplies Wall Transformer Regulation
