The ADE7816 is a highly accurate, multichannel metering device that is capable of measuring one voltage channel and up to six current channels. It measures line voltage and current and calculates active and reactive energy, as well as instantaneous rms voltage and current. The device incorporates seven sigma-delta (?-?) ADCs with a high accuracy energy measurement core. The six current input channels allow multiple loads to be measured simultaneously. The voltage channel and the six current channels each have a complete signal path allowing for a full range of measurements. Each input channel supports a flexible gain stage and is suitable for use with current transformers (CTs). Six on-chip digital integrators facilitate the use of the Rogowski coil sensors.The ADE7816 provides access to on-chip meter registers via either the SPI or I2C interface. A dedicated high speed interface, the high speed data capture (HSDC) port, can be used in conjunction with I2C to provide access to real-time ADC output information. A full range of power quality information, such as overcurrent, overvoltage, peak, and sag detection, is accessible via the two external interrupt pins, IRQ0 and IRQ1.The ADE7816 energy metering IC operates from a 3.3 V supply voltage and is available in a 40-lead LFCSP that is Pb free and RoHS compliant.

The EVAL-ADF4XXX is a USB to parallel port adaptor board which allows control of older PLL evaluation boards using a standard USB port. The evaluation board kit comes with a USB cable and the adaptor PCB board. The board contains a USB microcontroller which converts the USB data to lower speed serial data which can be used to control the PLL boards directly. The board also has a USB connector and 25-pin D-connector. The parallel port cable that ships with the older PLL evaluation boards should be connected to the 25-pin D-connector. The USB port should be connected to your pc using the USB cable provided. USB drivers for the board are provided on the standard PLL evaluation board CD. Please install the ADI evaluation board software before plugging in the USB board.

The ADF5000 prescaler is a low noise, low power, fixed RF divider block that can be used to divide down frequencies as high as 18 GHz to a lower frequency suitable for input to a PLL IC, such as the?ADF4156 or the ADF4106. The ADF5000 provides a divide-by-2 function. The ADF5000 operates from a 3.3 V supply and has differential 100 ? RF outputs to allow direct interface to the differential RF inputs of PLLs such as the ADF4156 and ADF4106.Applications PLL frequency range extender Point-to-point radios VSAT radios Communications test equipment?

The ADF7012 is a low power FSK/GFSK/OOK/GOOK/ASK UHF transmitter designed for short-range devices (SRDs). The output power, output channels, deviation frequency, and modulation type are programmable by using four, 32-bit registers.The fractional-N PLL and VCO with external inductor enable the user to select any frequency in the 75 MHz to 1 GHz band. The fast lock times of the fractional-N PLL make the ADF7012 suitable in fast frequency hopping systems. The fine frequency deviations available and PLL phase noise performance facilitates narrow-band operation.There are five selectable modulation schemes: binary frequency shift keying (FSK), Gaussian frequency shift keying (GFSK), binary on-off keying (OOK), Gaussian on-off keying (GOOK), and amplitude shift keying (ASK). In the compensation register, the output can be moved in <1 ppm steps so that indirect compensation for frequency error in the crystal reference can be made.A simple 3-wire interface controls the registers. In power-down, the part has a typical quiescent current of <0.1 ?A.APPLICATIONS Low cost wireless data transfer Security systems RF remote controls Wireless metering Secure keyless entry

The ADF7020-1 is a low power, highly integrated FSK/ GFSK/ ASK/ OOK/ GOOK transceiver designed for operation in thelow UHF and VHF bands. The ADF7020-1 uses an externalVCO inductor that allows users to set the operating frequencyanywhere between 135 MHz and 650 MHz. Using the divide-by-2circuit allows users to operate the device as low as 80 MHz.The typical range of the VCO is about 10% of the operatingfrequency. A complete transceiver can be built using a smallnumber of external discrete components, making the ADF7020-1 very suitable for price-sensitive and area-sensitiveapplications.The transmit section contains a VCO and low noisefractional-N PLL with output resolution of <1 ppm. Thisfrequency agile PLL allows the ADF7020-1 to be used infrequency-hopping spread spectrum (FHSS) systems. The VCOoperates at twice the fundamental frequency to reduce spuriousemissions and frequency pulling problems.The transmitter output power is programmable in 63 steps from?20 dBm to +13 dBm. The transceiver RF frequency, channelspacing, and modulation are programmable using a simple 3-wire interface. The device operates with a power supply range of2.3 V to 3.6 V and can be powered down when not in useA low IF architecture is used in the receiver (200 kHz),minimizing power consumption and the external componentcount and avoiding interference problems at low frequencies.The ADF7020-1 supports a wide variety of programmablefeatures, including Rx linearity, sensitivity, and IF bandwidth,allowing the user to trade off receiver sensitivity and selectivityfor current consumption, depending on the application. Thereceiver also features a patent-pending automatic frequencycontrol (AFC) loop, allowing the PLL to compensate forfrequency error in the incoming signal.An on-chip ADC provides readback of an integrated temperaturesensor, an external analog input, the battery voltage, or theRSSI signal, which provides savings on an ADC in someapplications. The temperature sensor is accurate to ?10?C overthe full operating temperature range of ?40?C to +85?C. Thisaccuracy can be improved by doing a 1-point calibration atroom temperature and storing the result in memory.Applications Low cost wireless data transfer Wireless medical applications Remote control/security systems Wireless metering Keyless entry Home automation Process and building control

The ADF7020-1 is a low power, highly integrated FSK/ GFSK/ ASK/ OOK/ GOOK transceiver designed for operation in thelow UHF and VHF bands. The ADF7020-1 uses an externalVCO inductor that allows users to set the operating frequencyanywhere between 135 MHz and 650 MHz. Using the divide-by-2circuit allows users to operate the device as low as 80 MHz.The typical range of the VCO is about 10% of the operatingfrequency. A complete transceiver can be built using a smallnumber of external discrete components, making the ADF7020-1 very suitable for price-sensitive and area-sensitiveapplications.The transmit section contains a VCO and low noisefractional-N PLL with output resolution of <1 ppm. Thisfrequency agile PLL allows the ADF7020-1 to be used infrequency-hopping spread spectrum (FHSS) systems. The VCOoperates at twice the fundamental frequency to reduce spuriousemissions and frequency pulling problems.The transmitter output power is programmable in 63 steps from?20 dBm to +13 dBm. The transceiver RF frequency, channelspacing, and modulation are programmable using a simple 3-wire interface. The device operates with a power supply range of2.3 V to 3.6 V and can be powered down when not in useA low IF architecture is used in the receiver (200 kHz),minimizing power consumption and the external componentcount and avoiding interference problems at low frequencies.The ADF7020-1 supports a wide variety of programmablefeatures, including Rx linearity, sensitivity, and IF bandwidth,allowing the user to trade off receiver sensitivity and selectivityfor current consumption, depending on the application. Thereceiver also features a patent-pending automatic frequencycontrol (AFC) loop, allowing the PLL to compensate forfrequency error in the incoming signal.An on-chip ADC provides readback of an integrated temperaturesensor, an external analog input, the battery voltage, or theRSSI signal, which provides savings on an ADC in someapplications. The temperature sensor is accurate to ?10?C overthe full operating temperature range of ?40?C to +85?C. Thisaccuracy can be improved by doing a 1-point calibration atroom temperature and storing the result in memory.Applications Low cost wireless data transfer Wireless medical applications Remote control/security systems Wireless metering Keyless entry Home automation Process and building control

The ADF7020-1 is a low power, highly integrated FSK/ GFSK/ ASK/ OOK/ GOOK transceiver designed for operation in thelow UHF and VHF bands. The ADF7020-1 uses an externalVCO inductor that allows users to set the operating frequencyanywhere between 135 MHz and 650 MHz. Using the divide-by-2circuit allows users to operate the device as low as 80 MHz.The typical range of the VCO is about 10% of the operatingfrequency. A complete transceiver can be built using a smallnumber of external discrete components, making the ADF7020-1 very suitable for price-sensitive and area-sensitiveapplications.The transmit section contains a VCO and low noisefractional-N PLL with output resolution of <1 ppm. Thisfrequency agile PLL allows the ADF7020-1 to be used infrequency-hopping spread spectrum (FHSS) systems. The VCOoperates at twice the fundamental frequency to reduce spuriousemissions and frequency pulling problems.The transmitter output power is programmable in 63 steps from?20 dBm to +13 dBm. The transceiver RF frequency, channelspacing, and modulation are programmable using a simple 3-wire interface. The device operates with a power supply range of2.3 V to 3.6 V and can be powered down when not in useA low IF architecture is used in the receiver (200 kHz),minimizing power consumption and the external componentcount and avoiding interference problems at low frequencies.The ADF7020-1 supports a wide variety of programmablefeatures, including Rx linearity, sensitivity, and IF bandwidth,allowing the user to trade off receiver sensitivity and selectivityfor current consumption, depending on the application. Thereceiver also features a patent-pending automatic frequencycontrol (AFC) loop, allowing the PLL to compensate forfrequency error in the incoming signal.An on-chip ADC provides readback of an integrated temperaturesensor, an external analog input, the battery voltage, or theRSSI signal, which provides savings on an ADC in someapplications. The temperature sensor is accurate to ?10?C overthe full operating temperature range of ?40?C to +85?C. Thisaccuracy can be improved by doing a 1-point calibration atroom temperature and storing the result in memory.Applications Low cost wireless data transfer Wireless medical applications Remote control/security systems Wireless metering Keyless entry Home automation Process and building control

The ADF7020-1 is a low power, highly integrated FSK/ GFSK/ ASK/ OOK/ GOOK transceiver designed for operation in thelow UHF and VHF bands. The ADF7020-1 uses an externalVCO inductor that allows users to set the operating frequencyanywhere between 135 MHz and 650 MHz. Using the divide-by-2circuit allows users to operate the device as low as 80 MHz.The typical range of the VCO is about 10% of the operatingfrequency. A complete transceiver can be built using a smallnumber of external discrete components, making the ADF7020-1 very suitable for price-sensitive and area-sensitiveapplications.The transmit section contains a VCO and low noisefractional-N PLL with output resolution of <1 ppm. Thisfrequency agile PLL allows the ADF7020-1 to be used infrequency-hopping spread spectrum (FHSS) systems. The VCOoperates at twice the fundamental frequency to reduce spuriousemissions and frequency pulling problems.The transmitter output power is programmable in 63 steps from?20 dBm to +13 dBm. The transceiver RF frequency, channelspacing, and modulation are programmable using a simple 3-wire interface. The device operates with a power supply range of2.3 V to 3.6 V and can be powered down when not in useA low IF architecture is used in the receiver (200 kHz),minimizing power consumption and the external componentcount and avoiding interference problems at low frequencies.The ADF7020-1 supports a wide variety of programmablefeatures, including Rx linearity, sensitivity, and IF bandwidth,allowing the user to trade off receiver sensitivity and selectivityfor current consumption, depending on the application. Thereceiver also features a patent-pending automatic frequencycontrol (AFC) loop, allowing the PLL to compensate forfrequency error in the incoming signal.An on-chip ADC provides readback of an integrated temperaturesensor, an external analog input, the battery voltage, or theRSSI signal, which provides savings on an ADC in someapplications. The temperature sensor is accurate to ?10?C overthe full operating temperature range of ?40?C to +85?C. Thisaccuracy can be improved by doing a 1-point calibration atroom temperature and storing the result in memory.Applications Low cost wireless data transfer Wireless medical applications Remote control/security systems Wireless metering Keyless entry Home automation Process and building control

The ADF7021-V is a high performance, low power, narrow-band RF transceiver based on the ADF7021-N. The architecture of the ADF7021-V transceiver is similar to that of the ADF7021-N except that an external VCO is used by the on-chip RF synthesizer for applications that require improved phase noise performance.The ADF7021-V is designed to operate in both the license-free ISM bands and in the licensed bands from 80 MHz to 960 MHz.To minimize RF feedthrough and spurious emissions, the external VCO operates at 2? or 4? the desired RF frequency; the ADF7021-V supports a maximum VCO frequency operation of 1920 MHz. The 4? VCO operation is programmable by enabling an additional on-chip divide-by-2 outside the RF synthesizer loop and offers improved phase noise performance.As with the ADF7021-N receiver, the IF filter bandwidths of 9 kHz, 13.5 kHz, and 18.5 kHz are supported, making the ADF7021-V ideally suited to worldwide narrow-band telemetry applications.The part has both Gaussian and raised cosine transmit data filtering options to improve spectral efficiency for narrow-band applications. It is suitable for circuit applications targeted at the following: European ETSI EN 300 220 North American FCC Part 15, Part 90, and Part 95 Japanese ARIB STD-T67 Korean short-range device regulations Chinese short-range device regulationsA complete transceiver can be built using a small number of discrete external components, making the ADF7021-V very suitable for area-sensitive, high performance driven applications.See data sheet for more information.APPLICATIONS Narrow-band, short range device (SRD) standards ETSI EN 300 220 FCC Part 90 (meets Emission Mask D requirements) FCC Part 95 ARIB STD-T67 Wireless Metering Narrow-band wireless telemetry

The ADF7024 is an ultralow power, integrated transceiver for use in the license-free ISM bands at 433 MHz, 868 MHz, and 915 MHz. Its ease of use and high performance make it suitable for a wide variety of wireless applications. The ADF7024 is suitable for operation under the European ETSI EN 300-220 regulation, the North American FCC Part 15 regulation, and other similar regulatory standards.The ADF7024 can operate under a number of predefined radio profiles. For each radio profile, optimized register settings are provided for the ADF7024 radio. This ensures that the RF communication layer works seamlessly, allowing the user to concentrate on the protocol and system level design and prototyping. The radio profiles cover common data rate and modulation options. There are six radio profiles in total, as shown in Table 1.The ADF7024 operates with a power supply range of 2.2 V to 3.6 V and has very low power consumption in both Tx and Rx modes, enabling long lifetimes in battery-operated systems while maintaining excellent RF performance.The low IF receiver minimizes power consumption and provides excellent sensitivity. The receiver is exceptionally linear and, therefore, is very resilient to the presence of interferers in spectrally noisy environments. The highly efficient transmitter has programmable output power up to 13.5 dBm and automatic power amplifier (PA) ramping to meet transient spurious specifications. The RF synthesizer comprises a voltage controlled oscillator (VCO), a low noise fractional-N phase-locked loop (PLL) and a loop filter, all of which are fully integrated and automatically calibrated. This agile frequency synthesizer facilitates the implementation of frequency-hopping spread spectrum (FHSS) systems.The smart wake mode (SWM) allows the ADF7024 to wake up autonomously from sleep using the internal wake-up timer without intervention from the host processor. This functionality allows carrier sense, packet sniffing, and packet reception while the host processor is in sleep, thereby reducing overall system current consumption.The ADF7024 eases the processing burden of the host processor by integrating the lower layers of a typical communication protocol stack. The host processor can configure the ADF7024 using a simple command-based protocol over a standard 4-wire SPI interface. A single-byte command transitions the radio between states or performs a radio function.A complete wireless solution can be built using a small number of external discrete components and a host processor (typically a microcontroller).For more information, see the ADF7024 Hardware Reference Manual, UG-698, which is only available as part of the ADF7024 design resource package.APPLICATIONS Wireless sensor networks (WSNs) Home and building automation Asset tracking Process and building control Industrial control Internet of Things (IoT)
