The LTC3406B is a high efficiency monolithic synchronous buck regulator using a constant frequency, current mode architecture. The device is available in an adjustable version and fixed output voltages of 1.5V and 1.8V. Supply current with no load is 300?A and drops to <1?A in shutdown. The 2.5V to 5.5V input voltage range makes the LTC3406B ideally suited for single Li-Ion battery-powered applications. 100% duty cycle provides low dropout operation, extending battery life in portable systems. PWM pulse skipping mode operation provides very low output ripple voltage for noise sensitive applications.Switching frequency is internally set at 1.5MHz, allowing the use of small surface mount inductors and capacitors. The internal synchronous switch increases efficiency and eliminates the need for an external Schottky diode. Low output voltages are easily supported with the 0.6V feedback reference voltage. The LTC3406B is available in a low profile (1mm) ThinSOT package. Refer to LTC3406 for applications that require Burst Mode? operation. VOUT FSW Features LTC3406 Adj. 1.5MHz Burst Mode LTC3406-1.2 1.2V 1.5MHz Burst Mode LTC3406-1.5 1.5V 1.5MHz Burst Mode LTC3406-1.8 1.8V 1.5MHz Burst Mode LTC3406B Adj 1.5MHz Burst Mode Disabled LTC3406B-1.2 1.2V 1.5MHz Burst Mode Disabled LTC3406B-2 Adj. 2.25MHz Burst Mode Disabled LTC3406A Adj. 1.5MHz Low Ripple Burst Mode LTC3406AB Adj. 1.5MHz Burst Mode Disabled LTC3406AB-2 Adj. 2.25MHz Burst Mode Disabled Applications Cellular Telephones Personal Information Appliances Wireless and DSL Modems Digital Still Cameras MP3 Players Portable Instruments

Demonstration circuit DC500 is a constant-frequency step-down converter, using the various versions (fixed output/adjustable output/Burst Mode/Burst Mode defeated) of the LTC3406 or LTC3406B monolithic synchronous buck regulators. The DC500 has an input voltage range of 2.7V to 5.5V, and is capable of delivering up to 600 mA of output current at minimum input voltage of 3V. The DC500A-E features the 1.5V fixed output LTC3406B-1.5 (Burst Mode defeated).

DC511A: Demo Board for the LT3439 Slew Rate Controlled Ultralow Noise 1A Isolated DC/DC Transformer Driver.

The LT1738 is a switching regulator controller designed to lower conducted and radiated electromagnetic interference (EMI). Ultralow noise and EMI are achieved by controlling the voltage and current slew rates of an external N-channel MOSFET switch. Current and voltage slew rates can be independently set to optimize harmonic content of the switching waveforms vs efficiency. The LT1738 can reduce high frequency harmonic power by as much as 40dB with only minor losses in efficiency. The LT1738 utilizes a current mode architecture optimized for single switch topologies such as boost, flyback and Cuk. The IC includes gate drive and all necessary oscillator, control and protection circuitry. Unique error amp circuitry can regulate both positive and negative voltages. The internal oscillator may be synchronized to an external clock for more accurate placement of switching harmonics. Protection features include gate drive lockout for low VIN, soft-start, output current limit, short-circuit current limit-ing, gate drive overvoltage clamp and input supply undervoltage lockout.Applications Power Supplies for Noise Sensitive Communication Equipment EMI Compliant Offline Power Supplies Precision Instrumentation Systems Isolated Supplies for Industrial Automation Medical Instruments Data Acquisition Systems

Demonstration circuit 516A-B is a low output voltage, synchronous boost converter featuring the LTC3424. The LTC3424 is ideal for applications that require an output voltage between 1.5V to 2.6V from a single alkaline or NiCd/NiMH cell. A bias voltage (VDD) of 2.7V to 5.5V is required to power the internal circuitry. The input voltage (VIN) range is 1V to 1.6V, but once up and running, the device can operate with an input voltage as low as 0.5V. The output voltage is set at 1.8V. For a 1V minimum battery voltage, the LTC3424 can provide 600mA.

The LTC4230 is a 3-channel Hot Swap? controller that allows a board to be safely inserted and removed from a live backplane. Internal high side switch drivers control the gates of external N-channel MOSFETs for supply voltages ranging from 1.7V to 16.5V. The LTC4230 provides soft-start and inrush current limiting during the programmable start-up period.On-chip current limit comparators provide dual level circuit breaker protection. The slow comparators trip at VCCn?? 50mV and activate in 10?s or are programmed by an external filter capacitor. The fast comparators trip at VCCn?? 150mV and typically respond in 500ns.Each FBn?pin monitors its own output supply voltage and signals its RESET pin. The ON pin turns the chip on and off and can be used for a reset function. The LTC4230 also provides additional functions including fault indication, autoretry or latchoff modes, programmable current limit response time based on the FAULT and FILTER pins? functionality.Applications Electronic Circuit Breaker Hot Board Insertion and Removal (Either On Backplane or On Removable Card) Industrial High Side Switch/Circuit Breaker

The LTC1604 is a 333ksps, 16-bit sampling A/D converter that draws only 220mW from ?5V supplies. This high performance device includes a high dynamic range sample-and-hold, a precision reference and a high speed parallel output. Two digitally selectable power shutdown modes provide power savings for low power systems.The LTC1604's full-scale input range is ?2.5V. Outstanding AC performance includes 90dB S/(N+D) and ?100dB THD at a sample rate of 333ksps.The unique differential input sample-and-hold can acquire single-ended or differential input signals up to its 15MHz bandwidth. The 68dB common mode rejection allows users to eliminate ground loops and common mode noise by measuring signals differentially from the source.The ADC has ?P compatible,16-bit parallel output port. There is no pipeline delay in conversion results. A separate convert start input and a data ready signal (BUSY) ease connections to FlFOs, DSPs and microprocessors.Applications Telecommunications Digital Signal Processing Multiplexed Data Acquisition Systems High Speed Data Acquisition Spectrum Analysis Imaging Systems

The LTC1628/LTC1628-PG are high performance dual step-down switching regulator controllers that drive all N-channel synchronous power MOSFET stages. A constant frequency current mode architecture allows adjustment of the frequency up to 300kHz. Power loss and noise due to the ESR of the input capacitors are minimized by operating the two controller output stages out of phase.OPTI-LOOP compensation allows the transient response to be optimized over a wide range of output capacitance and ESR values. The precision 0.8V reference and power good output indicator are compatible with future microprocessor generations, and a wide 3.5V to 30V (36V maximum) input supply range encompasses all battery chemistries.A RUN/SS pin for each controller provides both soft-start and optional timed, short-circuit shutdown. Current foldback limits MOSFET dissipation during short-circuit conditions when overcurrent latchoff is disabled. Output overvoltage protection circuitry latches on the bottom MOSFET until VOUT returns to normal. The FCB mode pin can select among Burst Mode, constant frequency mode and continuous inductor current mode or regulate a secondary winding. The LTC1628-PG includes a power good output pin that replaces the FLTCPL, fault coupling control pin of the LTC1628.Applications Notebook and Palmtop Computers, PDAs Battery Chargers Portable Instruments Battery-Operated Digital Devices DC Power Distribution Systems

DC551A-A: Demo Board for LTC4002-4.2 Standalone Li-Ion Switch Mode Battery Charger.

DC562A-A: Demo Board for the LT1725 General Purpose Isolated Flyback Controller.
