LTC3838EUHF-2 Demo Board | 4.5V ≤ VIN ≤ 14V; VOUT1 = 1.5V @ 20A, VOUT2 = 1.2V @ 20A
Analog Devices Inc.
Demonstration circuit DC1997A is a dual output synchronous buck converters featuring the LTC3838EUHF-1 (DC1997A-A) or the LTC3838EUHF-2 (DC1997A-B). Both assemblies provide two outputs of 1.5V/20A and 1.2V/20A over an input voltage range of 4.5V to 14V at a switching frequency of 300kHz. The LTC3838-1 and LTC3838-2 provide dual differential VOUT sensing while the dual LTC3838 (plain) has differential VOUT sensing on one channel. The "-2" version has an external reference input for channel 2.
$198.62
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | DC1997A-B-ND | 0 | 1 | $185.45 | $185.45 | $185.45 | $185.45 | $185.45 | $185.45 | Buy |
|
|
Analog Devices Inc | DC1997A-B | $198.62 | $198.62 | $198.62 | $198.62 | $198.62 | $198.62 | Buy | ||
|
 |
Arrow North American Components | DC1997A-B | 0 | 1 | $188.79 | $186.90 | $183.18 | $181.35 | $175.97 | $174.21 | Buy |
|
|
Verical Marketplace | DC1997A-B | 89 | 1 | $196.54 | $196.54 | $196.54 | $196.54 | $196.54 | $196.54 | Buy |
