LT8315EFE Isolated Demo Board | Offline Flyback, 90VAC ≤ VIN ≤ 265VAC, VOUT = 12V @ 0.55A
Analog Devices Inc.
Demonstration circuit 2337A is an offline isolated flyback converter featuring LT8315. The demo board outputs 12V, and maintains tight regulation with a load current from 4mA to 0.55A. It is optimized to operate over a wide AC input voltage range (90VAC to 265VAC, 47Hz to 63Hz). Output voltage accuracy stays within ±5% over the whole input voltage and load range.
$235.40
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | DC2337A-ND | 1 | 1 | $271.86 | $271.86 | $271.86 | $271.86 | $271.86 | $271.86 | Buy |
|
|
Analog Devices Inc | DC2337A | $235.40 | $235.40 | $235.40 | $235.40 | $235.40 | $235.40 | Buy | ||
|
 |
Arrow North American Components | DC2337A | 0 | 1 | $241.29 | $241.29 | $241.29 | $241.29 | $241.29 | $241.29 | Buy |
|
|
Verical Marketplace | DC2337A | 49 | 1 | $232.93 | $232.93 | $232.93 | $232.93 | $232.93 | $232.93 | Buy |
