LTC3458EDE Demo Board | 2V ≤ VIN ≤ 6V, VOUT = 7V @ 200mA ‐ 800mA
Analog Devices Inc.
Demonstration circuit 728 is a 1MHz Synchronous Step- Up DC/DC Converter featuring the LTC®3458EDE. The demo circuit demonstrates a DC/DC boost converter, with a 1.5A switch, providing 7V at 200mA to 800mA depending on input voltage, which ranges from 2V to 6V. The circuit demonstrates the advantages of output disconnect and inrush current limiting.
$117.70 - $134.66
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | DC728A-ND | 0 | 1 | $129.46 | $129.46 | $129.46 | $129.46 | $129.46 | $129.46 | Buy |
|
|
Analog Devices Inc | DC728A | $117.70 | $117.70 | $117.70 | $117.70 | $117.70 | $117.70 | Buy | ||
|
 |
Arrow North American Components | DC728A | 0 | 1 | $123.07 | $121.83 | $119.41 | $118.22 | $114.70 | $113.56 | Buy |
|
|
Mouser Electronics | 584-DC728A | 0 | 1 | $134.66 | $134.66 | $134.66 | $134.66 | $134.66 | $134.66 | Buy |
