MAX25221CATJ/V+
Analog Devices Inc.
Category: Displays
The MAX25220/MAX25221/MAX25221B/MAX25221C are a 4-channel TFT-LCD power IC that provides symmetrical positive AVDD and negative NAVDD supplies as well as VGON and VGOFF gate supplies. In addition, a VCOM buffer with output voltage range above and below ground and a temperature measurement block are integrated (MAX25221/B/C).The device contains non-volatile memory so that the values of all outputs can be calibrated for the lifetime of the device (maximum five times).Programming is carried out using the built-in I2C interface, which can also be used to read back diagnostic information. A stand-alone mode is also available.The temperature sensor interface block measures the temperature optionally allowing the VCOM output voltage to be adjusted depending on the measured temperature.The MAX25220/MAX25221/MAX25221B/MAX25221C are available in a TQFN package and operates in the -40°C to +125°C temperature range.ApplicationsCentral Information DisplaysInfotainment DisplaysInstrument Clusters
$2.19 - * $6.95
Distributors
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
Analog Devices Inc | MAX25221CATJ/V+ | $2.61 | $2.61 | Buy | ||||||
|
 |
element14 APAC | MAX25221CATJ/V+ | 226 | 1 | * $6.95 | * $5.35 | * $4.61 | * $3.84 | * $3.83 | * $3.83 | Buy |
|
 |
Farnell | MAX25221CATJ/V+ | 226 | 1 | * $6.89 | * $5.30 | * $4.57 | * $4.10 | * $3.78 | * $3.78 | Buy |
|
|
Mouser Electronics | 700-MAX25221CATJ/V+ | 1465 | 1 | $2.19 | $1.23 | $1.23 | $1.18 | $1.18 | $1.18 | Buy |
Technical Specifications
| ROHS Compliance | Compliant |
