Teltonika OTD500 5G Outdoor IP55 Router

• Connectivity: 5G, LTE, 3G with 4 SIM card slots
• Security Features: Firewall, VPN support (OpenVPN, IPsec, PPTP, L2TP)
• Design: Rugged IP55 rated, suitable for outdoor use
• Performance: MediaTek processor, 0.88 GHz, DDR3 RAM
• Power: PoE support, 9 W power consumption
• Management: Web-based management, supports HTTP, HTTPS, SNMP
• Dimensions: 110 x 235 x 49.3 mm

Kit Contents

• OTD500 router
• Router holder
• Quick Start Guide (QSG)
• Packaging box

Features:

• Mobile:

  • 5G sub-6GHz SA/NSA 2.4/3.4Gbps DL (4x4 MIMO), 900/550Mbps UL (2x2), 4G LTE - LTE Cat 19 1.6Gbps DL/200Mbps UL, and 3G up to 42Mbps DL/5.76Mbps UL
  • eSIM:

    • Consumer type eSIM, profile download, removal operations, and up to 7 eSIM profiles
• Supports sending and reading Unstructured Supplementary Service Data (USSD) data messages
• Band management:

  • Band lock and used band status display
• Direct connection (bridge) between mobile ISP and device on LAN
• SIM PIN code management:

  • SIM PIN code management enables setting, changing, or disabling the SIM card's PIN
• Ethernet:

  • 2 x ETH ports (can be configured as WAN), 10/100/1000Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, and supports auto MDI/MDIX crossover
• Security:

  • Port and tag-based VLAN separation VLAN
  • Mobile quota control:

    • Mobile data limit, customizable period, start time, warning limit, and phone number
  • Identification and authentication module, TPM 2.0 standard
  • Flexible access control of SSH, Web interface, CLI, and Telnet
• Network:

  • Firewall:

    • Port forward, traffic rules, custom rules, and TTL target customization
  • Network backup:

    • VRRP and wired options, each of which can be used as an automatic failover
    • Static routing, dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), and policy-based routing
    • VoIP passthrough support :

      • H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
• PoE In:

  • 1 x PoE In port
  • 802.3af/at PoE standards
• PoE out:1 x PoE out port

  • 802.3af Alternative B PoE standards
  • 15W maximum (power supply unit dependent)
• VPN:

  • OpenVPN multiple clients and a server can run simultaneously, 27 encryption methods
  • GRE:

    • GRE tunnel and GRE tunnel over IPsec support
  • SSTP client instance support
  • ZeroTier VPN client support
  • WireGuard VPN client and server support
  • Client/Server instances can run simultaneously, L2TPv3, and L2TP over IPsec support
• System characteristics:

  • CPU:

    • MediaTek, dual-core, 880MHz, and MIPS1004Kc
  • RAM:

    • 256MB and DDR3
    • 16MB serial NOR flash and 256MB serial NAND flash
• Power:

  • RJ45 socket
  • 42.5VDC to 57VDC input voltage range, reverse polarity protection, and voltage surge/transient protection
  • Power consumption:

    • 2.5W/9W idle maximum and 24W PoE maximum
• Operating environment:

  • -40°C to 55°C temperature range
  • 10% to 90% non-condensing humidity
  • IP55 rating
• CE, UKCA, RCM, CB, EAC, UCRF, and WEEE regulation

$476.42
