OPTOCOUPLER, SMD, DARLINGTON O/P; No. of Channels:1 Channel; Optocoupler Case Style:SOP; No. of Pins:4Pins; Forward Current If Max:50mA; Isolation Voltage:3.75kV; CTR Min:600%; Collector Emitter Voltage V(br)ceo:35V; Product Range:-; Approval Bodies:UL; Approval Category:UL Recognised; Continuous Collector Current Ic Max:80mA; Current Transfer Ratio Min:600%; External Depth:4.4mm; External Length / Height:2.6mm; External Width:5.3mm; Fall Time tf:250µs; Forward Voltage VF Max:1.4VDC; Input Current:20mA; Lead Spacing:2.54mm; No. of Channels:1Channels; Operating Temperature Max:100°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +100°C; Optocoupler Output Type:Photodarlington; Output Voltage:35V; Output Voltage Max:35VDC; Peak Forward Current:50mA; Rise Time:300µs

OPTOCOUPLER, SMD, TRANSISTOR O/P; No. of Channels:1 Channel; Optocoupler Case Style:SOP; No. of Pins:4Pins; Forward Current If Max:50mA; Isolation Voltage:3.75kV; CTR Min:50%; Collector Emitter Voltage V(br)ceo:80V; Product Range:PC35 Series; Approval Bodies:UL; Approval Category:UL Recognised; Continuous Collector Current Ic Max:8mA; Current Transfer Ratio Max:160%; Current Transfer Ratio Min:80%; External Depth:4.4mm; External Length / Height:2.6mm; External Width:5.3mm; Fall Time tf:18µs; Forward Voltage VF Max:1.4VDC; Input Current:20mA; Lead Spacing:2.54mm; No. of Channels:1Channels; Operating Temperature Max:100°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +100°C; Optocoupler Output Type:Phototransistor; Output Voltage:80V; Output Voltage Max:80VDC; Peak Forward Current:50mA; Rise Time:18µs

LED MOD, 3.6W, 190LM, 3000K, CRI 85; Product Range:Zenigata Series; LED Module Type:Board + LED; LED Colour:Warm White; CCT:3220K; Luminous Flux @ Test:190lm; Luminous Flux @ Max:-; Power Rating:3.6W; Supply Voltage:10.2V; Forward Current @ Test:360mA; Power Module Configuration:Square; Operating Temperature Min:-30°C; Operating Temperature Max:90°C; MSL:-; Colour Rendering Index:85; Forward Current If:400mA; Forward Current If Max:400mA; Forward Voltage @ Test:10.2V; Forward Voltage VF Max:11.5V; LED Mounting:Screw; Luminous Flux:190lm; Luminous Flux Min:140lm; No. of Pins:2Pins; Operating Temperature Range:-30°C to +90°C; Power @ Test:3.7W; Power Dissipation Pd:4.4W; Reverse Protection Voltage:-15V

LED MOD, 6.7W, 300LM, 2700K, CRI 85; Product Range:-; LED Module Type:Board + LED; LED Colour:Warm White; CCT:2870K; Luminous Flux @ Test:300lm; Luminous Flux @ Max:-; Power Rating:6.7W; Supply Voltage:10.2V; Forward Current @ Test:640mA; Power Module Configuration:Square; Operating Temperature Min:-30°C; Operating Temperature Max:90°C; MSL:-; Colour Rendering Index:85; Forward Current If:700mA; Forward Current If Max:700mA; Forward Voltage @ Test:10.2V; Forward Voltage VF Max:11.5V; LED Mounting:Screw; Luminous Flux:300lm; Luminous Flux Min:210lm; No. of Pins:2Pins; Operating Temperature Range:-30°C to +90°C; Power @ Test:6.5W; Power Dissipation Pd:8W; Reverse Protection Voltage:-15V

LED MOD, 6.7W, 390LM, 3500K, CRI 87; Product Range:MINI ZENIGATA Series; LED Module Type:Board + LED; LED Colour:Neutral White; CCT:3600K; Luminous Flux @ Test:390lm; Luminous Flux @ Max:-; Power Rating:6.7W; Supply Voltage:10.2V; Forward Current @ Test:640mA; Power Module Configuration:Square; Operating Temperature Min:-30°C; Operating Temperature Max:90°C; MSL:-; Colour Rendering Index:87; Forward Current If:700mA; Forward Current If Max:700mA; Forward Voltage @ Test:10.2V; Forward Voltage VF Max:11.5V; Luminous Flux:390lm; Luminous Flux Min:310lm; No. of Pins:2Pins; Operating Temperature Range:-30°C to +90°C; Power @ Test:6.5W; Power Dissipation Pd:8W; Reverse Protection Voltage:-15V

LED MOD, 6.7W, 390LM, 4000K, CRI 87; Product Range:MINI ZENIGATA Series; LED Module Type:Board + LED; LED Colour:Neutral White; CCT:4260K; Luminous Flux @ Test:390lm; Luminous Flux @ Max:-; Power Rating:6.5W; Supply Voltage:10.2V; Forward Current @ Test:640mA; Power Module Configuration:Square; Operating Temperature Min:-30°C; Operating Temperature Max:90°C; MSL:-; Colour Rendering Index:87; Forward Current If:700mA; Forward Current If Max:700mA; Forward Voltage @ Test:10.2V; Forward Voltage VF Max:11.5V; Luminous Flux:390lm; No. of Pins:2Pins; Operating Temperature Range:-30°C to +90°C; Power @ Test:6.5W; Power Dissipation Pd:8W; Reverse Protection Voltage:-15V

LED, PLCC4, 17LM, 5300K, 6400MCD; LED Colour:Cool White; LED Mounting:SMD; Bulb Size:-; Forward Current If:30mA; Forward Voltage:3.2V; Luminous Intensity:6.4mcd; Viewing Angle:-; Lens Shape:Round; Product Range:-; Automotive Qualification Standard:-; MSL:-; CCT:5300K; Forward Current @ Test:20mA; Forward Current If Max:30mA; Forward Voltage @ Test:3.2V; Forward Voltage VF Max:3.5V; Luminous Flux:17lm; Luminous Flux @ Test:17lm; Luminous Intensity @ Test:6.4mcd; Luminous Intensity Typ:6400mcd; No. of Pins:4Pins; Operating Temperature Max:100°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +100°C; Power @ Test:0.1W; Power Dissipation Pd:300mW; Reverse Protection Voltage:5V

LED, PLCC2, 5.0LM, 3000K, CRI 85; LED Colour:Warm White; LED Mounting:SMD; Bulb Size:-; Forward Current If:30mA; Forward Voltage:3.2V; Luminous Intensity:2cd; Viewing Angle:-; Lens Shape:Round; Product Range:-; Automotive Qualification Standard:-; MSL:-; CCT:3000K; Colour Rendering Index:85; Forward Current @ Test:20mA; Forward Current If Max:35mA; Forward Voltage @ Test:3.2V; Forward Voltage VF Max:3.7V; Luminous Flux:5lm; Luminous Intensity @ Test:2cd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +100°C; Power @ Test:0.1W; Power Dissipation Pd:123mW

LED, MINIZENI, 7W, PURE WHT, 5000K; LED Colour:Cool White; LED Mounting:SMD; Bulb Size:-; Forward Current If:-; Forward Voltage:-; Luminous Intensity:-; Viewing Angle:-; Lens Shape:-; Product Range:MINI ZENIGATA Series; Automotive Qualification Standard:-; MSL:-; CCT:5000K; Forward Current @ Test:520mA; Forward Current If Max:600mA; Forward Voltage @ Test:13.1V; Luminous Flux @ Test:560lm; No. of Pins:2Pins; Operating Temperature Max:90°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +90°C; Power @ Test:6.8W; Power Dissipation Pd:6.8W

LED, MINIZENI, 10W, NAT, WHT, 4000K; Product Range:MINI ZENIGATA Series; LED Colour:Neutral White; Viewing Angle:-; Luminous Flux @ Test:670lm; CCT:4080K; Forward Current If Max:550mA; Forward Voltage @ Test:19.6V; Forward Current @ Test:480mA; Power Dissipation Pd:9.4W; LED Mounting:SMD; No. of Pins:2Pins; Operating Temperature Max:90°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +90°C; Power @ Test:9.4W
