Evaluation PCB for High-Speed Single Open-Loop Buffer in the 8-Pin PSOP Package

Single to Single ADC Driver PCB for LMH6611 and LMH6618 (SOT23 package; unstuffed)

Single to Differential ADC Driver PCB for LMH6612 and LMH6619 (SOIC package, unstuffed)

Differential to Differential ADC Driver PCB for LMH6612 and LMH6619 (SOIC package; unstuffed)

evaluation module for charge pump inverter (bare PCB)

processing, such as filtering, amplification,or PCB layout related mismatches. Because both channels

The AD9910 is a direct digital synthesizer (DDS) featuringan integrated 14-bit DAC and supporting sample rates up to1 GSPS. The AD9910 employs an advanced, proprietary DDStechnology that provides a significant reduction in power consumptionwithout sacrificing performance. The DDS/DACcombination forms a digitally programmable, high frequency,analog output synthesizer capable of generating a frequencyagile sinusoidal waveform at frequencies up to 400 MHz.The user has access to the three signal control parameters thatcontrol the DDS: frequency, phase, and amplitude. The DDSprovides fast frequency hopping and frequency tuning resolutionwith its 32-bit accumulator. With a 1 GSPS sample rate, thetuning resolution is ~0.23 Hz. The DDS also enables fast phaseand amplitude switching capability.The AD9910 is controlled by programming its internal controlregisters via a serial I/O port. The AD9910 includes an integratedstatic RAM to support various combinations of frequency, phase,and/or amplitude modulation. The AD9910 also supports a userdefined, digitally controlled, digital ramp mode of operation. Inthis mode, the frequency, phase, or amplitude can be variedlinearly over time. For more advanced modulation functions, ahigh speed parallel data input port is included to enable directfrequency, phase, amplitude, or polar modulation.The AD9910 is specified to operate over the extended industrialtemperature range.Applications Agile local oscillator (LO) frequency synthesis Programmable clock generators FM chirp source for radar and scanning systems Test and measurement equipment Acousto-optic device drivers Polar modulators Fast frequency hopping

The AD9912 is a direct digital synthesizer (DDS) that features an integrated 14-bit digital-to-analog converter (DAC). The AD9912 features a 48-bit frequency tuning word (FTW) that can synthesize frequencies in step sizes no larger than 4 ?Hz. Absolute frequency accuracy can be achieved by adjusting the DAC system clock.The AD9912 also features an integrated system clock phase-locked loop (PLL) that allows for system clock inputs as low as 25 MHz.The AD9912 operates over an industrial temperature range, spanning ?40?C to +85?C.APPLICATIONS Agile LO frequency synthesis Low jitter, fine tune clock generation Test and measurement equipment Wireless base stations and controllers Secure communications Fast frequency hopping

The ADCLK905 (one input, one output), ADCLK907 (dual oneinput, one output), and ADCLK925 (one input, two outputs) areultrafast clock/data buffers fabricated on the Analog Devices, Inc.,proprietary XFCB3 silicon germanium (SiGe) bipolar process.The ADCLK905/ADCLK907/ADCLK925 feature full-swing emitter coupled logic (ECL) output drivers. For PECL (positive ECL) operation, bias VCC to the positive supply and VEE to ground. For NECL (negative ECL) operation, bias VCC to ground and VEE to the negative supply.The buffers offer 95 ps propagation delay, 7.5 GHz toggle rate, 10 Gbps data rate, and 60 fs random jitter (RJ).The inputs have center tapped, 100 ?, on-chip termination resistors. A VREF pin is available for biasing ac-coupled inputs.The ECL output stages are designed to directly drive 800 mV each side into 50 ? terminated to VCC ? 2 V for a total differential output swing of 1.6 V.The ADCLK905/ADCLK907/ADCLK925 are available in 16-lead LFCSP packages.Applications Clock and data signal restoration and level shifting Automated test equipment (ATE) High speed instrumentation High speed line receivers Threshold detection Converter clocking

The ADIS16507 is a precision, miniature microelectromechanical?system (MEMS) inertial measurement unit (IMU) that includes?a triaxial gyroscope and a triaxial accelerometer. Each inertial?sensor in the ADIS16507 combines with signal conditioning?that optimizes dynamic performance. The factory calibration?characterizes each sensor for sensitivity, bias, alignment,?linear acceleration (gyroscope bias), and point of percussion?(accelerometer location). As a result, each sensor has dynamic?compensation formulas that provide accurate sensor?measurements over a broad set of conditions.The ADIS16507 provides a simplified, cost effective method for?integrating accurate, multiaxis inertial sensing into industrial?systems, especially when compared with the complexity and?investment associated with discrete designs. All necessary motion?testing and calibration are part of the production process at the?factory, greatly reducing system integration time. Tight orthogonal?alignment simplifies inertial frame alignment in navigation?systems. The serial peripheral interface (SPI) and register?structure provide a simple interface for data collection and?configuration control.The ADIS16507 is available in a 100-ball, ball grid array (BGA)?package that is approximately 15 mm ? 15 mm ? 5 mm.Applications Navigation, stabilization, and instrumentation Unmanned and autonomous vehicles Smart agriculture and construction machinery Factory/industrial automation, robotics Virtual/augmented reality Internet of Moving Things
