EVAL MODULE FOR TPS65910A

The ADXRS453 is an angular rate sensor (gyroscope) intended for industrial, instrumentation, and stabilization applications in high vibration environments. An advanced, differential, quad sensor design rejects the influence of linear acceleration, enabling the ADXRS453 to offer high accuracy rate sensing in harsh envi-ronments where shock and vibration are present.The ADXRS453 uses an internal, continuous self-test architec-ture. The integrity of the electromechanical system is checked by applying a high frequency electrostatic force to the sense structure to generate a rate signal that can be differentiated from the base-band rate data and internally analyzed.The ADXRS453 is capable of sensing an angular rate of up to ?300?/sec. Angular rate data is presented as a 16-bit word that is part of a 32-bit SPI message.The ADXRS453 is available in a 16-lead plastic cavity SOIC (SOIC_CAV) and an SMT-compatible vertical mount package (LCC_V), and is capable of operating across a wide voltage range (3.3 V to 5 V). ApplicationsRotation sensing in high vibration environments Rotation sensing for industrial and instrumentation applicationsHigh performance platform stabilization

Automotive 4-Channel Capacitive to Digital Converter Evaluation Module

The LTC3246 is a switched capacitor buck-boost DC/DC converter with integrated watchdog timer. The device produces a regulated output (3.3V, 5V or adjustable) from a 2.7V to 38V input. Switched capacitor fractional conversion is used to maintain regulation over a wide range of input voltage. Internal circuitry automatically selects the conversion ratio to optimize efficiency as input voltage and load conditions vary. No inductors are required.The LTC3246?s reset time and watchdog timeout may be set without external components, or adjusted using external capacitors. A windowed watchdog function is used for high reliability applications. The reset input can be used for additional supply monitoring or be configured as a pushbutton reset.Low operating current (20?A without load, 1.5?A in shutdown) and low external parts count make the LTC3246 ideally suited for low power, space constrained automotive/ industrial applications. The device is short-circuit and overtemperature protected and is available in a thermally enhanced 16-pin MSOP package.Applications Automotive ECU/CAN Transceiver Supplies Industrial/Telecom Housekeeping Supplies Low Power 12V to 5V Conversion

Demonstration Circuit 3001A-B showcases the LTC4451 ideal diode controller with an integrated low RDS(ON) MOSFET. The board includes two independent LTC4451 ideal diodes sharing a common ground and operates over a range of 0V to 40V, carrying up to 8A at 25°C ambient temperature. The board can be set up in a diode-OR configuration by connecting the output channels together. NOTE: Although the DC3001A-B can carry 8A at 25°C, the LTC4451 is designed for a max current of 7A across –40°C to 125°C. Please follow the data sheet recommendations to design your application across the operating temperature range.

The ADIS16507 is a precision, miniature microelectromechanical?system (MEMS) inertial measurement unit (IMU) that includes?a triaxial gyroscope and a triaxial accelerometer. Each inertial?sensor in the ADIS16507 combines with signal conditioning?that optimizes dynamic performance. The factory calibration?characterizes each sensor for sensitivity, bias, alignment,?linear acceleration (gyroscope bias), and point of percussion?(accelerometer location). As a result, each sensor has dynamic?compensation formulas that provide accurate sensor?measurements over a broad set of conditions.The ADIS16507 provides a simplified, cost effective method for?integrating accurate, multiaxis inertial sensing into industrial?systems, especially when compared with the complexity and?investment associated with discrete designs. All necessary motion?testing and calibration are part of the production process at the?factory, greatly reducing system integration time. Tight orthogonal?alignment simplifies inertial frame alignment in navigation?systems. The serial peripheral interface (SPI) and register?structure provide a simple interface for data collection and?configuration control.The ADIS16507 is available in a 100-ball, ball grid array (BGA)?package that is approximately 15 mm ? 15 mm ? 5 mm.Applications Navigation, stabilization, and instrumentation Unmanned and autonomous vehicles Smart agriculture and construction machinery Factory/industrial automation, robotics Virtual/augmented reality Internet of Moving Things

The ADF4371 allows implementation of fractional-N or Integer N phase-locked loop (PLL) frequency synthesizers when used with an external loop filter and an external reference frequency. The wideband microwave voltage controlled oscillator (VCO) design allows frequencies from 62.5 MHz to 32 GHz to be generated.The ADF4371 has an integrated VCO with a fundamental output frequency ranging from 4000 MHz to 8000 MHz. In addition, the VCO frequency is connected to divide by 1, 2, 4, 8, 16, 32, or 64 circuits that allows the user to generate radio frequency (RF) output frequencies as low as 62.5 MHz at RF8x. A frequency multiplier at RF16x generates from 8 GHz to 16 GHz. A frequency quadrupler generates frequencies from 16 GHz to 32 GHz at RF32x. RFAUX8x duplicates the frequency range of RF8x or permits direct access to the VCO output. To suppress the unwanted products of frequency multiplication, a harmonic filter exists between the multipliers and the output stages of RF16x and RF32x.Control of all on-chip registers is through a 3-wire interface. The ADF4371 operates with analog and digital power suppliesranging from 3.15 V to 3.45 V, and 5 V for the VCO power supply. The ADF4371 also contains hardware and software power-down modes. APPLICATIONS Wireless infrastructure (multicarrier global system for mobile communication (MC-GSM), 5 G) Test equipment and instrumentation Clock generation Aerospace and defense

The CC1352P device is a true multi band wireless MCU supporting long range applications with the industry’s lowest power integrated +20 dBm power amplifier (PA). The CC1352P enables concurrent operation at both 2.4  GHz and Sub-1 GHz frequencies with PA support determined by external RF matching components.

To kick start your development, we offer two LAUNCHXL-CC1352P LaunchPads with optimized external RF components, one for Sub-1GHz PA and another for 2.4GHz PA wireless operations:

LAUNCHXL-CC1352P1:

• Sub-1 GHz operation at 868 MHz / 915 MHz up to 20 dBm
• 2.4 GHz operation up to 5 dBm

LAUNCHXL-CC1352P-2:

• Sub-1 GHz operation at 868 MHz / 915 MHz up to +14 dBm
• 2.4 GHz operation up to +18 dBm (For Europe, 2.4 GHz operation is certified up to +10 dBm)

The CC1352P device is part of the SimpleLink™ microcontroller (MCU) platform which consists of Wi-Fi®, Bluetooth® low energy, Sub-1 GHz and host MCUs, which all share a common, easy-to-use development environment with a single core software development kit (SDK) and rich tool set.

Features:

• LaunchPad with multiband radio supporting concurrent 2.4 GHz and sub-1 GHz operation
• Broad band antenna support for Sub-1 GHz (868 MHz / 915 MHz) and 2.4 GHz frequency bands
• On-board emulator gets you started with instant code development
• All IOs accessible on pin headers compatible with the LaunchPad/BoosterPack eco system

What's included:

• LaunchPad Board
• Micro USB Cable
• Quick Start Guide

AM57x IDK LCD Kit

Dual op amp evaluation module for SOT23-8 package
