The ADM2761E/ADM2763E are 500 kbps, 5.7 kV rms, signal isolated RS-485 transceivers that pass radiated emissions testing to the EN 55032, Class B standard with margin on a 2-layer printed circuit board (PCB). These devices are compliant to the RS-485 and RS-422 communication standards. The ADM2761E/ ADM2763E isolation barrier provides robust system level immunity to IEC 61000-4-x system level electromagnetic compatibility (EMC) standards. The devices are suitable for applications that require insulation against working voltages of 1060 V rms and 1500 V dc for the lifetime of the device.The devices are protected against ??12 kV contact and ??15 kV air IEC 61000-4-2 electrostatic discharge (ESD) events on the RS-485 A, B, Y, and Z pins. The ADM2763E features a receiver cable invert pin to allow quick correction of the reversed cable connection on the A and B receiver bus pins while maintaining full receiver fail-safe performance.These devices are optimized for low speed over long cable runs and have a maximum data rate of 500 kbps. The high differential output voltage makes these devices suitable for PROFIBUS? nodes when powered with 5 V on the VDD2 supply. The VDD1 primary supply and VDD2 isolated supply both support a wide range of voltages (1.7 V to 5.5 V and 3.0 V to 5.5 V, respectively). Half-duplex and full duplex device options are available in the industry standard 16-lead, wide body, standard SOIC_W package with 8.3 mm creepage and clearance.Applications Solar inverters Electrical test and measurement Heating, ventilation, and air-conditioning (HVAC) networks Industrial field buses Building automation

LM53601-Q1 Adjustable Output; 1000mA Buck Regulator Evaluation Module With Spread Spectrum

The HMC629ALP4E is a broadband 4-bit GaAs ICDigital Attenuator in a low cost leadless SMT package.This versatile digital attenuator incorporates off-chipAC ground capacitors for near DC operation, makingit suitable for a wide variety of RF and IF applications.The dual mode control interface is CMOS/TTL compatible,and accepts either a three wire serial input ora 4-bit parallel word. The HMC629ALP4E is housedin a RoHS compliant 4x4 mm QFN leadless package,and requires no external matching components.Applications Cellular/3G infrastructure WiBro / WiMAX / 4G Microwave radio & VSAT Test equipment and sensors? IF & RF applications

The AD5764R is a quad, 16-bit, serial input, bipolar voltage output DAC that operates from supply voltages of ?11.4 V to ?16.5 V. Nominal full-scale output range is ?10 V. The AD5764R provides integrated output amplifiers, reference buffers, and proprietary power-up/power-down control circuitry. The part also features a digital I/O port, programmed via the serial interface, and an analog temperature sensor. The part incorporates digital offset and gain adjust registers per channel.The AD5764R is a high performance converter that provides guaranteed monotonicity, integral nonlinearity (INL) of ?1 LSB, low noise, and 10 ?s settling time. The AD5764R includes an on-chip 5 V reference with a reference temperature coefficient of 10 ppm/?C maximum. During power-up when the supply voltages are changing, VOUTx is clamped to 0 V via a low impedance path.The AD5764R is based on the iCMOS? technology platform, which is designed for analog systems designers within industrial/instrumentation equipment OEMs who need high performance ICs at higher voltage levels. iCMOS enables the development of analog ICs capable of 30 V and operation at ?15 V supplies, while allowing reductions in power consumption and package size, coupled with increased ac and dc performance.The AD5764R uses a serial interface that operates at clock rates of up to 30 MHz and is compatible with DSP and microcontroller interface standards. Double buffering allows the simultaneous updating of all DACs. The input coding is programmable to either twos complement or offset binary formats. The asynchronous clear function clears all data registers to either bipolar zero or zero scale, depending on the coding used. The AD5764R is ideal for both closed-loop servo control and open-loop control applications. The AD5764R is available in a 32-lead TQFP and offers guaranteed specifications over the ?40?C to +85?C industrial temperature range (see Figure 1 for the functional block diagram).APPLICATIONS Industrial automation Open-/closed-loop servo control Process control Data acquisition systems Automatic test equipment Automotive test and measurement High accuracy instrumentation

10-V to 55-V Input; 3.3-V Output; 4-A; Wide Input Range EVM

The HMC375LP3(E) is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier are ideal for GSM & CDMA cellular basestation front- end receivers operating between 1.7 and 2.2 GHz. This LNA has been optimized to provide 0.9 dB noise figure, 17 dB gain and +33 dBm output IP3 from a single supply of +5V @ 136mA. Input and output return losses are 14 dB typical with the LNA requiring minimal external components to optimize the RF input match, RF ground and DC bias.Applications GSM, GPRS & EDGE CDMA & W-CDMA DECT

The LTC2324-12 is a low noise, high speed quad 12-bit + sign successive approximation register (SAR) ADC with differential inputs and wide input common mode range. Operating from a single 3.3V or 5V supply, the LTC2324- 12 has an 8VP-P differential input range, making it ideal for applications which require a wide dynamic range with high common mode rejection. The LTC2324-12 achieves ?0.5LSB INL typical, no missing codes at 12 bits and 78dB SNR.The LTC2324-12 has an onboard low drift (20ppm/?C max) 2.048V or 4.096V temperature-compensated reference. The LTC2324-12 also has a high speed SPI-compatible serial interface that supports CMOS or LVDS. The fast 2Msps per channel throughput with no latency makes the LTC2324-12 ideally suited for a wide variety of high speed applications. The LTC2324-12 dissipates only 40mW per channel and offers nap and sleep modes to reduce the power consumption to 26?W for further power savings during inactive periods.Applications High Speed Data Acquisition Systems Communications Optical Networking Multiphase Motor Control

The LTC2983 measures a wide variety of temperature sensors and digitally outputs the result, in ?C or ?F, with 0.1?C accuracy and 0.001?C resolution. The LTC2983 can measure the temperature of virtually all standard (type B, E, J, K, N, S, R, T) or custom thermocouples, automatically compensate for cold junction temperatures and linearize the results. The device can also measure temperature with standard 2-, 3- or 4-wire RTDs, thermistors and diodes. It has 20 reconfigurable analog inputs enabling many sensor connections and configuration options. The LTC2983 includes excitation current sources and fault detection circuitry appropriate for each type of temperature sensor.The LTC2983 allows direct interfacing to ground referenced sensors without the need for level shifters, negative supply voltages, or external amplifiers. All signals are buffered and simultaneously digitized with three high accuracy, 24-bit ?? ADCs, driven by an internal 10ppm/?C (maximum) reference.Applications Direct Thermocouple Measurements Direct RTD Measurements Direct Thermistor Measurements Custom Sensor Applications

4/3FA 1.2 V Nickel Metal Hydride Battery Rechargeable (Secondary) 3.7Ah

22 µF ±20% 6.3V Ceramic Capacitor X5R 0603 (1608 Metric)
