The HMC955LC4B is a 1 to 2 Demux designed to support data transmission rates up to 32 Gbps. The demux uses both rising and falling edges of the half-rate clock to sample the data in sequence 01-02 and latches the data on the rising edge into the differential outputs. The demux also has high-speed clock synchronous invert input that allows for scrambling of the data. The HMC955LC4B also features an output level control pin, VR, which allows for loss compensation or for signal level optimization.All differential inputs to the HMC955LC4B are CML and terminated on-chip with 50 Ohms to the positive supply, GND, and may be AC or DC coupled. The differential CML outputs are source terminated to 50 Ohms and may also be AC or DC coupled. Outputs can be connected directly to a 50 Ohm ground-terminated system or drive devices with CML logic input. The HMC955LC4B operates from a single -3.3 V supply and is available in a ceramic ROHS-compliant 4x4 mm SMT package.APPLICATIONSSONET OC-192Broadband Test & Measurement EquipmentFPGA Interfacing Circuitry16 G and 32 G Fiber Channel100 Gbit EthernetADC Encoder

The HMC958LC5 is a 4:1 Selector designed to support data transmission rates of up to 14 Gbps and selector port operation up to 14 GHz. The selector routes the differential inputs to either one or both of the desired outputs upon assertion of the appropriately selected port. The HMC958LC5 also features an output level control pin, VR, which allows for loss compensation or for signal level optimization.All single-ended input signals to the HMC958LC5 are terminated with 50 ??to ground on-chip, and may be either AC or DC coupled. The outputs of the HMC958LC5 may be operated either differentially or single ended. Outputs can be connected directly to a 50 ??terminated system, while DC blocking capacitors may be used if the terminating system is 50 ? to a non-ground DC voltage. The HMC958LC5 operates from a single -3.3V DC supply and is available in a ceramic RoHS compliant 5 ? 5 mm SMT package.APPLICATIONS SONET OC-192 and 10 GbE 16G Fiber Channel 4:1 Multiplexer Built-In Test Broadband Test & Measurement

The ADG741 is a monolithic CMOS SPST switch. It is designed on an advanced submicron process that provides low power dissipation yet high switching speed, low on resistance, low leakage currents and -3 dB bandwidths of greater than 200 MHz can be achieved.The ADG741 can operate from a single 1.8 V to 5.5 V supply, making it ideal for use in battery-powered instruments and with Analog Devices' new generation of DACs and ADCs.APPLICATIONS Battery Powered Systems Communication Systems Sample Hold Systems Audio Signal Routing Video Switching Mechanical Reed Relay Replacement

The AD4695/AD4696 are compact, high accuracy, low power, 16-channel, 16-bit, 500 kSPS/1 MSPS, multiplexed input precision, successive approximation register (SAR) analog-to-digital converters (ADCs) with Easy Drive features and extensive digital functionality.The AD4695/AD4696 are optimal for use in space constrained, multichannel, precision data acquisition systems and monitoring circuits. The AD4695/AD4696 feature a true 16-bit SAR ADC core with no missing codes, a 16-channel, low crosstalk multiplexer, a flexible channel sequencer, overvoltage protection clamp circuits on each analog input, on-chip oversampling and decimation, threshold detection and alert indicators, and an autonomous conversion (autocycle) mode.The AD4695/AD4696 Easy Drive features relax the drive requirements of the analog front end (AFE) and reference circuitry. Analog input high-Z mode and reference input high?Z mode simplify system designs, reduce component count, and increase channel density by removing the need for dedicated high speed ADC drivers and reference buffers. The WLCSP option of the AD4695/AD4696 includes an internal reference buffer, which provides a true, buffered reference input.Input overvoltage protection clamps on each analog input protect the AD4695/AD4696 from overvoltage events and prevent overvoltage events on one channel from degrading performance on other channels (see Figure 27 in the data sheet).Advanced digital functionality makes the AD4695/AD4696 compatible with a variety of low power digital hosts. The low serial peripheral interface (SPI) clock rate requirements, on-chip customizable channel sequencers, and oversampling and decimation reduce the burden on the digital host system. Autocycle mode and threshold detection features enable low power, interrupt driven firmware design by performing conversions autonomously and generating alerts based on channel specific threshold limits.The AD4695/AD4696 are available in a 5 mm ? 5 mm 32-lead lead frame chip scale package (LFCSP) and a 2.96 mm ? 2.96 mm 36-ball wafer level chip scale package (WLCSP) with operation specified from ?40?C to +125?C.APPLICATIONS Photodiode monitoring Medical instrumentation Vital signs monitoring Electronic test and measurement Automated test equipment Instrumentation and process control Battery-powered equipment

DC918C-M: Demo Board for the LTC2201 16-Bit, 20Msps ADC.

DC919A-A: Demo Board for the LTC2207 16-Bit, 105Msps ADC.

DC919A-C: Demo Board for the LTC2205 16-Bit, 65Msps ADCs.

DC941A: Demo Board for the LTC2482 16-Bit Delta Sigma ADC with Easy Drive Input Current Cancellation.

Demonstration Circuit 974 is a 100kHz to -500kHz programmable frequency, high voltage, current-mode DC/DC step-down converter featuring the LT3844. The operating frequency can be synchronized up to 600kHz. The board operates from a Vin range of 15V to -60V and outputs 12VOUT @ 4.2A (50W).

The LT3585 series are highly integrated ICs designed to charge photo?ash capacitors in digital and ?lm cameras. A new control technique allows for the use of extremely small transformers. Each part contains an on-chip high voltage NPN power switch. Output voltage detection is completely contained within the part, eliminating the need for any discrete zener diodes or resistors. The output voltage can be adjusted by simply changing the turns ratio of the transformer.The CHRG/IADJ pin gives full control of the part to the user. Driving CHRG/IADJ low puts the part in low power shutdown. The CHRG/IADJ pin can also be used to reduce the input current of the charger, useful in extending battery life. The DONE pin indicates when the part has completed charging.The LT3585 series of parts are housed in tiny 3mm ? 2mm DFN packages.Applications Digital/Film Camera Flash PDA/Cell Phone Flash Emergency Strobe
