The AD9528 is a two-stage PLL with an integrated JESD204B SYSREF generator for multiple device synchronization. The first stage phase-locked loop (PLL) (PLL1) provides input reference conditioning by reducing the jitter present on a system clock. The second stage PLL (PLL2) provides high frequency clocks that achieve low integrated jitter as well as low broadband noise from the clock output drivers. The external VCXO provides the low noise reference required by PLL2 to achieve the restrictive phase noise and jitter requirements necessary to achieve acceptable performance. The on-chip VCO tunes from 3.450 GHz to 4.025 GHz. The integrated SYSREF generator outputs single shot, N-shot, or continuous signals synchronous to the PLL1 and PLL2 outputs to time align multiple devices.The AD9528 generates six outputs (Output 0 to Output 3, Output 12, and Output 13) with a maximum frequency of 1.25 GHz, and eight outputs with a maximum frequency of up to 1 GHz. Each output can be configured to output directly from PLL1, PLL2, or the internal SYSREF generator. Each of the 14 output channels contains a divider with coarse digital phase adjustment and an analog fine phase delay block that allows complete flexibility in timing alignment across all 14 outputs. The AD9528 can also be used as a dual input flexible buffer to distribute 14 device clock and/or SYSREF signals. At power-up, the AD9528 sends the VCXO signal directly to Output 12 and Output 13 to serve as the power-up ready clocks.Note that, throughout this data sheet, the dual function pin names are referenced by the relevant function where applicable.Applications High performance wireless transceivers LTE and multicarrier GSM base stations Wireless and broadband infrastructure Medical instrumentation Clocking high speed ADCs, DACs, DDSs, DDCs, DUCs, MxFEs; supports JESD204B Low jitter, low phase noise clock distribution ATE and high performance instrumentation

The AD9547 provides synchronization for many systems, including synchronous optical networks (SONET/SDH). The AD9547 generates an output clock that is synchronized to one of two differential or four single-ended external input references. The digital PLL allows for reduction of input time jitter or phase noise associated with the external references. The AD9547 con-tinuously generates a clean (low jitter), valid output clock, even when all references fail, by means of digitally controlled loop and holdover circuitry.The AD9547 operates over an industrial temperature range of ?40?C to +85?C.ApplicationsNetwork synchronizationCleanup of reference clock jitterSONET/SDH clocks up to OC-192, including FECStratum 2 holdover, jitter cleanup, and phase transient controlStratum 3E and Stratum 3 reference clocksWireless base stations, controllersCable infrastructureData communications

The AD9554-1 is a low loop bandwidth clock translator that provides jitter cleanup and synchronization for many systems,including synchronous optical networks (SONET/SDH). The AD9554-1 generates an output clock synchronized to up to four external input references. The digital PLLs (DPLLs) allowreduction of input time jitter or phase noise associated with the external references. The digitally controlled loop and holdovercircuitry of the AD9554-1 continuously generates a low jitteroutput clock even when all reference inputs have failed.The AD9554-1 operates over an industrial temperature range of ?40?C to +85?C. The AD9554 is a version of this device with two outputs per PLL. If a single or dual DPLL version of thisdevice is needed, refer to the AD9557 or AD9559, respectively.Applications Network synchronization, including synchronous Ethernet and synchronous digital hierarchy (SDH) to optical transport network (OTN) mapping/demapping Cleanup of reference clock jitter SONET/SDH clocks up to OC-192, including FEC Stratum 3 holdover, jitter cleanup, and phase transient control Cable infrastructure? Data communications? Professional video

LMR16010 Wide Vin Step-Down Converter Evaluation Module

5A Evaluation Module

CYW920706WCDEVAL board features WICED Bluetooth CYW20706 device

TPS2046BEVM Evaluation Module

Evaluation Module for TPS51916 DDR2; DDR3 & DDR3L Memory Power Solution Synchronous Buck Controller

TSW38J84 Evaluation Module

XDS560™ software v2 system trace USB debug probe
