| Price | |||||||||||
| RoHS | Y | Y | Y | Y | Y | Y | Y | ||||
| Lead Status | Y | Y | Y | Y | Y | Y | Y | ||||
| Battery overvoltage protection(max)(V) | 4.55 | 4.6 | 4.6 | ||||||||
| Battery overvoltage protection(min)(V) | 4.55 | 3.85 | 3.85 | ||||||||
| Features | Overvoltage,Single pin output drive | LDO output,Overvoltage,Single pin output drive,Undervoltage | BAT temp thermistor monitoring (JEITA profile),IC thermal regulation,IINDPM (Input current limit),Input OVP,Power Path,VINDPM (Input voltage threshold to maximize adaptor power) | LDO output,Overvoltage,Single pin output drive,Undervoltage | Adjustable switching frequency,BAT temp thermistor monitoring (JEITA profile),Bidirectional,IC thermal regulation,ICO (Input Current Optimization),IINDPM (Input current limit),Input OVP,Integrated ADC,Integrated LDO,SYNC Pin,Solar input/MPPT,USB C/PD compatible,VINDPM (Input voltage threshold to maximize adaptor power) | BAT temp thermistor monitoring (JEITA profile),IC thermal regulation,Input OVP,Integrated LDO,Integrated buck converter,Power Path,VINDPM (Input voltage threshold to maximize adaptor power) | BAT temp thermistor monitoring (JEITA profile),IC thermal regulation,VINDPM (Input voltage threshold to maximize adaptor power) | ||||
| Function | Protection | Protection | Protection | ||||||||
| Number of series cells(max) | 3 | 3,4 | 3,4 | ||||||||
| Number of series cells(min) | 2,3 | 2,3,4 | 2,3,4 | ||||||||
| Operating current(typ)(A) | 1 | 1 | 1 | ||||||||
| Operating temperature range(C) | -40 | -40 | -40 | -40 | -40 | -40 | -40 | ||||
| Overvoltage protection | 4.55 | 4.55 | 4.35 | ||||||||
| Package area(mm^2) | 4 | 4 | 16 | 4 | 30 | 6.75999999999999792000000000000016 | 4 | ||||
| Package size (L x W)(mm) | 2 x 2 | 2 x 2 | 4 x 4 | 2 x 2 | 6 x 5 | 2.5999999999999996 x 2.5999999999999996 | 2 x 2 | ||||
| Package type | WSON | WSON | WQFN | WSON | VQFN | DSBGA | WSON | ||||
| Pin count | 6 | 8 | 24.0 | 8.0 | 36 | 25 | 8 | ||||
| Rating | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | ||||
| TI functional safety category | |||||||||||
| Vin(max)(V) | 25 | 20 | 13.5 | 20 | 60 | 5.5 | 25 | ||||
| TI.com inventory | 1040400 | 70436 | 54480 | 125500 | 14405 | 34686 | 500 | ||||
| Approx. price(US$) | .18 | 1ku | .091 | 1ku | .9 | 1ku | .333 | 1ku | 2.69 | 1ku | 1.47 | 1ku | .39 | 1ku | ||||
| Absolute max Vin(max)(V) | 22 | 60 | 20 | 30 | |||||||
| Battery charge voltage(max)(V) | 4.52 | 36 | 4.65 | 4.4 | |||||||
| Battery charge voltage(min)(V) | 3.5 | 0 | 3.6 | 3.5 | |||||||
| Cell chemistry | Li-Ion/Li-Polymer,Lithium Phosphate/LiFePO4 | Li-Ion/Li-Polymer,Lithium Phosphate/LiFePO4,NiMH,SuperCap | Li-Ion/Li-Polymer,Lithium Phosphate/LiFePO4 | Li-Ion/Li-Polymer,Lithium Phosphate/LiFePO4 | |||||||
| Charge current(max)(A) | 1.5 | 20 | 0.3 | 0.8 | |||||||
| Control interface | I2C | I2C | I2C | Standalone (RC-Settable) | |||||||
| Control topology | Switch-Mode Buck | Switch-Mode Buck-boost | Linear | Linear | |||||||
| Number of series cells | 1 | 1,2,3,4,5,6,7 | 1 | 1 | |||||||
| Vin(min)(V) | 3.9 | 0 | 3.4 | 3 |
