| Price | $0.86 | $1.02 | $6.08 | ||||||||
| RoHS | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | Yes | Compliant | Compliant | |
| Lead Status | No | No | No | No | No | No | No | Yes | No | No | |
| Iq(Typ)(mA) | 0.018 | 0.018 | 0.23 | 0.03 | 9 | 1.35 | |||||
| Iout(Max)(A) | 1.2 | 1.2 | 3 | 15 | |||||||
| Duty Cycle(Max)(%) | 100 | 100 | 100 | 80 | 50 | ||||||
| Operating Temperature Range(C) | -40 to 85 | -40 to 85 | -40 to 85 | -40 to 105,-40 to 85 | -40 to 105 | -40 to 105 | -40 to 105 | -40 to 85 | -40 to 125 | ||
| Rating | Catalog | Catalog | Catalog | Automotive | Catalog | Catalog | Catalog | Catalog | Catalog | ||
| Package Group | MSOP-PowerPAD,VSON | MSOP-PowerPAD,VSON | VQFN-HR | WSON | WSON | WSON | WSON | HTSSOP | VQFN-CLIP | ||
| Switching Frequency(Max)(kHz) | 1500 | 1500 | 2200 | 3500 | 700 | 1000 | |||||
| Vout(Max)(V) | 1.5 | 3.3 | 20 | 5 | 1.2 | 5.5 | |||||
| Vin(Max)(V) | 6 | 6 | 20 | 5.5 | 5.5 | 5.5 | 5.5 | 20 | 20 | ||
| Type | Converter | Converter | Converter | Converter | Converter | Converter | |||||
| Control Mode | Voltage Mode | Voltage Mode | Voltage Mode | D-CAP3 | |||||||
| Vout(Min)(V) | 1.5 | 3.3 | 5 | 1.2 | 0.6 | ||||||
| Special Features | Enable,Light Load Efficiency,Power Good,Synchronous Rectification | Enable,Light Load Efficiency,Power Good,Synchronous Rectification | Adjustable Current Limit,Enable,Frequency Synchronization,Load Disconnect,Synchronous Rectification | Enable,Light Load Efficiency,Load Disconnect | Adjustable Rise Time,Power Good,Quick Output Discharge,Vbias | Adjustable Rise Time,Power Good,Vbias | Adjustable Rise Time,Power Good,Vbias | Enable,Phase Interleaving,Power Good,Synchronous Rectification | Adjustable Current Limit,Dynamic Voltage Scaling,Enable,Light Load Efficiency,Power Good,Pre-Bias Start-Up,Synchronous Rectification,UVLO Adjustable,Voltage Margining | ||
| Approx. Price (US$) | 1.05 | 1ku | 1.05 | 1ku | 0.64 | 1ku | 0.49 | 1ku | 0.49 | 1ku | 0.49 | 1ku | 1.40 | 1ku | 3.18 | 1ku | |||
| Switching Frequency(Min)(kHz) | 1000 | 1000 | 200 | 3500 | 250 | 250 | |||||
| Vin(Min)(V) | 2.5 | 2.5 | 2.7 | 2.3 | 0.6 | 0.6 | 0.6 | 4.5 | 4.5 | ||
| Switch Current Limit(Typ)(A) | 7.2 | 0.6 | |||||||||
| Regulated Outputs(#) | 1 | 1 | 1 | 1 | |||||||
| Switch Current Limit(Min)(A) | 0.5 | ||||||||||
| Package Size | mm2 | mm2 | mm2 | ||||||||
| Output Rise Time @ 1.8V(Typ)(us) | Adjustable | Adjustable | Adjustable | ||||||||
| Ron @1.8V(Typ)(mOhm) | 3.9 | 3.9 | 3.9 | ||||||||
| Imax(A) | 10 | 10 | 10 | ||||||||
| Quiescent Current (Iq)(Typ)(uA) | 55 | 55 | 55 | ||||||||
| HBM ESD(kV) | 2 | 2 | 2 | ||||||||
| Shutdown Current (ISD)(Typ)(uA) | 5 | 5 | 5 | ||||||||
| Ron(Typ)(mOhm) | 3.9 | 3.9 | 3.9 | ||||||||
| Number of Channels(#) | 1 | 1 | 1 | ||||||||
| Ron @4.5V(Typ)(mOhm) | 3.9 | 3.9 | 3.9 | ||||||||
| Rise Time(Typ)(us) | Adjustable | Adjustable | Adjustable |
