Texas Instruments PGA970EVM

SN65HVD251DG4

Texas Instruments SN65HVD251DG4

SN75LVDS84DGGG4

Texas Instruments SN75LVDS84DGGG4

TPS7A2601DRVT

Texas Instruments TPS7A2601DRVT

AFE7681IABJ

Texas Instruments AFE7681IABJ

MSP430FR2353TRSMR

Texas Instruments MSP430FR2353TRSMR

UCC21750DW

Texas Instruments UCC21750DW

V62/18615-01XE

Texas Instruments V62/18615-01XE

ADS52J65IRGCT

Texas Instruments ADS52J65IRGCT

INA253A1IPWR

Texas Instruments INA253A1IPWR

Price
RoHS Compliant Compliant Y Y Y See ti.com Y Compliant Y
Lead Status No No Y See ti.com See ti.com See ti.com See ti.com See ti.com Y
Package size mm2 mm2 mm2 mm2 mm2 mm2 mm2
Iout(Max)(A) 0.5
Vout(Min)(V) 1.24
Features Enable,Power Good,Soft Start DAC,OpAmp,PGA,Real-Time Clock Bi-directional,Enhanced PWM Rejection,Low-side Capable High Performance Bi-directional,Enhanced PWM Rejection,Integrated Shunt,Low-side Capable
Output options Adjustable Output
Rating Catalog Catalog Catalog Catalog Space Catalog Catalog
Fixed output options(V) 1.8,3.3,5
PSRR @ 100 KHz(dB) 22
Accuracy(%) 1
Iq(Typ)(mA) 0.0025
Vin(Max)(V) 18
Regulated outputs(#) 1
Noise(uVrms) 200
Dropout voltage (Vdo)(Typ)(mV) 330
Vin(Min)(V) 2.4
Approx. price(US$) 0.49 | 1ku 1.55 | 1ku 3.48 | 1ku 1.49 | 1ku
Vout(Max)(V) 17.45
Operating temperature range(C) -40 to 125 -40 to 85 -40 to 105 -40 to 125 -55 to 125 -40 to 85 -40 to 125
Package Group WSON|6 FCBGA|400 LQFP|48,TSSOP|38,VQFN|32,VQFN|40 SOIC|16 TSSOP|8 VQFN|64 TSSOP|20
Thermal resistance JA(C/W) 73
# of DUCs/TX 1
Data rate(MSPS) 750
# of DDCs/RX 1
# of TX/RX 4T2R
Application Wireless infrastructure
I2C 2
ADC 12-bit SAR
RAM(KB) 2
Timers - 16-bit 4
Bootloader (BSL) UART
Non-volatile memory (kB) 16
GPIO pins(#) 44
Comparator channels (#) 2
SPI 4
USB No
UART 2
DIN V VDE V 0884-10 transient overvoltage rating(Vpk) 8400
Output VCC/VDD(Max)(V) 33
Input VCC(Min)(V) 3
Number of channels(#) 1 1 1
Power switch IGBT SiCFET
Prop delay(ns) 90
DIN V VDE V 0884-10 working voltage(Vpk) 2121
Isolation rating(Vrms) 5700
Input VCC(Max)(V) 5.5
Output VCC/VDD(Min)(V) 13
Peak output current(A) 10
CMRR(Min)(dB) 120 120
Gain error(%) 0.2 0.4
Bandwidth(kHz) 400 350
Common mode voltage(Max)(V) 80 80
Input offset (+/-)(Max)(uV) 25 12.5mA
Gain(V/V) 20 100mV/A,200mV/A,400mV/A
Product type Analog Output Analog Output w/Integrated Shunt Resistor
Input offset drift (+/-)(Typ)(uV/C) 0.05 125uA/C
Comparators(#) 0 0
Iq(Max)(mA) 2.6 2.6
Supply voltage(Min)(V) 2.7 2.7
Common mode voltage(Min)(V) -4 -4
Gain error drift (+/-)(Max)(ppm/C) 10 45
Supply voltage(Max)(V) 5.5 5.5
Reference mode Ext,Int
Number of input channels 8
Resolution(Bits) 16
SNR(dB) 78
Input range(Vp-p) 2
Interface JESD204B,Serial LVDS
Input buffer Yes
SFDR(dB) -85
Architecture Pipeline
Analog input BW(MHz) 130
Power consumption(Typ)(mW) 70
