| Price | $5.65 | $6.17 | $5.11 | $6.08 | |||||||
| RoHS | Compliant | Y | Y | Y | Compliant | Compliant | Compliant | Compliant | Compliant | Y | |
| Lead Status | No | Y | Y | See ti.com | No | No | No | No | No | Y | |
| Iq(Typ)(mA) | 8 | 8 | 7.7 | 1.35 | 7.7 | 7.7 | |||||
| Control Mode | D-CAP,D-CAP2 | D-CAP,D-CAP2 | Voltage Mode | D-CAP3 | Voltage Mode | Voltage Mode | |||||
| Switching Frequency(Min)(kHz) | 250 | 250 | 200 | 250 | 200 | 200 | |||||
| Special Features | Adjustable Current Limit,Dynamic Voltage Scaling,Enable,PMBus,Power Good,Pre-Bias Start-Up,Remote Sense,Synchronous Rectification,UVLO Adjustable,Voltage Margining | Adjustable Current Limit,Dynamic Voltage Scaling,Enable,PMBus,Power Good,Pre-Bias Start-Up,Remote Sense,Synchronous Rectification,UVLO Adjustable,Voltage Margining | Adjustable Current Limit,Dynamic Voltage Scaling,Frequency Synchronization,PMBus,Phase Interleaving,Power Good,Remote Sense,Synchronous Rectification,Tracking,UVLO Adjustable,Voltage Margining | Adjustable Current Limit,Dynamic Voltage Scaling,Enable,Light Load Efficiency,Power Good,Pre-Bias Start-Up,Synchronous Rectification,UVLO Adjustable,Voltage Margining | Adjustable Current Limit,Dynamic Voltage Scaling,Frequency Synchronization,PMBus,Phase Interleaving,Power Good,Remote Sense,Synchronous Rectification,Tracking,UVLO Adjustable,Voltage Margining | Adjustable Current Limit,Dynamic Voltage Scaling,Frequency Synchronization,PMBus,Phase Interleaving,Power Good,Remote Sense,Synchronous Rectification,Tracking,UVLO Adjustable,Voltage Margining | |||||
| Vin(Min)(V) | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | 4.5 | |||||
| Operating Temperature Range(C) | -40 to 85 | -40 to 85 | -40 to 125 | -40 to 125 | -40 to 125 | -40 to 125 | |||||
| Rating | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | Catalog | |
| Vout(Max)(V) | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | |||||
| Switching Frequency(Max)(kHz) | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | |||||
| Type | Converter | Converter | Converter | Converter | Converter | Converter | Converter | Converter | Converter | ||
| Regulated Outputs(#) | 1 | 1 | 1 | 1 | 1 | 1 | |||||
| Duty Cycle(Max)(%) | 80 | 80 | 100 | 50 | 100 | 100 | |||||
| Package Group | LQFN-CLIP | LQFN-CLIP | LQFN-CLIP | VQFN-CLIP | LQFN-CLIP | LQFN-CLIP | |||||
| Iout(Max)(A) | 20 | 20 | 35 | 15 | 35 | 35 | |||||
| Vin(Max)(V) | 18 | 18 | 18 | 20 | 18 | 18 | |||||
| Approx. Price (US$) | 3.40 | 1ku | 3.40 | 1ku | 4.62 | 1ku | 3.18 | 1ku | 4.62 | 1ku | 4.62 | 1ku | |||||
| Vout(Min)(V) | 0.6 | 0.6 | 0.35 | 0.6 | 0.35 | 0.35 | |||||
| Control mode | ACM/AECM | ACM/AECM | D-CAP+ | ACM/AECM | |||||||
| Maximum package height(mm) | 0.7 | 0.7 | 0.7 | 1 | |||||||
| Operating temperature range(C) | -40 | -40 | -40 | -40 | |||||||
| Package area(mm^2) | 11.25 | 11.25 | 30 | 7.5 | |||||||
| Package size (L x W)(mm) | 4.5 x 2.5 | 4.5 x 2.5 | 6 x 5 | 2.5 x 3 | |||||||
| Package type | WQFN-FCRLF | WQFN-FCRLF | WQFN-FCRLF | VQFN-HR | |||||||
| Pin count | 17 | 17 | 37 | 14 | |||||||
| TI functional safety category | |||||||||||
| TI.com inventory | 1022 | 491 | 10546 | 117242 | |||||||
| Approx. price(US$) | 3.08 | 1ku | 2.02 | 1ku | 2.25 | 1ku | .75 | 1ku | |||||||
| Duty cycle(max)(%) | 94 | 76 | 94 | ||||||||
| Features | Adjustable current limit,Differential Remote Sense,Enable,Forced PWM,Frequency synchronization,Over Current Protection,Power good,Pre-Bias Start-Up,Soft Start Adjustable,Synchronous Rectification,UVLO adjustable | Adaptive/Dynamic Voltage Scaling,Adjustable current limit,Differential Remote Sense,Enable,Forced PWM,I2C,Light Load Efficiency,Over Current Protection,Power good,Pre-Bias Start-Up,SVID,Soft Start Adjustable,Synchronous Rectification,Telemetry,UVLO adjustable,VID Interface | Adjustable current limit,Enable,Forced PWM,Frequency synchronization,Over Current Protection,Power good,Pre-Bias Start-Up,Soft Start Adjustable,Synchronous Rectification,UVLO adjustable | ||||||||
| Iout(max)(A) | 12 | 35 | 3 | ||||||||
| Iq(typ)(mA) | 1.2 | 5 | 1.2 | ||||||||
| Regulated outputs(#) | 1 | 1 | 1 | ||||||||
| Switching frequency(max)(kHz) | 2200 | 1200 | 2200 | ||||||||
| Switching frequency(min)(kHz) | 500 | 600 | 500 | ||||||||
| Vin(max)(V) | 18 | 16 | 18 | ||||||||
| Vin(min)(V) | 4 | 4 | 4 | ||||||||
| Vout(max)(V) | 7 | 3.04 | 7 | ||||||||
| Vout(min)(V) | 0.5 | 0.5 | 0.5 | ||||||||
| EMI features | Low parasitic Hotrod packaging |
