The Maxim ICL7136 is a monolithic analog to digital converter with very high input impedance. On-board active components include segment drivers, segment decoders, voltage reference and a clock circuit. The ICL7136 directly drives a non-multiplexed liquid crystal (LCD) display, requiring no external display drive circuitry. Significantly reduced power consumption makes the ICL7136 a superior device, especially for portable systems.Versatility and accuracy are inherent features of this converter. The dual-slope conversion technique automatically rejects interference signals common in industrial environments. The true differential input and reference are particularly useful when making ratiometric measurements (ohms or bridge transducers), and the zero-integrator phase in Maxim's ICL7136 eliminates overrange hangover and hysteresis effects. Finally, this device offers high accuracy by lowering rollover error to less than one count and zero reading drift to less than 1μV/°C.ApplicationsConductanceCurrentMaterial ThicknessPressureResistanceSpeedTemperatureVoltage

The Maxim ICL7137 is a monolithic analog to digital converter with all the necessary active devices to directly interface with a light emitting diode (LED) display. Excluding the LED display current, the ICL7137 supply current is under 200μA, making it suitable for battery operation.Versatility and accuracy are inherent features of this converter. The dual-slope conversion technique automatically rejects interference signals common in industrial environments. The true differential input and reference are particularly useful when making ratiometric measurements (ohms or bridge transducers), and the zero integrator phase in Maxim's ICL7137 eliminates overrange hangover and hysteresis effects. Finally, this device offers high accuracy by lowering rollover error to less than one count and zero reading drift to less than 1μV/°C.ApplicationsConductanceCurrentMaterial ThicknessPressureResistanceSpeedTemperatureVoltage

The Maxim ICL7137 is a monolithic analog to digital converter with all the necessary active devices to directly interface with a light emitting diode (LED) display. Excluding the LED display current, the ICL7137 supply current is under 200μA, making it suitable for battery operation.Versatility and accuracy are inherent features of this converter. The dual-slope conversion technique automatically rejects interference signals common in industrial environments. The true differential input and reference are particularly useful when making ratiometric measurements (ohms or bridge transducers), and the zero integrator phase in Maxim's ICL7137 eliminates overrange hangover and hysteresis effects. Finally, this device offers high accuracy by lowering rollover error to less than one count and zero reading drift to less than 1μV/°C.ApplicationsConductanceCurrentMaterial ThicknessPressureResistanceSpeedTemperatureVoltage

The Maxim ICM7555 and ICM7556 are respectively singleand dual general-purpose RC timers capable of generatingaccurate time delays or frequencies. The primaryfeature is an extremely low supply current, making thisdevice ideal for battery-powered systems. Additional featuresinclude low THRESHOLD, active-low TRIGGER, and active-low RESETcurrents, a wide operating supply voltage range, andimproved performance at high frequencies.These CMOS low-power devices offer significant performanceadvantages over the standard 555 and 556 bipolartimers. Low-power consumption, combined with the virtuallynonexistent current spike during output transitions, makethese timers the optimal solution in many applications.ApplicationsMissing Pulse DetectorPrecision TimingPulse GeneratorPulse Position ModulationPulse-Width ModulationSequential TimingTime Delay Generation

The Maxim ICM7555 and ICM7556 are respectively singleand dual general-purpose RC timers capable of generatingaccurate time delays or frequencies. The primaryfeature is an extremely low supply current, making thisdevice ideal for battery-powered systems. Additional featuresinclude low THRESHOLD, active-low TRIGGER, and active-low RESETcurrents, a wide operating supply voltage range, andimproved performance at high frequencies.These CMOS low-power devices offer significant performanceadvantages over the standard 555 and 556 bipolartimers. Low-power consumption, combined with the virtuallynonexistent current spike during output transitions, makethese timers the optimal solution in many applications.ApplicationsMissing Pulse DetectorPrecision TimingPulse GeneratorPulse Position ModulationPulse-Width ModulationSequential TimingTime Delay Generation

The Maxim ICL7129A/MAX7129 is a high precision monolithic 4-1/2 digit A/D converter that directly drives a multiplexed liquid crystal display. Using a novel 'successive integration' technique, the ICL7129A/MAX7129 has a ±20,000 count resolution on both 2.00000V and 200.00mV ranges. It features high impedance differential inputs, excellent differential linearity, true ratiometric operation and auto polarity. The only external active component required to make precision DVM/DPMs is a reference. The overrange and underrange outputs and the 10:1 range changing input facilitate the design of autoranging systems. The ICL7129A/MAX7129 detects and flags a LOW BATTERY condition and also checks for continuity, giving a visual indication and a logic level output which can be used to generate an audible signal.The MAX7129 has a fullscale accuracy of 0.0005%, resolution of 10µV, zero reading drift of 0.5µV/°C, an input bias of 10pA max, and a rollover error of less than 1 count. Maxim has reduced the noise of the ICL7129A to 3µV—significantly lower than the MAX7129.

The Maxim ICL7126 is a monolithic analog to digital converter with very high input impedance. On-board active components include segment drivers, segment decoders, voltage reference and a clock circuit. The ICL7126 directly drives a non-multiplexed liquid crystal (LCD) display, requiring no external display drive circuitry. Significantly reduced power consumption makes the ICL7126 a superior device, especially for portable systems.Versatility and accuracy are inherent features of this converter. The dual-slope conversion technique automatically rejects interference signals common in industrial environments. The true differential input and reference are particularly useful when making ratiometric measurements (ohms or bridge transducers), and the zero-integrator phase in Maxim's ICL7126 eliminates overrange hangover and hysteresis effects. The Zero Integrator phase also allows the use of larger auto zero capacitors reducing noise further. Finally, this device offers high accuracy by lowering rollover error to less than one count and zero reading drift to less than 1μV/°C.ApplicationsConductanceCurrentMaterial ThicknessPressureResistanceSpeedTemperatureVoltage
