Analog Devices Inc.

Category: Integrated Circuits (ICs)

DeepCover™ embedded security solutions cloak sensitive data under multiple layers of advanced physical security to provide the most secure key storage possible. The DeepCover Secure Authenticator (DS28E25) combines crypto-strong, bidirectional, secure challengeand-response authentication functionality with an implementation based on the FIPS 180-3-specified SecureHash Algorithm (SHA-256). A 4Kb user-programmable EEPROM array provides nonvolatile storage of application data and additional protected memory holds a readprotectedsecret for SHA-256 operations and settings for user memory control. Each device has its own guaranteedunique 64-bit ROM identification number (ROM ID) that is factory programmed into the chip. This unique ROM ID is used as a fundamental input parameter for cryptographic operations and also serves as an electronic serial number within the application. A bidirectional security model enables two-way authentication between a host system and slave-embedded DS28E25. Slave-to-host authentication is used by a host system to securely validate that an attached or embedded DS28E25 is authentic. Hostto-slave authentication is used to protect DS28E25 user memory from being modified by a nonauthentic host. The SHA-256 message authentication code (MAC), which the DS28E25 generates, is computed from data in the user memory, an on-chip secret, a host random challenge, and the 64-bit ROM ID. The DS28E25 communicates over the single-contact 1-Wire® bus at overdrive speed. The communication follows the 1-Wire protocol with the ROM ID acting as node address in the case of a multiple-device 1-Wire network.Our Secure Drug Delivery video shows how Maxim security products can be used to authenticate remote drug delivery.ApplicationsAuthentication of Network-Attached AppliancesKey Generation and Exchange for Cryptographic SystemsPrinter Cartridge ID/AuthenticationReference Design License ManagementSecure Feature Setting for Configurable SystemsSensor/Accessory Authentication and CalibrationSystem Intellectual Property Protection

* $1.85
