Analog Devices Inc.

Category: Amplifiers and Comparators

720MHz, 3.5mA Power Efficient Rail-to-Rail I/O Op Amps Features: Gain Bandwidth Product: 720MHz –3dB Frequency (AV = 1): 400MHz Low Quiescent Current: 3.5mA Max High Slew Rate: 280V/μs Input Common Mode Range Includes Both Rails Output Swings Rail-to-Rail Low Broadband Voltage Noise: 2.75nV/√Hz Power-Down Mode: 42μA Fast Output Recovery Supply Voltage Range: 2.5V to 5.25V Input Offset Voltage: 350μV Max Large Output Current: 90mA CMRR: 105dB Open Loop Gain: 60V/mV Operating Temperature Range: –40°C to 125°C Single in 6-Pin TSOT-23 Dual in MS8, 2mm × 2mm DFN, 8-Pin TS0T-23, MS10 Quad in MS16

* $2.89 - $5.90
