Analog Devices Inc.

Category: Amplifiers and Comparators

Dual 30MHz, 240A Power Efficient Rail-to-Rail I/O Op Amps Features:Gain Bandwidth Product: 30MHzLow Quiescent Current: 240μAOp Amp Drives up to 1nF Capacitive LoadsOffset Voltage: 400μV MaximumRail-to-Rail Input and OutputSupply Voltage Range: 1.8V to 5.25VInput Bias Current: 100nA MaximumCMRR/PSRR: 100dB/95dBShutdown Current: 10μA MaximumOperating Temperature Range: –40°C to 125°CSingle in 6-Lead TSOT-23, 2mm × 2mm DFN PackagesDual in 8-Lead MS8, MS10, TS0T-23, 2mm × 2mm DFN PackagesQuad in MS16 Package

$2.58
