Analog Devices Inc.

Category: Integrated Circuits (ICs)

The MAX22288 Home Bus System (HBS) compatibletransceiver can be used in the Home Bus System, wheredata and power are passed on a single pair of wireswhile minimizing the need for external components.The MAX22288 provides robust communication byusing dynamic cable termination that improves thesignal quality with longer cables and higher data rates.The device data outputs AIO/BIO do not load the buswhen the MAX22288 is not powered. The MAX22288supports passing data with speed up to 200kbps.The MAX22288 features adjustable receiver thresholdsand driver slew rates that allow the MAX22288 to beused in a wide variety of systems. Integrated protectionensures robust communication in harsh industrialenvironments.The MAX22288 is pin-to-pin compatible with theMAX22088, the Home Bus System (HBS) CompatibleTransceiver with Active Inductor. The MAX22288 isrecommended for use in an HBS system where anexternal power supply is typically available.The MAX22288 is specified for operation over the -40°Cto +125° C temperature range and is available in acompact 24-pin 4mm x 4mm TQFN package.ApplicationsHVACBuilding ControllersIndustrial IoT

* $3.98 - $3.79
