MAX2680EUT+T

Analog Devices Inc.

Category: Integrated Circuits (ICs)

The MAX2680/MAX2681/MAX2682 miniature, low-cost, low-noise downconverter mixers are designed for low-voltage operation and are ideal for use in portable communications equipment. Signals at the RF input port are mixed with signals at the local oscillator (LO) port using a double-balanced mixer. These downconverter mixers operate with RF input frequencies between 400MHz and 2500MHz, and downconvert to IF output frequencies between 10MHz and 500MHz.The MAX2680/MAX2681/MAX2682 operate from a single +2.7V to +5.5V supply, allowing them to be powered directly from a 3-cell NiCd or a 1-cell Lithium battery. These devices offer a wide range of supply currents and input intercept (IIP3) levels to optimize system performance. Additionally, each device features a low-power shutdown mode in which it typically draws less than 0.1µA of supply current. Consult the Selector Guide for various combinations of IIP3 and supply current.The MAX2680/MAX2681/MAX2682 are manufactured on a high-frequency, low-noise, advanced silicon-germanium process and are offered in the space-saving 6-pin SOT23 package.Applications400MHz/900MHz/2.4GHz ISM-Band RadiosCell Phones/Cordless PhonesIEEE 802.11 and Wireless DataPersonal Communications Systems (PCS)Wireless Local Loop (WLL)

* $2.26 - * $2.09
Distributor SKU Stock MOQ 1 10 50 100 1000 10000 Purchase
element14 APAC MAX2680EUT+T 1893 100 * $2.09 * $1.75 * $1.71 Buy
Farnell MAX2680EUT+T 1893 100 * $2.08 * $1.92 * $1.92 Buy
Mouser Electronics 700-MAX2680EUTT 2286 1 $2.65 $2.14 $2.14 $1.95 $1.37 $1.29 Buy

Technical Specifications

ROHS Compliance Compliant
