Analog Devices Inc.

Category: Amplifiers and Comparators

The MAX40108 is a low-power, high-precision operational amplifier (op amp) that operates with a power supply voltage as low as 0.9V.Available in a space-saving, 1.22mmx 0.92mm, 6-bump wafer-level package (WLP) with a 0.4mm bump pitch, it is designed for use in portable, consumer, medical, and industrial applications.The MAX40108 features rail-to-rail CMOS inputs and outputs, a 168kHz GBW consuming only 25.5µA (typ) supply current and 1µV (typ) zero-drift input offset voltage over time and temperature. The zero-drift feature reduces the high 1/f noise typically found in CMOS input operational amplifiers, making it useful for a wide variety of low-frequency measurement applications.The MAX40108 operates from a 0.9V to 3.6V power supply voltage and is specified over the -40°C to +125°C extended operating temperature range.ApplicationsFitness and Health (Smart Watch, Heart-Rate Monitor)Home Medical (Blood Glucose,Weight Scale, Blood Pressure, EKG)Industrial IOT (Pressure, Flow, Level, Temperature, Proximity)Wearable Devices

* $2.06 - * $2.01
