Analog Devices Inc.

Category: Amplifiers and Comparators

The MAX44259/MAX44260/MAX44261/MAX44263 offer aunique combination of high speed, precision, low noise,and low-voltage operation making them ideally suitedfor a large number of signal processing functions suchas filtering and amplification of signals in portable andindustrial equipment.The devices’ rail-to-rail input/outputs and low noise guarantee maximumdynamic range in demanding applications such as 12- to14-bit SAR ADC drivers. Unlike traditional rail-to-rail inputstructures, input crossover distortion is absent due to anoptimized input stage with an ultra-quiet charge pump.The MAX44260 includes a fast-power-on shutdown modefor further power savings. The MAX44261 offers a uniqueon-demand calibration pin where the user can invokeself-trimming of the input offset voltage. The MAX44263is a dual amplifier.The family of parts operates from a supply range of 1.8Vto 5.5V over the -40°C to +125°C temperature rangeand can operate down to 1.7V over the 0°C to +70°Ctemperature range. The MAX44259 is offered in a 5-pinSOT23 package. The MAX44260/MAX44261 are availablein small, 6-pin SC70 packages. The MAX44260 isalso available in a 1mm x 1.5mm thin µDFN (ultra-thinLGA)package. The MAX44263 is available in a small8-pin SC70 package.Design Solution: Amplifier Extends the Battery Life of Your Heart Rate Monitor ›Applications3G/4G HandsetsAnalog-to-Digital Converter BuffersBattery-Operated DevicesGeneral-Purpose Signal ProcessingNotebooksPortable Media PlayersPortable Medical InstrumentsTransimpedance Amplifiers

$0.00 - $3.45
