Analog Devices Inc.

Category: Amplifiers and Comparators

The MAX44284 is a high-side, current-sense amplifier that operates with a 1.7V to 5.5V single supply and is optimized for very low power operation with only 21µA of quiescent current.The MAX44284 offers precision accuracy specifications of 2µV VOS and gain error of 0.05%. The device features an input common-mode voltage range from -0.1V to +36V. This current-sense amplifier has a voltage output and is offered in four different gain versions.The MAX44284 is offered in small 6-bump, 0.4mm-pitch WLP (1.3mm x 0.9mm) and 6-pin SOT23 packages and is specified for operation over the -40°C to +125°C automotive temperature range.ApplicationsBase-StationsDC-DC Current Sensing in Power ManagementMedical Pulse Oximeters and Infusion PumpsNotebook ComputersPortable-/Battery-Powered SystemsSmartphones and Tablets

* $3.07
