Analog Devices Inc.

Category: Amplifiers and Comparators

The MAX9201/MAX9202/MAX9203 high-speed, lowpower,quad/dual/single comparators feature TTL logicoutputs with active internal pullups. Fast propagationdelay (7ns typ at 5mV overdrive) makes these devicesideal for fast A/D converters and sampling circuits, linereceivers, V/F converters, and many other data-discrimination,signal restoration applications.All comparators can be powered from separate analogand digital power supplies or from a single combinedsupply voltage. The analog input common-mode rangeincludes the negative rail, allowing ground sensingwhen powered from a single supply. The MAX9201/MAX9202/MAX9203 consume only 9mW per comparatorwhen powered from a +5V supply.The MAX9202/MAX9203 feature output latches with TTLcompatible inputs. The comparator output states areheld when the latch inputs are driven low. TheMAX9201 provides all the same features as theMAX9202/MAX9203 with the exception of the latches.The MAX9201/MAX9202/MAX9203 are lower power andlower cost upgrades to the MAX901/MAX902/MAX903offering a 50% power savings and smaller packaging.ApplicationsHigh-Speed A/D ConvertersHigh-Speed Data SamplingHigh-Speed Signal Squaring/RestorationHigh-Speed V/F ConvertersInput Trigger CircuitryLine ReceiversPWM CircuitsThreshold Detectors

* $6.77 - * $8.91
