MAX9617AXT+T
Analog Devices Inc.
Category: Amplifiers and Comparators
The MAX9617–MAX9620 are low-power, zero-drift operational amplifiers available in space-saving SC70 packages. They are designed for use in portable consumer, medical, and industrial applications.The MAX9617–MAX9620 feature rail-to-rail CMOS inputs and outputs, a 1.5MHz GBW at just 59µA supply current and 10µV (max) zero-drift input offset voltage over time and temperature. The zero-drift feature reduces the high 1/f noise typically found in CMOS input operational amplifiers, making it useful for a wide variety of low-frequency measurement applications.The MAX9617 and MAX9619 are available in a space-saving, 2mm x 2mm, 6-pin SC70 package. The MAX9619 features a power-saving shutdown mode. The MAX9618 is available in a 2mm x 2mm, 8-pin SC70 package. The MAX9620 is available in a 2mm x 2mm, 5-pin SC70 package. All devices are specified over the -40°C to +125°C automotive operating temperature range.ApplicationsBattery-Powered DevicesCardiac MonitorsLoop-Powered SystemsPortable Medical DevicesSensor Interfaces
* $2.42 - $4.92
Distributors
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
element14 APAC | MAX9617AXT+T | 2153 | 100 | * $2.46 | * $2.13 | * $2.08 | Buy | |||
|
 |
Farnell | MAX9617AXT+T | 2153 | 100 | * $2.42 | * $2.17 | * $2.17 | Buy | |||
|
 |
Mouser Electronics | 700-MAX9617AXTT | 1247 | 1 | $4.92 | $3.20 | $2.76 | $2.25 | $1.81 | $1.81 | Buy |
|
 |
Newark | MAX9617AXT+T | 5 | 1 | $3.67 | $2.80 | $2.47 | $2.35 | $2.35 | $2.35 | Buy |
Technical Specifications
| ROHS Compliance | Compliant |
