TAS2770YFFT
Texas Instruments
Category: Amplifiers and Comparators
Digital Input Mono Class-D Audio Amplifier with Speaker IV Sense 30-DSBGA -40 to 85
$1.56 - * $3.67
Distributors
Currency:
| Distributor | SKU | Stock | MOQ | 1 | 10 | 50 | 100 | 1000 | 10000 | Purchase | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 |
DigiKey | 296-47924-6-ND | 0 | 1 | $3.26 | $2.93 | $2.77 | $2.40 | $1.86 | $1.29 | Buy |
|
 |
Arrow North American Components | TAS2770YFFT | 0 | 250 | $1.18 | $1.18 | $1.18 | $1.18 | $1.39 | $2.70 | Buy |
|
|
AVNET Express | TAS2770YFFT | 250 | $1.51 | $1.45 | Buy | |||||
|
 |
element14 APAC | TAS2770YFFT | 132 | 1 | * $3.67 | * $3.31 | * $3.13 | * $3.06 | * $3.06 | * $3.06 | Buy |
|
 |
Farnell | TAS2770YFFT | 132 | 1 | * $3.44 | * $3.10 | * $2.74 | * $2.53 | * $2.53 | * $2.53 | Buy |
|
|
Mouser Electronics | 595-TAS2770YFFT | 120 | 1 | $3.10 | $2.72 | $2.72 | $2.28 | $2.17 | $2.17 | Buy |
|
|
Newark | TAS2770YFFT | 132 | 1 | $3.73 | $3.56 | $3.24 | $3.10 | $3.10 | $3.10 | Buy |
|
|
Texas Instruments | TAS2770YFFT | 668 | 1 | $2.60 | $2.60 | $2.60 | $2.15 | $1.16 | $1.16 | Buy |
|
|
Verical Marketplace | TAS2770YFFT | 4000 | 250 | $2.06 | $2.06 | $2.06 | $2.06 | $1.54 | $1.46 | Buy |
Parts in family
Technical Specifications
| Lead Free Status | No |
| ROHS Compliance | Compliant |
| Analog Supply (V)(Max) | 16 |
| Analog Supply (V)(Min) | 4.5 |
| Approx. Price (US$) | 1.49 | 1ku |
| Architecture | Smart Amp |
| Audio Input Type | Digital Input |
| Closed/Open Loop | Closed |
| Control Interface | I2C |
| Iq(Max)(mA) | 10 |
| Iq(Typ)(mA) | 7.07 |
| Load(Min)(ohms) | 4 |
| Operating Temperature Range(C) | -40 to 85 |
| Output Power(W) | 20 |
| PSRR(dB) | 90 |
| Power Stage Supply(Max)(V) | 16 |
| Power Stage Supply(Min)(V) | 4.5 |
| SNR(dB) | 108 |
| Speaker Channels(Max) | Mono |
| THD + N @ 1 kHz(%) | 0.007 |
