The ADCMP606 and ADCMP607 are very fast comparatorsfabricated on XFCB2, an Analog Devices, Inc., proprietaryprocess. These comparators are exceptionally versatile and easyto use. Features include an input range from VEE ? 0.5 V toVCCI + 0.2 V, low noise, CML-compatible output drivers, andTTL-/CMOS-compatible latch inputs with adjustable hysteresisand/or shutdown inputs.The devices offer 1.25 ns propagation delay with 2.5 ps rmsrandom jitter (RJ). Overdrive and slew rate dispersion aretypically less than 50 ps.A flexible power supply scheme allows the devices to operatewith a single +2.5 V positive supply and a ?0.5 V to +2.7 Vinput signal range up to a +5.5 V positive supply with a ?0.5 Vto +5.7 V input signal range. The ADCMP607 features splitinput/output supplies with no sequencing restrictions tosupport a wide input signal range with independent outputswing control and power savings.The CML-compatible output stage is fully back-matched forsuperior performance. The comparator input stage offers robustprotection against large input overdrive, and the outputs do notphase reverse when the valid input signal range is exceeded. Onthe ADCMP607, latch and programmable hysteresis features arealso provided with a unique single-pin control option.The ADCMP606 is available in a 6-lead SC70 package and theADCMP607 is available in a 12-lead LFCSP package.Applications High speed instrumentation Clock and data signal restoration Logic level shifting or translation Pulse spectroscopy High speed line receivers Threshold detection Peak and zero-crossing detectors High speed trigger circuitry Pulse-width modulators Current-/voltage-controlled oscillators Automatic test equipment (ATE)

The LT1970A is a ?500mA power op amp with precise externally controlled current limiting. Separate control voltages program the sourcing and sinking current limit sense thresholds with 1% accuracy. Output current may be boosted by adding external power transistors.The circuit operates with single or split power supplies from 5V to 36V total supply voltage. In normal operation, the input stage supplies and the output stage supplies are connected (VCC to V+ and VEE to V?). To reduce power dissipation it is possible to power the output stage (V+, V?) from independent, lower voltage rails. The amplifier is unity-gain stable with a 3.6MHz gain-bandwidth product and slews at 1.6V/?s. The LT1970A can drive capacitive and inductive loads directly.Open-collector status flags signal current limit circuit activation, as well as thermal shutdown of the amplifier. An enable logic input puts the amplifier into a low power, high impedance output state when pulled low. Thermal shutdown and a ?800mA fixed current limit protect the chip under fault conditions.The LT1970A is packaged in a 20-lead TSSOP package with a thermally conductive copper bottom plate to facilitate heat sinking.Applications Automatic Test Equipment Laboratory Power Supplies Motor Drivers Thermoelectric Cooler Driver

DC566A-A: Demo Board for the LTC6910 Digitally Controlled Programmable Gain Amplifiers in SOT-23.

The LTC2051/LTC2052 are dual/quad zero-drift operational amplifiers available in the MS8 and SO-8/GN16 and S14 packages. For space limited applications, the LTC2051 is available in a 3mm ? 3mm ? 0.8mm dual fine pitch leadless package (DFN). They operate from a single 2.7V supply and support ?5V applications. The current consumption is 750?A per op amp.The LTC2051/LTC2052, despite their miniature size, feature uncompromising DC performance. The typical input offset voltage and offset drift are 0.5?V and 10nV/?C. The almost zero DC offset and drift are supported with a power supply rejection ratio (PSRR) and common mode rejection ratio (CMRR) of more than 130dB.The input common mode voltage ranges from the negative supply up to typically 1V from the positive supply. The LTC2051/LTC2052 also have an enhanced output stage capable of driving loads as low as 2k? to both supply rails. The open-loop gain is typically 140dB. The LTC2051/ LTC2052 also feature a 1.5?VP-P DC to 10Hz noise and a 3MHz gain-bandwidth product.Applications Thermocouple Amplifiers Electronic Scales Medical Instrumentation Strain Gauge Amplifiers High Resolution Data Acquisition DC Accurate RC Active Filters Low Side Current Sense

The LT3469 is a transconductance (gm) amplifier that can drive outputs up to 33V from a 5V or 12V supply. An internal switching regulator generates a boosted supply voltage for the gm amplifier. The amplifier can drive capacitive loads in the range of 5nF to 300nF. Slew rate is limited only by the maximum output current. The 35V output voltage capability of the switching regulator, along with the high supply voltage of the amplifier, combine to allow the wide output voltage range needed to drive a piezoceramic microactuator.The LT3469 switching regulator switches at 1.3MHz, allowing the use of tiny external components. The output capacitor can be as small as 0.22?F, saving space and cost versus alternative solutions.The LT3469 is available in a low profile ThinSOT? package.Applications Piezo Speakers Piezo Microactuators Varactor Bias

The ADM1192 is an integrated current sense amplifier that offers digital current and voltage monitoring via an on-chip, 12-bit analog-to-digital converter (ADC), communicated through an I2C interface.An internal current sense amplifier senses voltage across the sense resistor in the power path via the VCC pin and the SENSE pin.A 12-bit ADC can measure the current seen in the sense resistor and in the supply voltage on the VCC pin. An industry-standard I2C interface allows a controller to read current and voltage data from the ADC. Measurements can be initiated by an I2C command. Alternatively, the ADC can run continuously, and the user can read the latest conversion data whenever it is required. Up to four unique I2C addresses can be created, depending on the way the ADR pin is connected.A SETV pin is also included. A voltage applied to this pin is internally compared to the output voltage on the current sense amplifier. The output of the SETV comparator asserts when the current sense amplifier output exceeds the SETV voltage. This event is detected at the ALERT block. The ALERT block then charges up the external TIMER capacitor with a fixed current. When this timing cycle is complete, the ALERT output asserts.The ALERT output can be used as a flag to warn a micro-controller or field programmable gate array (FPGA) of an overcurrent condition. ALERT outputs of multiple ADM1192 devices can be tied together and used as a combined alert.A basic P-channel FET hot swap circuit can be implemented with the ALERT output. The value of the TIMER capacitor should be set so that the charging time of this capacitor is much longer than the period where a higher than nominal inrush current may be flowing.The ADM1192 is packaged in a 10-lead MSOP.APPLICATIONS Power monitoring/power budgeting Central office equipment Telecommunication and data communication equipment PCs/servers

The ADA4098-1?and ADA4098-2?are single/dual robust, precision, rail-to-rail input and output operational amplifiers (op amps) with inputs that operate from ?VS to +VS and beyond, which is referred to in this data sheet as Over-The-Top?. The devices feature offset voltages of ?VS, independent of the +VS supply.The ADA4098-1 and ADA4098-2 are unity-gain stable and can drive loads requiring up to 20 mA per channel. The devices can also drive capacitive loads as large as 200 pF. The amplifiers are available with low power shutdown.The ADA4098-1 is available in a standard, 6-lead thin small outline transistor (TSOT) package. The ADA4098-2 is available in an 8-lead standard small outline (SOIC_N) package, 8-lead mini small outline package (MSOP), and 10-lead lead-frame chip-scale package (LFCSP).APPLICATIONS Industrial sensor conditioning Supply current sensing Battery and power supply monitoring Front-end amplifiers in abusive environments 4 mA to 20 mA transmitters

The ADA4522-1 / ADA4522-2 / ADA4522-4 are single/dual/quadchannel, zero drift op amps with low noise and power, groundsensing inputs, and rail-to-rail output, optimized for totalaccuracy over time, temperature, and voltage conditions. Thewide operating voltage and temperature ranges, as well as thehigh open-loop gain and very low dc and ac errors make thedevices well suited for amplifying very small input signals andfor accurately reproducing larger signals in a wide variety ofapplications.The ADA4522-1 / ADA4522-2 / ADA4522-4 performance isspecified at 5.0 V, 30 V, and 55 V power supply voltages. Thesedevices operate over the range of 4.5 V to 55 V, and are excellentfor applications using single-ended supplies of 5 V, 10 V, 12 V,and 30 V, or for applications using higher single supplies anddual supplies of ?2.5 V, ?5 V, and ?15 V. The ADA4522-1 / ?ADA4522-2 / ADA4522-4 use on-chip filtering to achieve highimmunity to electromagnetic interference (EMI).The ADA4522-1 / ADA4522-2 / ADA4522-4 are fully specifiedover the extended industrial temperature range of ?40?C to+125?C and are available in 8-lead MSOP, 8-lead SOIC, 14-leadSOIC, and 14-lead TSSOP packages.APPLICATIONS Inductance, capacitance, and resistance (LCR) meter/megohmmeter front-end amplifiers Load cell and bridge transducers Magnetic force balance scales High precision shunt current sensing Thermocouple/resistance temperature detector (RTD) sensors Programmable logic controller (PLC) input and output amplifiers

The ADCMP551 / ADCMP552?/ ADCMP553?are single supply,high speed comparators fabricated on Analog Devices?proprietary XFCB process. The devices feature a 750 ps propagation delay with less than 150 ps overdrive dispersion. Dispersion, a measure of the difference in propagation delay under differing overdrive conditions, is a particularly importantcharacteristic of high speed comparators. A separateprogrammable hysteresis pin is available on the ADCMP552.A differential input stage permits consistent propagation delay with a common-mode range from ?0.2 V to VCCI ? 2.0 V. Outputs are complementary digital signals are fully compatible with PECL 10 K and 10 KH logic families. The outputs providesufficient drive current to directly drive transmission lines terminated in 50 ? to VCCO - 2 V. A latch input is included and permits tracking, track-and-hold, or sample-and-hold modes of operation. The latch input pins contain internal pullups that set the latch in tracking mode when left open. The ADCMP551 / ADCMP552 / ADCMP553 are specified over the ?40?C to +85?C industrial temperature range. TheADCMP551 is available in a 16-lead QSOP package; theADCMP552 is available in a 20-lead QSOP package; and the ADCMP553 is available in an 8-lead MSOP package.APPLICATIONS Automatic test equipment High speed instrumentation Scope and logic analyzer front ends Window comparators High speed line receivers Threshold detection Peak detection High speed triggers Patient diagnostics Disk drive read channel detection Hand-held test instruments Zero crossing detectors Line receivers and signal restoration Clock drivers

The ADCMP563/ADCMP564 are high speed comparatorsfabricated on Analog Devices? proprietary XFCB process. Thedevices feature a 700 ps propagation delay with less than 75 psoverdrive dispersion. Dispersion, a measure of the difference inpropagation delay under differing overdrive conditions, is a particularlyimportant characteristic of high speed comparators. A separateprogrammable hysteresis pin is available on the ADCMP564.A differential input stage permits consistent propagation delaywith a wide variety of signals in the common-mode range from?2.0 V to +3.0 V. Outputs are complementary digital signals thatare fully compatible with ECL 10 K and 10 KH logic families.The outputs provide sufficient drive current to directly drivetransmission lines terminated in 50 ? to ?2 V. A latch input,which is included, permits tracking, track-and-hold, or sample-and-holdmodes of operation. The latch input pins contain internalpull-ups that set the latch in tracking mode when left open.The ADCMP563/ADCMP564 are specified over the industrialtemperature range (?40?C to +85?C).Applications Automatic test equipment High speed instrumentation Scope and logic analyzer front ends Window comparators High speed line receivers Threshold detection Peak detection High speed triggers Patient diagnostics Hand-held test instruments Zero crossing detectors Line receivers and signal restoration Clock drivers
