Texas Instruments
LM139AW/883
|
Texas Instruments
LMV951MK/NOPB
|
Texas Instruments
LPV7215MG/NOPB
|
Texas Instruments
M38510/12501BGA
|
Texas Instruments
M38510/11201BDA
|
Texas Instruments
LMH6550MM/NOPB
|
Texas Instruments
LPV531MKX/NOPB
|
Texas Instruments
LMH6551MMX/NOPB
|
Texas Instruments
LMH6601MGX/NOPB
|
Texas Instruments
LMC6442AIMX/NOPB
|
| Price |
|
|
|
|
|
|
$3.44 |
$0.51 |
|
$1.15 |
|
| RoHS |
|
Not Compliant |
Compliant |
Compliant |
Not Compliant |
Not Compliant |
Yes |
Compliant |
Compliant |
Compliant |
Compliant |
| Lead Status |
|
No |
No |
No |
No |
No |
Yes |
No |
No |
No |
No |
| Package Size |
|
mm2 |
mm2 |
mm2 |
|
mm2 |
mm2 |
mm2 |
mm2 |
mm2 |
mm2 |
| Vs(Max)(V) |
|
36 |
|
5.5 |
|
36 |
|
|
|
|
|
| Rating |
|
Military |
Catalog |
Catalog |
Military |
Military |
Catalog |
Catalog |
Catalog |
Catalog |
Catalog |
| tRESP Low - to - High(us) |
|
0.7 |
|
12 |
|
0.7 |
|
|
|
|
|
| Output Type |
|
Open Collector, Open Drain |
|
Push-Pull |
|
Open Collector, Open Drain |
|
|
|
|
|
| Special Features |
|
N/A |
|
N/A |
|
N/A |
|
|
|
|
|
| Vos (Offset Voltage @ 25C)(Max)(mV) |
|
2 |
2.8 |
3.4 |
|
5 |
5 |
4.5 |
5 |
2.4 |
3 |
| Vs(Min)(V) |
|
2 |
|
2.7 |
|
2 |
|
|
|
|
|
| Number of Channels(#) |
|
4 |
1 |
1 |
|
4 |
1 |
1 |
1 |
1 |
2 |
| Iq per channel(Max)(mA) |
|
0.5 |
0.78 |
0.00092 |
|
0.5 |
24 |
0.53 |
14.5 |
11.5 |
0.0012 |
| Operating Temperature Range(C) |
|
-55 to 125 |
-40 to 125 |
-40 to 125 |
|
-55 to 125 |
-40 to 85 |
-40 to 85 |
-40 to 85 |
-40 to 85 |
-40 to 85 |
| Input Bias Current (+/-)(Max)(nA) |
|
100 |
|
0.001 |
|
100 |
|
|
|
|
|
| VICR(Max)(V) |
|
34 |
|
5.5 |
|
34 |
|
|
|
|
|
| Rail-to-Rail |
|
Out |
In,Out |
No |
|
Out |
No |
In to V-,Out |
No |
In to V-,Out |
In to V-,Out |
| Package Group |
|
CDIP,CFP,DIESALE,LCCC |
SOT |
SC70,SOT-23 |
|
CFP |
SOIC,VSSOP |
SOT-23-THIN |
SOIC,VSSOP |
SC70 |
PDIP,SOIC |
| VICR(Min)(V) |
|
0 |
|
0 |
|
0 |
|
|
|
|
|
| CMRR(Min)(dB) |
|
|
82 |
|
|
|
72 |
72 |
72 |
56 |
67 |
| Architecture |
|
|
Bipolar |
|
|
|
Bipolar,Fully Differential,Voltage FB |
CMOS |
Bipolar,Fully Differential,Voltage FB |
Bipolar,Voltage FB |
CMOS |
| Total Supply Voltage(Min)(+5V=5, +/-5V=10) |
|
|
0.9 |
|
|
|
4.5 |
2.7 |
3 |
2.4 |
1.8 |
| Slew Rate(Typ)(V/us) |
|
|
1.4 |
|
|
|
3000 |
2.5 |
2400 |
275 |
0.0041 |
| Additional Features |
|
|
Shutdown |
|
|
|
Shutdown |
Shutdown |
N/A |
Shutdown |
Decompensated |
| Iq per channel(Typ)(mA) |
|
|
0.57 |
|
|
|
20 |
0.425 |
12.5 |
9.6 |
0.00095 |
| CMRR(Typ)(dB) |
|
|
93 |
|
|
|
82 |
95 |
80 |
68 |
92 |
| Offset Drift(Typ)(uV/C) |
|
|
0.15 |
|
|
|
1.6 |
0.1 |
0.8 |
5 |
0.4 |
| Vn at 1kHz(Typ)(nV/rtHz) |
|
|
25 |
|
|
|
|
25 |
|
|
170 |
| Total Supply Voltage(Max)(+5V=5, +/-5V=10) |
|
|
3 |
|
|
|
12 |
5 |
12 |
5.5 |
11 |
| Input Bias Current(Max)(pA) |
|
|
80000 |
|
|
|
16000000 |
1 |
10000000 |
50 |
0.05 |
| GBW(Typ)(MHz) |
|
|
2.8 |
|
|
|
400 |
4.6 |
370 |
250 |
0.01 |
| Output Current(Typ)(mA) |
|
|
80 |
|
|
|
75 |
15 |
65 |
150 |
0.9 |
| Approx. Price (US$) |
|
|
0.52 | 1ku |
0.49 | 1ku |
|
|
1.99 | 1ku |
0.45 | 1ku |
1.71 | 1ku |
0.62 | 1ku |
0.87 | 1ku |
| @ MHz |
|
|
|
|
|
|
5 |
|
5 |
10 |
|
| 2nd Harmonic(dBc) |
|
|
|
|
|
|
92 |
|
94 |
56 |
|
| 3rd Harmonic(dBc) |
|
|
|
|
|
|
103 |
|
96 |
73 |
|
| Vn at Flatband(Typ)(nV/rtHz) |
|
|
|
|
|
|
6 |
|
6 |
10 |
|
| Acl, min spec gain(V/V) |
|
|
|
|
|
|
1 |
|
1 |
1 |
|
| BW @ Acl(MHz) |
|
|
|
|
|
|
400 |
|
370 |
250 |
|
