150MHz, 250V/s, AV 4 Operational Amplifier Features: Gain-Bandwidth: 150MHz Gain of 4 Stable Slew Rate: 250V/µs Input Noise Voltage: 6nV/√Hz C-Load™ Op Amp Drives Capacitive Loads Maximum Input Offset Voltage: 600µV Maximum Input Bias Current: 300nA Maximum Input Offset Current: 300nA Minimum Output Swing Into 500Ω: ±12V Minimum DC Gain: 50V/mV, RL = 500Ω Settling Time to 0.1%: 65ns, 10V Step Settling Time to 0.01%: 85ns, 10V Step Differential Gain: 0.08%, AV = 4, RL = 150Ω Differential Phase: 0.2°, AV = 4, RL = 150Ω

100MHz Current Feedback Amplifier with DC Gain Control Features: Very Fast Transconductance Amplifier Bandwidth: 75MHz Outputs Swing Within 0.8V of Supplies gm = 10 × ISET Low THD: 0.2% at 30mVRMS Input Wide ISET Range: 1µA to 1mA Very Fast Current Feedback Amplifier Bandwidth: 100MHz Slew Rate: 1000V/µs Output Drive Current: 30mA Differential Gain: 0.04% Differential Phase: 0.1° High Input Impedance: 25MΩ, 6pF Wide Supply Range: ±2V to ±15V Inputs Common Mode to Within 1.5V of Supplies Supply Current: 7mA Available in 8-Lead PDIP and SOIC Packages

Dual 100MHz Current Feedback Amplifiers Features: 100MHz Bandwidth 1000V/µs Slew Rate Low Cost 30mA Output Drive Current 0.04% Differential Gain 0.1° Differential Phase High Input Impedance: 25MΩ, 3pF Wide Supply Range: ±2V to ±15V Low Supply Current: 6mA Per Amplifier Inputs Common Mode to Within 1.5V of Supplies Outputs Swing Within 0.8V of Supplies

Low Cost Dual and Triple 130MHz Current Feedback Amplifiers with Shutdown Features: 90MHz Bandwidth on ±5V 0.1dB Gain Flatness > 30MHz Completely Off in Shutdown, 0µA Supply Current High Slew Rate: 1600V/µs Wide Supply Range: ±2V(4V) to ±15V(30V) 60mA Output Current Low Supply Current: 5mA/Amplifier Differential Gain: 0.016% Differential Phase: 0.075° Fast Turn-On Time: 100ns Fast Turn-Off Time: 40ns 14-Pin and 16-Pin Narrow SO Packages

Low Cost Dual and Triple 130MHz Current Feedback Amplifiers with Shutdown Features: 90MHz Bandwidth on ±5V 0.1dB Gain Flatness > 30MHz Completely Off in Shutdown, 0µA Supply Current High Slew Rate: 1600V/µs Wide Supply Range: ±2V(4V) to ±15V(30V) 60mA Output Current Low Supply Current: 5mA/Amplifier Differential Gain: 0.016% Differential Phase: 0.075° Fast Turn-On Time: 100ns Fast Turn-Off Time: 40ns 14-Pin and 16-Pin Narrow SO Packages

Precision Operational Amplifier Features: Guaranteed Low Offset Voltage LT1001AM 15µV max LT1001C 60µV max Guaranteed Low Drift LT1001AM 0.6µV/°C max LT1001C 1.0µV/°C max Guaranteed Low Bias Current LT1001AM 2nA max LT1001C 4nA max Guaranteed CMRR LT1001AM 114dB min LT1001C 110dB min Guaranteed PSRR LT1001AM 110dB min LT1001C 106dB min Low Power Dissipation LT1001AM 75mW max LT1001C 80mW max Low Noise 0.3µVp-p

Low Noise, High Speed Precision Operational Amplifiers Features: Guaranteed 4.5 nV/√Hz 10Hz noise Guaranteed 3.8 nV/√Hz 1kHz noise 0.1Hz to 10Hz noise, 60nVP-P, Typical Guaranteed 7 Million Min Voltage Gain, RL = 2k Guaranteed 3 Million Min Voltage Gain, RL = 600 Guaranteed 25µV Max Offset Voltage Guaranteed 0.6µV/°C Max Drift with Temperature Guaranteed 11V/µs Min Slew Rate (LT1037) Guaranteed 117 dB Min CMRR

Picoamp Input Current, Microvolt Offset, Low Noise Op Amp Features: Guaranteed Bias Current TA = 25°C: 100pA Max TA = –55°C to 125°C: 600pA Max Guaranteed Offset Voltage: 120µV Max Guaranteed Drift: 1.5µV/°C Max Low Noise, 0.1Hz to 10Hz: 0.5µVP-P Guaranteed Low Supply Current: 600µA Max Guaranteed CMRR: 114dB Min Guaranteed PSRR: 114dB Min Guaranteed Voltage Gain with 5mA load Current Available in 8-Lead PDIP and SO Packages

Picoamp Input Current, Microvolt Offset, Low Noise Op Amp Features: Guaranteed Bias Current TA = 25°C: 100pA Max TA = –55°C to 125°C: 600pA Max Guaranteed Offset Voltage: 120µV Max Guaranteed Drift: 1.5µV/°C Max Low Noise, 0.1Hz to 10Hz: 0.5µVP-P Guaranteed Low Supply Current: 600µA Max Guaranteed CMRR: 114dB Min Guaranteed PSRR: 114dB Min Guaranteed Voltage Gain with 5mA load Current Available in 8-Lead PDIP and SO Packages

Picoamp Input Current, Microvolt Offset, Low Noise Op Amp Features: OP-07 Type Performance: at 1/8th of OP-07’s Supply Current at 1/20th of OP-07’s Bias and Offset Currents Guaranteed Offset Voltage: 25µV Max Guaranteed Bias Current: 100pA Max Guaranteed Drift: 0.6µV/°C Max Low Noise, 0.1Hz to 10Hz: 0.5µVP-P Guaranteed Low Supply Current: 500µA Max Guaranteed CMRR: 114dB Min Guaranteed PSRR: 114dB Min Guaranteed Operation at ±1.2V Supplies
