The AD9520-31 provides a multioutput clock distribution function with subpicosecond jitter performance, along with an on-chip PLL and VCO. The on-chip VCO tunes from 1.72 GHz to 2.25 GHz. An external 3.3 V/5 V VCO/VCXO of up to 2.4 GHz can also be used.The AD9520 serial interface supports both SPI and I2C? ports. An in-package EEPROM can be programmed through the serial interface and store user-defined register settings for power-up and chip reset.The AD9520 features 12 LVPECL outputs in four groups. Any of the 1.6 GHz LVPECL outputs can be reconfigured as two 250 MHz CMOS outputs.Each group of outputs has a divider that allows both the divide ratio (from 1 to 32) and the phase (coarse delay) to be set.The AD9520 is available in a 64-lead LFCSP and can be operated from a single 3.3 V supply. The external VCO can have an operating voltage up to 5.5 V. A separate output driver power supply can be from 2.375 V to 3.465 V.The AD9520 is specified for operation over the standard industrial range of ?40?C to +85?C.1The AD9520 is used throughout this data sheet to refer to all the members of the AD9520 family. However, when AD9520-3 is used, it is referring to that specific member of the AD9520 family.Applications Low jitter, low phase noise clock distribution Clock generation and translation for SONET, 10Ge, 10G FC, and other 10 Gbps protocols Forward error correction (G.710) Clocking high speed ADCs, DACs, DDSs, DDCs, DUCs, MxFEs High performance wireless transceivers ATE and high performance instrumentation Broadband infrastructures

The AD9522-11 provides a multioutput clock distribution function with subpicosecond jitter performance, along with an on-chip PLL and VCO. The on-chip VCO tunes from 2.27 GHz to 2.65 GHz. An external 3.3 V/5 V VCO/VCXO of up to 2.4 GHz can also be used.The AD9522 serial interface supports both SPI and I2C? ports. An in-package EEPROM can be programmed through the serial interface and store user-defined register settings for power-up and chip reset.The AD9522 features 12 LVDS outputs in four groups. Any of the 800 MHz LVDS outputs can be reconfigured as two 250 MHz CMOS outputs.Each group of outputs has a divider that allows both the divide ratio (from 1 to 32) and the phase (coarse delay) to be set.The AD9522 is available in a 64-lead LFCSP and can be operated from a single 3.3 V supply. The external VCO can have an operating voltage up to 5.5 V.The AD9522 is specified for operation over the standard industrial range of ?40?C to +85?C.The AD9520-1 is an equivalent part to the AD9522-1 featuring LVPECL/CMOS drivers instead of LVDS/CMOS drivers.1The AD9522 is used throughout this data sheet to refer to all the members of the AD9522 family. However, when AD9522-1 is used, it is referring to that specific member of the AD9522 family.ApplicationsLow jitter, low phase noise clock distributionClock generation and translation for SONET, 10Ge, 10G FC, and other 10 Gbps protocolsForward error correction (G.710)Clocking high speed ADCs, DACs, DDSs, DDCs, DUCs, MxFEsHigh performance wireless transceiversATE and high performance instrumentationBroadband infrastructures

The AD9523-1 provides a low power, multi-output, clock distribution function with low jitter performance, along with an on-chip PLL and VCO with two VCO dividers. The on-chip VCO tunes from 2.94 GHz to 3.1 GHz.The AD9523-1 is designed to support the clock requirements for long term evolution (LTE) and multicarrier GSM base station designs. It relies on an external VCXO to provide the reference jitter cleanup to achieve the restrictive low phase noise requirements necessary for acceptable data converter SNR performance.The input receivers, oscillator, and zero delay receiver provide both single-ended and differential operation. When connected to a recovered system reference clock and a VCXO, the device generates 14 low noise outputs with a range of 1 MHz to 1 GHz, and one dedicated buffered output from the input PLL (PLL1). The frequency and phase of one clock output relative to another clock output can be varied by means of a divider phase select function that serves as a jitter-free, coarse timing adjustment in increments that are equal to half the period of the signal coming out of the VCO.An in-package EEPROM can be programmed through the serial interface to store user-defined register settings for power-up and chip reset.APPLICATIONS LTE and multicarrier GSM base stations Wireless and broadband infrastructure Medical instrumentation Clocking high speed ADCs, DACs, DDSs, DDCs, DUCs, MxFEs Low jitter, low phase noise clock distribution Clock generation and translation for SONET, 10Ge, 10G FC, and other 10 Gbps protocols Forward error correction (G.710) High performance wireless transceivers ATE and high performance instrumentation

The 10 clock outputs of the AD9544 are synchronized to any one of up to four input references. The digital phase-locked loops (DPLLs) reduce timing jitter associated with the external references. The digitally controlled loop and holdover circuitry continuously generate a low jitter output signal, even when all reference inputs fail.The AD9544 is available in a 48-lead LFCSP (7 mm ? 7 mm) package and operates over the ?40?C to +85?C temperature range.Note that throughout this data sheet, multifunction pins, such as SDO/M5, are referred to either by the entire pin name or by a single function of the pin, for example, M5, when only that function is relevant.Appliations SyncE and GPS synchronization and jitter cleanup Optical transport networks (OTN), SDH, and macro and small cell base stations OTN mapping/demapping with jitter cleaning Small base station clocking, including baseband and radio Stratum 2, Stratum 3e, and Stratum 3 holdover, jitter cleanup, and phase transient control JESD204B support for analog-to-digital converter (ADC) and digital-to-analog converter (DAC) clocking Cable infrastructures Carrier Ethernet

The AD9559 is a low loop bandwidth clock multiplier that provides jitter cleanup and synchronization for many systems, including synchronous optical networks (SONET/SDH). The AD9559 generates an output clock synchronized to up to four external input references. The digital PLL allows for reduction of input time jitter or phase noise associated with the external references. The digitally controlled loop and holdover circuitry of the AD9559 continuously generates a low jitter output clock even when all reference inputs have failed.The AD9559 operates over an industrial temperature range of ?40?C to +85?C. If a single DPLL version of this part is needed, refer to the AD9557.APPLICATIONS Network synchronization, including Synchronous Ethernet and OTN mapping/de-mapping Cleanup of reference clock jitter SONET/SDH clocks up to OC-192, including FEC Stratum 3 holdover, jitter cleanup, and phase transient control Wireless base station controllers Cable infrastructure Data communications

The ADCLK905 (one input, one output), ADCLK907 (dual oneinput, one output), and ADCLK925 (one input, two outputs) areultrafast clock/data buffers fabricated on the Analog Devices, Inc.,proprietary XFCB3 silicon germanium (SiGe) bipolar process.The ADCLK905/ADCLK907/ADCLK925 feature full-swing emitter coupled logic (ECL) output drivers. For PECL (positive ECL) operation, bias VCC to the positive supply and VEE to ground. For NECL (negative ECL) operation, bias VCC to ground and VEE to the negative supply.The buffers offer 95 ps propagation delay, 7.5 GHz toggle rate, 10 Gbps data rate, and 60 fs random jitter (RJ).The inputs have center tapped, 100 ?, on-chip termination resistors. A VREF pin is available for biasing ac-coupled inputs.The ECL output stages are designed to directly drive 800 mV each side into 50 ? terminated to VCC ? 2 V for a total differential output swing of 1.6 V.The ADCLK905/ADCLK907/ADCLK925 are available in 16-lead LFCSP packages.Applications Clock and data signal restoration and level shifting Automated test equipment (ATE) High speed instrumentation High speed line receivers Threshold detection Converter clocking

Delay Line IC Nonprogrammable 5 Tap 500ns 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)

Dual DPLL, Quad Input, 10 Output, Multiservice Line Card Clock Translator and Jitter Cleaner Features:Dual DPLL synchronizes 2 kHz to 750 MHz physical layer clocks providing frequency translation with jitter cleaning of noisy referencesComplies with ITU-T G.8262 and Telcordia GR-253Supports Telcordia GR-1244, ITU-T G.812, G.813, G.823, G.824, and G.825Continuous frequency monitoring and reference validation for frequency deviation as low as 50 ppbBoth DPLLs feature a 24-bit fractional divider with 24-bit programmable modulusProgrammable digital loop filter bandwidth: 104 Hz to 1850 HzAutomatic and manual holdover and reference switchover, providing zero delay, hitless, or phase buildout operationProgrammable priority-based reference switching with manual, automatic revertive, and automatic nonrevertive modes supported5 pairs of clock output pins with each pair useable as differential LVDS/HCSL/CML or as 2 single-ended outputs (1 Hz to 500 MHz)2 differential or 4 single-ended input referencesCrosspoint mux interconnects reference inputs to PLLsSupports embedded (modulated) input/output clock signalsFast DPLL locking modesProvides internal capability to combine the low phase noise of a crystal resonator or crystal oscillator with the frequency stability and accuracy of a TCXO or OCXOExternal EEPROM support for autonomous initializationSingle 1.8 V power supply operation with internal regulationBuilt in temperature monitor/alarm and temperature compensation for enhanced zero delay performance

Low Phase Noise, Triple Output Clock Distribution Divider/Driver Features: Low Noise Clock Distribution: Suitable for High Speed/High Resolution ADC Clocking Additive Jitter < 20fsRMS (12kHz to 20MHz) Additive Jitter < 85fsRMS (10Hz to Nyquist) 1.8GHz Maximum Input Frequency (LTC6954-1 When DELAY = 0) 1.4GHz Maximum Input Frequency (LTC6954-1 When DELAY > 0, LTC6954-2, -3, -4) EZSync™ Clock Synchronization Compatible Three Independent, Low Noise Outputs Four Output Combinations Available Three Independent Programmable Dividers Covering All Integers From 1 to 63 Three Independent Programmable Delays Covering All Integers From 0 to 63 –40°C to 105°C Junction Temperature Range

Microwave Wideband Synthesizer with Integrated VCO Features: Output frequency range: 800 MHz to 12.8 GHz Jitter = 18 fsRMS (Integration BW: 100 Hz to 100 MHz) Jitter = 27 fsRMS (ADC SNR Method) Wideband Noise Floor: -160 dBc/Hz @12 GHz PLL Specifications: -239 dBc/Hz: Normalized In-Band Phase Noise Floor -147 dBc/Hz: Normalized In-Band 1/f Noise Phase Detector Frequency up to 500 MHzReference Input Frequency up to 1 GHz Typical -100 dBc PFD spursReference to Output Delay Specifications: Part-to-Part Standard Deviation: 3 ps Temperature Drift: 0.03 ps/ Adjustment Step Size: <+/-0.1 ps Multi-chip Output Phase Alignment 3.3 V and 5 V Power supplies 7 mm x 7 mm 48 Lead LGA
