The DS1374 is a 32-bit binary counter designed to continuously count time in seconds. An additional counter generates a periodic alarm or serves as a watchdog timer. If disabled, this counter can be used as 3 bytes of nonvolatile (NV) RAM. Separate output pins are provided for an interrupt and a square wave at one of four selectable frequencies. A precision temperature-compensated reference and comparator circuit monitor the status of VCC to detect power failures, provide a reset output, and automatically switch to the backup supply when necessary.Additionally, the reset pin is monitored as a pushbutton input for externally generating a reset. The device is programmed serially through an I²C serial interface.ApplicationsMedical EquipmentPoint-of-Sale EquipmentPortable InstrumentationTelecommunications

Real Time Clock Real Time Clock

The DS3231M is a low-cost, extremely accurate, I2C real-time clock (RTC). The device incorporates a battery input and maintains accurate timekeeping when main power to the device is interrupted. The integration of the microelectromechanical systems (MEMS) resonator enhances the long-term accuracy of the device and reduces the piece-part count in a manufacturing line. The DS3231M is available in the same footprint as the popular DS3231 RTC.The RTC maintains seconds, minutes, hours, day, date, month, and year information. The date at the end of the month is automatically adjusted for months with fewer than 31 days, including corrections for leap year. The clock operates in either the 24-hour or 12-hour format with an active-low AM/PM indicator. Two programmable time-of-day alarms and a 1Hz output are provided. Address and data are transferred serially through an I2C bidirectional bus. A precision temperature-compensated voltage reference and comparator circuit monitors the status of VCC to detect power failures, to provide a reset output, and to automatically switch to the backup supply when necessary. Additionally, the active-low RST pin is monitored as a pushbutton input for generating a microprocessor reset. See the Block Diagram in the full data sheet for more details.ApplicationsIndustrial ApplicationsPower Meters

Ultra-Low-Power, I²C Real-Time Clock and Power Management

The MAX31331 ultra-low power, real-time clock (RTC) is a time-keeping device that consumes nominal 65nA timekeeping current, extending battery life. The MAX31331 supports a wide range of 32.768kHz crystals. A crystal with any capacitive loading (CL) spec can be used, which broadens the pool of usable crystals for this device. This device is accessed through an I²C serial interface.

The device also features a backup supply pin (VBAT) and automatically switches over to the backup supply (VBAT) when the main supply (VCC) drops below the programmed threshold voltage and the backup supply (VBAT) voltage.

Other features include two time-of-day alarms, interrupt outputs, programmable square-wave output, event detection input with timestamping, and a serial bus timeout mechanism. The 32-byte timestamp registers double as RAM storage. The device features a digital Schmitt trigger input (DIN) which can be used to record timestamps and/or generate an interrupt on the falling/rising edge of the DIN signal. The clock/calendar provides seconds, minutes, hours, day, month, year, and date information. A 1/128 second register is available for a sub-second timestamp resolution. The date at the end of the month is automatically adjusted for months with fewer than 31 days, including corrections for leap year. The clock operates in 24-hour/12-hour format.

The MAX31331 is available in lead (Pb)-free/RoHS compliant, 12-bump, 1.66mm x 1.26mm WLP with 0.4mm pitch, as well as a 10-pin 3mm x 3mm TDFN package.

The device supports the -40°C to +85°C extended temperature range.

Applications

• Medical
• Wearables
• Portable Instruments
• Telematics
• Industrial
• IoT

Features and Benefits:

• Ultra-Low-Power Extends Run Time
  • 65nA Timekeeping Current
  • 1.1V to 5.5V Timekeeping Voltage Range
  • Automatic Switchover to Backup Supply on Power Fail Event
  • Trickle Charger for External Supercapacitor or Rechargeable Battery
• Small Footprint and Low BOM
  • 1.66mm x 1.26mm 12-bump WLP
  • 3mm x 3mm 10-pin TDFN
  • No External Load Capacitors Required
• Provides Flexibility
  • Wide Range of External Crystals Supported (No External Loading Required)
  • Frequency Correction with <0.5ppm Resolution
  • 1.62V to 5.5V Interface Voltage Range
• Value-Added Features for Ease of Use
  • Event Detection with Dedicated Pin
  • Timestamps for Various Events
  • Low Battery Voltage Detection
  • 1/128 Second Register
  • Alarms and Countdown Timer
  • 32-byte User RAM

The MAX31343 is a low-cost, extremely accurate, I2C real-time clock (RTC). The device incorporates a battery input and maintains accurate timekeeping when main power to the device is interrupted. The integration of the microelectromechanical systems (MEMS) resonator enhances the long-term accuracy of the device and eliminates the external crystal requirement in the system. The MAX31343 is available in the 8-pin WLP and TDFN packages.The RTC maintains seconds, minutes, hours, day, date, month, year, and century information. The date at the end of the month is automatically adjusted for months with fewer than 31 days, including corrections for leap year up to year 2199. The clock operates in the 24-hour format. Other features including two programmable time-of-day alarms, interrupt output, uncompensated programmable clock output, and temperature-compensated programmable square-wave output. Address and data are transferred serially through an I2C bidirectional bus. A voltage reference and comparator circuit monitors the status of VCC to detect power failures and automatically switch to the backup supply when necessary. See the Typical Application Circuit for more details.ApplicationsAction CamerasCommunicationsHandheld InstrumentationIndustrialPower MetersWearables

CLOCK & TIMING ANALOG DEV KITS;

Timers 115VAC-50HZ PANEL 12 M RESET TIMR

The Maxim ICM7555 and ICM7556 are respectively singleand dual general-purpose RC timers capable of generatingaccurate time delays or frequencies. The primaryfeature is an extremely low supply current, making thisdevice ideal for battery-powered systems. Additional featuresinclude low THRESHOLD, active-low TRIGGER, and active-low RESETcurrents, a wide operating supply voltage range, andimproved performance at high frequencies.These CMOS low-power devices offer significant performanceadvantages over the standard 555 and 556 bipolartimers. Low-power consumption, combined with the virtuallynonexistent current spike during output transitions, makethese timers the optimal solution in many applications.ApplicationsMissing Pulse DetectorPrecision TimingPulse GeneratorPulse Position ModulationPulse-Width ModulationSequential TimingTime Delay Generation
