| Price | |||||||||||
| RoHS | Compliant | Not Compliant | |||||||||
| Lead Status | No | No | |||||||||
| Housing Material | Nylon | ||||||||||
| Packaging Quantity | 1 | 100 | 100 | ||||||||
| Product Type | Housing | Hardware | Accessory | ||||||||
| Agency/Standard Number | E28476 | ||||||||||
| Packaging Method | Box | Bag | Bag | ||||||||
| Connector & Contact Terminates To | Wire & Cable | ||||||||||
| Housing Type | Plug/Receptacle | ||||||||||
| Contact Retention | Without | ||||||||||
| Multiple Contact Types | Without | ||||||||||
| Operating Voltage | 600 | ||||||||||
| UL Flammability Rating | UL 94V-0 | ||||||||||
| Glow Wire Rating | Standard Part - Not Glow Wire | ||||||||||
| Number of Rows | 1 | ||||||||||
| Contact Layout | Inline | ||||||||||
| Number of Positions | 2 | ||||||||||
| Housing Color | White | ||||||||||
| Centerline (Pitch) | 6.35 | ||||||||||
| Circuit Application | Power & Signal | ||||||||||
| Termination Method to Wire & Cable | Crimp | ||||||||||
| Operating Temperature Range | -67 – 221 | ||||||||||
| Connector Mounting Type | Cable Mount | ||||||||||
| Sealable | No | ||||||||||
| Connector System | Wire-to-Wire | ||||||||||
| Material | Zinc Alloy | ||||||||||
| Width | .312 | .312 | |||||||||
| For Use With | 6, 14, 20, 26, 34, 41, 50, 75 and 104 Position Standard Connectors | 20, 26, 34, 41 and 50 Position Posted Connectors | |||||||||
| Jackscrew Type | Turnable | Turnable | |||||||||
| Comment | Two required. | Two required. | |||||||||
| Hardware Type | Jackscrew Kit | Jackscrew Kit | |||||||||
| Jackscrew Material | Zinc Alloy | Zinc Alloy | |||||||||
| Mounting Hardware | Jackscrew Pin and Jackscrew Tip Male | Jackscrew Tip Male and Spirol Pin | |||||||||
| Length | 1.673 | 2.285 | |||||||||
| Height | 7.92 | 7.92 | |||||||||
| Thread Size | 6-32 [M3.5 x .6] | 6-32 | |||||||||
| Jackscrew Style | Short | Long | |||||||||
| Thread Lead Type | Single | Single | |||||||||
| Jackscrew Finish | Clear Chromate | Clear Chromate | |||||||||
| Strain Relief | Without | Without |
