Signal Conditioning Passive SMT Freq. Doubler, 4 - 8 GHz Fin

The HMC1044LP3E is a programmable bandwidth LPF (Low Pass Filter) targeted at all applications that use quadrature modulators and/or demodulators. The HMC1044LP3E filters out LO harmonics and ensures little or no LO contribution to modulator sideband rejection or demodulator image rejection performance.Although targeted at LO filtering applications, the HMC1044LP3E can be used to filter all RF harmonics such as the ones generated by amplifiers.The HMC1044LP3E offers a choice of 16 programmable bands, optimized for high and low cellular bands ranging from 1 to 3 GHz, making the a truly wideband part compatible with wideband PLLs with Integrated VCOs and wideband quadrature modulators and demodulators. It enables wideband multi-standard, multi-carrier designs that are field configurable on-the-fly for each individual application.The HMC1044LP3E is packaged in a compact 3x3 mm QFN leadless package.APPLICATIONS Filtering LO Harmonics to Reduce Modulator Sideband Rejection & Demodulator Image Rejection Amplifier Harmonic Filtering RF Filtering

The HMC891LP5E is a MMIC band pass filter which features a user selectable passband frequency. The 3 dB filter bandwidth is approximately 9%. The 20 dB filter bandwidth is approximately 27%. The center frequency can be varied between 2 and 3.9 GHz by applying an analog tune voltage between 0 and 14V. This tunable filter can be used as a much smaller alternative to physically large switched filter banks and cavity tuned filters. The HMC891LP5E has excellent microphonics due to the monolithic design, and provides a dynamically adjustable solution in advanced communications applications.Applications Test & Measurement Equipment Military RADAR & EW/ECM SATCOM & Space R&D Laboratories

Signal Conditioning assive Freq. Doubler Chip, 12-18GHz Fin

Active Filters BPF 20GHZ-40GHZ

SAW FILTER BAND 66 RX

Signal Conditioning 1710-1785 MHz Directional Cplr.

Noise Filter for use with Control Panel. Input Frequency Range: 50 → 60Hz. Leakage Current: 1mA. Input Current Range: 3A. Mounting Style: DIN Rail Mount. MPN: S8V-NFS203, Omron

Schneider Electric VW3A4554 Choke 155mm Length,, 30 A, 200 → 690 V for use with Altivar 61 Series. Width: 170mm. Depth: 135mm. Dimensions: 155 x 170 x 135 mm.

Common Mode Chokes / Filters SMD AC Common Mode Choke
