Precision Extended Bandwidth, RMS-to-DC Converter Features: High Linearity: 0.02% Linearity Allows Simple System Calibration Wide Input Bandwidth: Bandwidth to 0.1% Additional Gain Error: 40kHz Bandwidth Independent of Input Voltage Amplitude No-Hassle Simplicity: True RMS-DC Conversion with Only One External Capacitor Delta Sigma Conversion Technology Low Supply Current: 330µA Typ Ultralow Shutdown Current: 0.1µA Flexible Inputs: Differential or Single Ended Rail-to-Rail Common Mode Voltage Range Up to 1VPEAK Differential Voltage Flexible Output: Rail-to-Rail Output Separate Output Reference Pin Allows Level Shifting Small Size: Space Saving 8-Pin MSOP Package

Single Supply V.35 Transceiver Features: Single Chip Provides All V.35 Differential Clock and Data Signals Operates From Single 5V Supply Software Selectable DTE or DCE Configuration Transmitters and Receivers Will Withstand Repeated ±10kV ESD Pulses Shutdown Mode Reduces Icc to 1µA Typ 10MBaud Transmission Rate Transmitter Maintains High Impedance When Disabled, Shut Down, or with Power Off Meets CCITT V.35 Specification Transmitters are Short-Circuit Protected

Single Supply V.35 Transceiver Features: Single Chip Provides All V.35 Differential Clock and Data Signals Operates From Single 5V Supply Software Selectable DTE or DCE Configuration Transmitters and Receivers Will Withstand Repeated ±10kV ESD Pulses Shutdown Mode Reduces Icc to 1µA Typ 10MBaud Transmission Rate Transmitter Maintains High Impedance When Disabled, Shut Down, or with Power Off Meets CCITT V.35 Specification Transmitters are Short-Circuit Protected

High Current Supercapacitor Backup Controller and System Monitor Features: High Efficiency Synchronous Step-Down CC/CV Charging of One to Four Series Supercapacitors Step-Up Mode in Backup Provides Greater Utilization of Stored Energy in Supercapacitors 14-Bit ADC for Monitoring System Voltages/Currents, Capacitance and ESR Active Overvoltage Protection Shunts Internal Active Balancers—No Balance Resistors VIN: 4.5V to 35V, VCAP(n): Up to 5V per Capacitor, Charge/Backup Current: 10+A Programmable Input Current Limit Prioritizes System Load Over Capacitor Charge Current Dual Ideal Diode PowerPath™ Controller All N-FET Charger Controller and PowerPath Controller Compact 38-Lead 5mm × 7mm QFN Package AEC-Q100 Qualified for Automotive Applications

Dual Wide Range Power Monitor Features: Rail-to-Rail Input Range: 0V to 100V Wide Input Supply Range: 2.7V to 100V Measures Current, Voltage, and Power Shunt Regulator for Supplies >100V 8-/12-Bit ADCs with Less Than ±0.3% Total Unadjusted Error Four General Purpose Inputs/Outputs Configurable as ADC Inputs Continuous Scan and Snapshot Modes Stores Minimum and Maximum Measurements Alerts When Alarm Thresholds Exceeded Shutdown Mode with IQ < 50μA Split SDA Pin Eases Opto-Isolation Available in 16-Lead 4mm × 3mm DFN and MSOP Packages

2A Bidirectional Buck-Boost DC/DC Regulator and Charger/Balancer Features: VCAP Operating Range: 0.1V to 5.5V VSYS Operating Range: 1.71V to 5.25V Automatic Switchover from Charge to Backup Mode Programmable ±2% Accurate Charge Input Current Limit from 125mA to 2A ±1% Backup Voltage Accuracy Automatic Backup Capacitor Balancing Fixed 1.2MHz Switching Frequency Burst Mode® Operation: 40μA Quiescent Current Built-In Programmable Multipurpose Comparator with Open-Collector Output Open-Collector Outputs to Indicate Direction of Operation and End of Charge Thermally Enhanced TSSOP-24 and 4mm × 4mm QFN-24 Packages

The MAX180/MAX181 are complete 12-bit Data Acquisition System (DAS) which combine 8/6 channel input multiplexer, high bandwidth Track-and-Hold (T/H), low-drift zener reference, and flexible microprocessor (µP) interface with high conversion speed and low power consuption. The MAX180/MAX181 can be configured by a µP for unipolar or bipolar conversions and single-ended or differential inputs. Both devices sample and digitize at 100kHz throughout rate and feature a fast 8- or 16-bit µP interface.The MAX180 has 8 analog input channels, while the MAX181 has 6. The multiplexer output of the MAX180 is fed directly into the Analog-to-Digital Converter (ADC) input. The MAX181 brings out both the multiplexer output and ADC input to separate pins, allowing a programmable gain amplifier to be inserted between the MUX and the ADC.The systems allow the user to choose between an internal or an external reference. Furthermore, the internal reference value and the offest can be adjusted, allowing the overall system gain and offset errors to be nulled. The multiplexer has high impedence inputs, simplifying analog drive requirements.ApplicationsAutomated Test Equipment (ATE)Digital Signal Processing (DSP)High-Accuracy Process ControlHigh-Speed Servo Loops

The MAX199 multi-range, 12-bit data-acquisition system(DAS) requires only a single +5V supply for operation,and converts analog signals up to ±4V at its inputs. Thissystem provides eight analog input channels that areindependently software programmable for a variety ofranges: ±VREF, ±VREF/2, 0V to VREF, or 0V to VREF/2.This increases effective dynamic range to 14 bits, andprovides the user flexibility to interface 4mA-to-20mA,±12V, and ±15V powered sensors to a single +5V system.In addition, the converter is fault-protected to±16.5V; a fault condition on any channel will not affectthe conversion result of the selected channel. Other featuresinclude a 5MHz bandwidth track/hold, 100kspsthroughput rate, internal/external clock, internal/externalacquisition control, 8+4 parallel interface, and operationwith an internal 4.096V or external reference.A hardware active-low SHDN pin and two programmable power-downmodes (STBYPD, FULLPD) provide low-currentshutdown between conversions. In STBYPD mode, thereference buffer remains active, eliminating start-updelays.The MAX199 employs a standard microprocessor (µP)interface. Its three-state data I/O interface is configuredto operate with 8-bit data buses, and data-access andbus-release timing specifications are compatible withmost popular µPs. All logic inputs and outputs areTTL/CMOS compatible.The MAX199 is available in 28-pin DIP, wide SO, SSOP,and ceramic SB packages.For a different combination of input ranges (±10V, ±5V,0V to 10V, 0V to 5V), see the MAX197 data sheet. For 12-bit bus interfaces, see the MAX196/MAX198 data sheet.ApplicationsAutomatic Testing SystemsData-Acquisition SystemsIndustrial-Control SystemsMedical InstrumentsRoboticsTelecommunications

The MAX199 multi-range, 12-bit data-acquisition system(DAS) requires only a single +5V supply for operation,and converts analog signals up to ±4V at its inputs. Thissystem provides eight analog input channels that areindependently software programmable for a variety ofranges: ±VREF, ±VREF/2, 0V to VREF, or 0V to VREF/2.This increases effective dynamic range to 14 bits, andprovides the user flexibility to interface 4mA-to-20mA,±12V, and ±15V powered sensors to a single +5V system.In addition, the converter is fault-protected to±16.5V; a fault condition on any channel will not affectthe conversion result of the selected channel. Other featuresinclude a 5MHz bandwidth track/hold, 100kspsthroughput rate, internal/external clock, internal/externalacquisition control, 8+4 parallel interface, and operationwith an internal 4.096V or external reference.A hardware active-low SHDN pin and two programmable power-downmodes (STBYPD, FULLPD) provide low-currentshutdown between conversions. In STBYPD mode, thereference buffer remains active, eliminating start-updelays.The MAX199 employs a standard microprocessor (µP)interface. Its three-state data I/O interface is configuredto operate with 8-bit data buses, and data-access andbus-release timing specifications are compatible withmost popular µPs. All logic inputs and outputs areTTL/CMOS compatible.The MAX199 is available in 28-pin DIP, wide SO, SSOP,and ceramic SB packages.For a different combination of input ranges (±10V, ±5V,0V to 10V, 0V to 5V), see the MAX197 data sheet. For 12-bit bus interfaces, see the MAX196/MAX198 data sheet.ApplicationsAutomatic Testing SystemsData-Acquisition SystemsIndustrial-Control SystemsMedical InstrumentsRoboticsTelecommunications

Clock Buffer 8SLVP1104A 1:4, LVPECL Output Fanout Buffer
