| Price | $7.57 | $9.04 | $5.91 | $11.21 | $10.04 | ||||||
| RoHS | Compliant | Compliant | Compliant | Compliant | Compliant | Yes | Yes | Compliant | Compliant | Compliant | |
| Lead Status | No | No | Yes | No | No | Yes | Yes | No | No | No | |
| Frequency(MHz) | 60 | 60 | 60 | 60 | 60 | 8 | 8 | ||||
| Package Group | LQFP,TQFP,VQFN | LQFP,TQFP,VQFN | LQFP | LQFP | LQFP | LQFP,TQFP,VQFN | LQFP,TQFP,VQFN | ||||
| I2C | 1 | 1 | 1 | 1 | 1 | 0 | 0 | ||||
| CPU | C28x | C28x,CLA | C28x | C28x | C28x | MSP430 | MSP430 | ||||
| ROM(KB) | 0 | 0 | 0 | 0 | 0 | ||||||
| Approx. Price (US$) | 4.04 | 1ku | 4.76 | 1ku | 3.25 | 1ku | 3.55 | 1ku | 6.25 | 1ku | 3.00 | 1ku | 3.35 | 1ku | ||||
| UART | 1 | 1 | 3 | 3 | 3 | 1 | 1 | ||||
| Flash(KB) | 128 | 128 | 32 | 64 | 128 | ||||||
| CAP | 1 | 1 | 1 | 1 | 1 | ||||||
| Analog to Digital Converter (ADC) | ADC12 | ADC12 | ADC12 | ADC12 | ADC12 | ||||||
| Additional Features | Single Zone Code Security ,Temperature Sensor ,32-bit CPU Timers ,Watchdog Timer ,NMI Watchdog Timer ,2-pin Oscillator ,0-pin Oscillators ,Power On Reset (POR),Brown Out Reset (BOR),AEC-Q100 Automotive Qual | Single Zone Code Security,Temperature Sensor,32-bit CPU Timers,Watchdog Timer,NMI Watchdog Timer,2-pin Oscillator,0-pin Oscillators,Power On Reset (POR),Brown Out Reset (BOR),AEC-Q100 Automotive Qual | Dual Zone Code Security,Temperature Sensor,32-bit CPU Timers,Watchdog Timer,NMI Watchdog Timer,2-pin Oscillator,0-pin Oscillators,Power On Reset (POR),Brown Out Reset (BOR),AEC-Q100 Automotive Qual | Dual Zone Code Security,Temperature Sensor,32-bit CPU Timers,Watchdog Timer,NMI Watchdog Timer,2-pin Oscillator,0-pin Oscillators,Power On Reset (POR),Brown Out Reset (BOR),AEC-Q100 Automotive Qual | InstaSPIN-FOC Technology,Dual Zone Code Security,Temperature Sensor,32-bit CPU Timers,Watchdog Timer,NMI Watchdog Timer,2-pin Oscillator,0-pin Oscillators,Power On Reset (POR),Brown Out Reset (BOR),AEC-Q100 Automotive Qual | Watchdog,Temp Sensor | Watchdog,Temp Sensor | ||||
| Package Size | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | ||||
| GPIO | 45 ,33 ,26 | 45,33,26 | 42 | 42 | 42 | ||||||
| Processing Accelerators | N/A | N/A | N/A | N/A | N/A | ||||||
| ADC (Ch) | 16 ,14 ,13 | 16,14,13 | 16 | 16 | 16 | ||||||
| Frequency per CLA (MHz) | 0 | 60 | 0 | 0 | 0 | ||||||
| SPI | 2,1 | 2,1 | 1 | 1 | 1 | 1 | 1 | ||||
| Other Connectivity Features | CAN ,LIN | CAN,LIN | CAN | CAN | CAN | ||||||
| PWM Technology Type | Type 1 | Type 1 | Type 1 | Type 1 | Type 1 | ||||||
| Other Sensing Features | CAN ,LIN | High Resolution Captures,Standard Comparators | Programmable Gain Amplifiers (PGA),Windowed Comparators | Programmable Gain Amplifiers (PGA),Windowed Comparators | Programmable Gain Amplifiers (PGA),Windowed Comparators | ||||||
| Total Processing (MIPS) | 60 | 120 | 60 | 60 | 60 | ||||||
| Operating Temperature Range(C) | -40 to 105,-40 to 125 | -40 to 105,-40 to 125,-40 to 85 | -40 to 105,-40 to 125 | -40 to 105,-40 to 125 | -40 to 105,-40 to 125 | -40 to 85 | -40 to 85 | ||||
| RAM(KB) | 20 | 20 | 12 | 16 | 16 | 0.25 | 0.5 | ||||
| High Resolution PWM(Ch) | 7 ,6 ,4 | 7,6,4 | 0 | 0 | 0 | ||||||
| PWM(Ch) | 14 ,12 ,8 | 14,12,8 | 14 | 14 | 14 | ||||||
| Other Actuation Features | N/A | N/A | Digital to Analog Converters (DAC) | Digital to Analog Converters (DAC) | Digital to Analog Converters (DAC) | ||||||
| Comparators(Inputs) | 3 | 3 | 6 | 7 | 7 | Yes | Yes | ||||
| QEP | 1 | 1 | 1 | 1 | 1 | ||||||
| Multiplier | N/A | N/A | |||||||||
| Timers - 32-bit | 0 | 0 | |||||||||
| Active Power (uA/MHz) | 280 | 280 | |||||||||
| Rating | Catalog | Catalog | |||||||||
| GPIO Pins(#) | 48 | 48 | |||||||||
| Timers - 16-bit | 2 | 2 | |||||||||
| AES | N/A | N/A | |||||||||
| Min VCC | 1.8 | 1.8 | |||||||||
| Max VCC | 3.6 | 3.6 | |||||||||
| DMA | 0 | 0 | |||||||||
| Non-volatile Memory (KB) | 8 | 16 | |||||||||
| ADC | ADC12 - 8ch | ADC12 - 8ch | |||||||||
| Wakeup Time (us) | 6 | 6 | |||||||||
| Special I/O | N/A | N/A | |||||||||
| BSL | UART | UART | |||||||||
| Standby Power (LPM3-uA) | 1.6 | 1.6 |
