794727-1

TE Connectivity 794727-1

2-480701-0

TE Connectivity 2-480701-0

1-641966-1

TE Connectivity 1-641966-1

TE Connectivity 1-172337-2

TE Connectivity 1-172329-2

TE Connectivity 1-172158-9

1-641970-1

TE Connectivity 1-641970-1

350987-4

TE Connectivity 350987-4

794537-1

TE Connectivity 794537-1

1-480711-1

TE Connectivity 1-480711-1

Price
RoHS
Lead Status
Number of Rows 3 1 1 1 1 1 2 1 3 3
Housing Material Nylon Nylon Nylon Nylon 6/6 Nylon 6/6 Nylon 6/6 Nylon Nylon Nylon Nylon
CSA Rating Certified Certified Certified Certified Certified Certified Certified
Packaging Quantity 1 1 100 500 500 500 100 100 1 1
Product Type Housing Housing Header Connector Connector Connector Header Header Housing Housing
Length 20.32 20.32
Housing Color Black Natural Black Red Red Black Black Natural Black Brown
Agency/Standard Number E28476 E28476 E28476 E28476 E28476 E28476 E28476
Assembly Integration Feature Without Without Without Without Without Without Without
Connector & Contact Terminates To Wire & Cable Wire & Cable Printed Circuit Board Wire & Cable Wire & Cable Wire & Cable Printed Circuit Board Printed Circuit Board Wire & Cable Wire & Cable
Number of Positions 12 3 3 3 3 3 6 3 9 15
Contact Retention Without Without Without Without Without Without Without Without Without Without
Multiple Contact Types Without Without Without Without Without Without Without
Operating Voltage 600 600 600 600 600 600 600 600 600 600
Circuit Identification Feature Without
CSA File Number LR 7189 LR7189 LR7189 LR7189 LR7189 LR7189 LR7189
Agency/Standard CSA CSA CSA CSA CSA CSA CSA
Glow Wire Rating Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire
Connector System Wire-to-Wire Wire-to-Wire Wire-to-Board Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Board Wire-to-Board Wire-to-Wire Wire-to-Wire
Contact Type Pin Pin Pin Socket Pin Pin Pin Pin Socket Pin
Row-to-Row Spacing 6.35 6.35 6.35 .25
Contact Layout Matrix Inline Matrix Matrix Inline Matrix Matrix
Housing Type Receptacle Receptacle Plug Plug Receptacle Receptacle Receptacle Receptacle Plug Receptacle
Height 27.43 7.62
Connector Mounting Type Panel Panel Board Mount Cable Mount Panel Panel Board Mount Board Mount Cable Mount Panel
Panel Mount Feature With With Without Without Without Without With
For Use With Plug Housing Appropriate Universal MATE-N-LOK Plug Mates with Plug Housing (Using Socket Contacts) Mates with Plug Housing (Using Socket Contacts) Mates with Plug Housing (Using Pin Contacts) Appropriate Universal MATE-N-LOK Cap or Header Appropriate Universal MATE-N-LOK Plug
Width 1.04 13.97
Centerline (Pitch) 6.35 6.35 6.35 4.2 4.2 4.14 6.35 6.35 6.35 6.35
UL Rating Recognized Recognized Recognized Recognized Recognized Recognized Recognized
Circuit Application Power & Signal Power & Signal Power Power & Signal Power & Signal Power & Signal Power Power Power & Signal Power & Signal
Termination Method to Wire & Cable Crimp Crimp Crimp Crimp Crimp Crimp Crimp
Selectively Loaded No
Panel Thickness .76 – 2.29 .76 – 2.29 .03 – .09 .76 – 2.29
UL Flammability Rating UL 94V-2 UL 94V-2 UL 94V-0 UL 94V-2 UL 94V-2 UL 94V-0 UL 94V-0 UL 94V-2 UL 94V-2 UL 94V-2
Panel Mount Feature Type Patch & Tabs Patch & Tabs Patch & Tabs
Packaging Method Package Package Bag/Box Bag Bag Bag Bag Bag Package Package
Operating Temperature Range -67 – 221 -67 – 221 -67 – 221 -20 – 105 -20 – 105 -20 – 105 -40 – 221 -40 – 221 -67 – 221 -67 – 221
VDE Tested Yes Yes Yes Yes Yes Yes Yes
Sealable No No No No No No No No No No
Number of Signal Positions 0 0 0 0 0
Number of Power Positions 0 3 3 3 3 6 3
PCB Mount Retention Without Without Without
Contact Mating Area Plating Thickness .76 – .91 150 – 200 150 – 200
Contact Termination Area Plating Material Gold Tin Pre-Tin
Contact Current Rating (Max) 12 12 12
PCB Thickness (Recommended) 1.57 1.57 1.57
Termination Post & Tail Length 3.56 3.56 3.18
PCB Mount Orientation Vertical Vertical Vertical
Termination Post &Tail Length .14 .14 .125
Termination Method to Printed Circuit Board Through Hole - Solder Through Hole - Solder Through Hole - Solder
Contact Mating Area Plating Material Gold Tin Pre-Tin
Strain Relief Without Without
Mating Retention Type Positive Lock Positive Lock
PCB Mount Alignment Type Standard Polarized Tail
PCB Mount Alignment With Without
Mating Retention With With
Mating Alignment With With
Mating Alignment Type Polarization Polarization
Underplate Material Thickness 50
Contact Termination Area Plating Thickness 100
