| Price | |||||||||||
| RoHS | Compliant | Y | Y | Not Compliant | Not Compliant | Compliant | Compliant | Compliant | Compliant | Compliant | |
| Lead Status | No | See ti.com | Y | No | No | No | No | No | No | No | |
| Frequency(Max)(kHz) | 1000 | 1000 | |||||||||
| Rating | Catalog | Catalog | |||||||||
| Approx. price(US$) | 0.80 | 1ku | 0.85 | 1ku | |||||||||
| Gate drive(Typ)(A) | 0.6 | 0.6 | |||||||||
| Topology | Half-Bridge,Resonant LLC | Half-Bridge,Resonant LLC | |||||||||
| Package Group | SOIC|14 | SOIC|14 | |||||||||
| Features | Integrated Gate Drivers,Light Load Efficiency,Supports external bias,Thermal Shutdown | HV Start-up,Integrated Gate Drivers,Light Load Efficiency,Thermal Shutdown,Wide AC input,Wide DC input,X cap discharge integrated | |||||||||
| Control method | Current | Current | |||||||||
| Frequency(Min)(kHz) | 35 | 35 | |||||||||
| Duty cycle(Max)(%) | 50 | 50 | |||||||||
| Operating temperature range(C) | -40 to 125 | -40 to 125 | |||||||||
| Package size | mm2 | mm2 | |||||||||
| VCC(Min)(V) | 11.25 | 13 | |||||||||
| VCC(Max)(V) | 30 | 30 |
