2 A, Low VIN, Low Noise, CMOS Linear Regulator Features: 2 A maximum output current Low input voltage supply range VIN = 1.10 V to 1.98 V, no external bias supply required Fixed output voltage range: VOUT_FIXED = 0.9 V to 1.5 V Adjustable output voltage range: VOUT_ADJ = 0.5 V to 1.5 V Ultralow noise: 2 μV rms, 100 Hz to 100 kHz Noise spectral density 4 nV/√Hz at 10 kHz 3 nV/√Hz at 100 kHz Low dropout voltage: 62 mV typical at 2 A load Operating supply current: 4.5 mA typical at no load ±1.5% fixed output voltage accuracy over line, load, and temperature Excellent power supply rejection ratio (PSRR) performance 62 dB typical at 10 kHz at 2 A load 46 dB typical at 100 kHz at 2 A load Excellent load/line transient response Soft start to reduce inrush current Optimized for small 10 μF ceramic capacitors Current-limit and thermal overload protection Power-good indicator Precision enable 16-lead, 3 mm × 3 mm LFCSP package AEC-Q100 qualified for automotive applications

Very Low Quiescent Current, 150 mA, with Output Discharge LDO Regulator Features: Very low quiescent current IQ = 590 nA with 0 µA load IQ = 890 nA with 1 µA load Maintains very low quiescent current in dropout (pass through mode): IQ_DROP = 720 nA with 0 µA load IQ_DROP = 1200 nA with 1 µA load Stable with 1 µF ± 30% ceramic input and output capacitors Maximum load current: ILOAD_MAX: 150 mA Input voltage range: 2.2 V to 5.5 V Low shutdown current: 50 nA typical Low dropout voltage: 120 mV at 150 mA load Initial output voltage accuracy: ±1% Accuracy over line, load, and temperature: ±3.5% 7 fixed output voltage options: 1.2 V to 3.3 V Adjustable output option can be set from 1.2 V to 4.2 V See data sheet for additional features

Very Low Quiescent Current, 150 mA, with Output Discharge LDO Regulator Features: Very low quiescent current IQ = 590 nA with 0 µA load IQ = 890 nA with 1 µA load Maintains very low quiescent current in dropout (pass through mode): IQ_DROP = 720 nA with 0 µA load IQ_DROP = 1200 nA with 1 µA load Stable with 1 µF ± 30% ceramic input and output capacitors Maximum load current: ILOAD_MAX: 150 mA Input voltage range: 2.2 V to 5.5 V Low shutdown current: 50 nA typical Low dropout voltage: 120 mV at 150 mA load Initial output voltage accuracy: ±1% Accuracy over line, load, and temperature: ±3.5% 7 fixed output voltage options: 1.2 V to 3.3 V Adjustable output option can be set from 1.2 V to 4.2 V See data sheet for additional features

RESET CIRCUIT MPU #1 SC-70-3; Threshold Voltage:2.31V; No. of Supervisors / Monitors:1Monitors; Supply Voltage Min:1.2V; Supply Voltage Max:5.5V; Reset Type:Open-Drain; Digital IC Case:SC-70; No. of Pins:3Pins; Delay Time:150ms; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Cut Tape; Product Range:ADM1818 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

SUPERVISOR CIRCUIT MPU #1 SOT-23-5; Threshold Voltage:2.5V; No. of Supervisors / Monitors:1Monitors; Supply Voltage Min:1V; Supply Voltage Max:5.5V; Reset Type:Manual Active-High / Active-Low; Digital IC Case:SOT-23; No. of Pins:5Pins; Delay Time:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:ADM6319 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

Ultra Low Noise High PSR

Ultra Low Noise High PSRR #Negative LDO

Very Low Quiescent Current, 150 mA, LDO Regulator Features: Very low quiescent current IQ = 590 nA with 0 µA load IQ = 890 nA with 1 µA load Maintains very low quiescent current in dropout (pass through mode): IQ_DROP = 720 nA with 0 µA load IQ_DROP = 1200 nA with 1 µA load Stable with 1 µF ± 30% ceramic input and output capacitors Maximum load current: ILOAD_MAX: 150 mA Input voltage range: 2.2 V to 5.5 V Low shutdown current: 50 nA typical Low dropout voltage: 120 mV at 150 mA load Initial output voltage accuracy: ±1% Accuracy over line, load, and temperature: ±3.5% 7 fixed output voltage options: 1.2 V to 3.3 V Adjustable output option can be set from 1.2 V to 4.2 V See data sheet for additional features

800 mA, Ultra Low Noise/High PSRR LDO Features: Input voltage range: 4.5 V to 16 V Maximum output current: 800 mA Low Noise: 1.0 μVRMS Total Integrated Noise from 100 Hz to 100 KHz 1.6 μVRMS Total Integrated Noise from 10 Hz to 100 KHz Noise Spectral Density <1.7nV√Hz above 10 KHz PSRR of >90 dB from 1 KHz to 100 KHz, >60dB @ 1 MHz, VOUT = 5V Dropout voltage: 600 mV @ VOUT = 5 V/800 mA load Initial accuracy: ±1% Accuracy over line, load, and temperature: ±2% Quiescent Current, IGND = 4.3 mA @ No Load Low shutdown current: 0.1 μA Stable with a 10 μF ceramic output capacitor Fixed output voltage options: 1.8 V, 2.8 V, 3.0 V, 3.3 V and 5.0 V (16 outputs between 1.5 V and 5.0 V are available) 8-lead LFCSP package and SOIC package

4-PIN MICRO PROCESSOR VOLTAGE MONITOR;
