| Price | $1.07 | $1.36 | $1.89 | $11.21 | $1.36 | ||||||
| RoHS | Compliant | Yes | Yes | Y | Compliant | Compliant | Compliant | ||||
| Lead Status | Yes | Yes | Yes | Y | Yes | Yes | Yes | ||||
| Switching Frequency(Typ)(kHz) | 5500 | 5500 | 5500 | 5500 | 2000 | ||||||
| Operating Temperature Range(C) | -40 to 85 | -40 to 85 | -40 to 85 | -40 to 100 | -40 to 85 | -40 to 85 | |||||
| Switching Frequency(Min)(kHz) | 4900 | 4900 | |||||||||
| Vout(Min)(V) | 1.2 | 1.05 | 1.8 | 11.4 | 1.5 | 1.8 | |||||
| Vout(Max)(V) | 1.2 | 1.05 | 1.8 | 12.6 | 1.5 | 2.5 | |||||
| Vin(Min)(V) | 2.3 | 2.5 | 2.3 | 4.5 | 2.5 | 2.2 | |||||
| Regulated Outputs(#) | 1 | 1 | 1 | 2 | 1 | 1 | |||||
| Special Features | Enable,Light Load Efficiency,Output Discharge,Spread Spectrum | Enable,Output Discharge,Spread Spectrum | Enable,Light Load Efficiency,Output Discharge,Spread Spectrum | Dual Output,Unregulated,1W | Enable,Output Discharge,Spread Spectrum | Enable,Light Load Efficiency,Output Discharge | |||||
| Package Type | MicroSiP (BGA) | MicroSiP (BGA) | MicroSiP (BGA) | Leaded | MicroSiP (BGA) | MicroSiP (BGA) | |||||
| Soft Start | Fixed | Fixed | Fixed | Fixed | Fixed | ||||||
| Vin(Max)(V) | 4.8 | 5.5 | 4.8 | 5.5 | 5.5 | 5.5 | |||||
| Iq(Typ)(mA) | 0.017 | 7 | 0.017 | 7 | 0.00036 | ||||||
| Switching Frequency(Max)(kHz) | 6000 | 6000 | |||||||||
| Iout(Max)(A) | 0.6 | 1.6 | 0.6 | 0.041 | 1.6 | 0.2 | |||||
| Approx. Price (US$) | 0.95 | 1ku | 1.21 | 1ku | 0.95 | 1ku | 6.14 | 1ku | 1.21 | 1ku | 1.32 | 1ku | |||||
| Package Size | mm2 | ||||||||||
| Vout2(Min)(V) | -11.4 | ||||||||||
| Vout2(Max)(V) | -12.6 | ||||||||||
| Preset Vout(V) | 12 | ||||||||||
| Iout2(A) | 0.04 |
