| Price | $1.03 | $0.88 | |||||||||
| RoHS | Not Compliant | Compliant | Compliant | Compliant | Yes | Yes | Yes | Yes | Compliant | Not Compliant | |
| Lead Status | No | No | No | No | Yes | Yes | Yes | Yes | No | No | |
| Package Size | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | mm2 | |||
| Approx. Price (US$) | 0.43 | 1ku | 0.43 | 1ku | 0.43 | 1ku | 0.47 | 1ku | 0.43 | 1ku | 0.43 | 1ku | 0.43 | 1ku | 0.87 | 1ku | |||
| Supply Voltage(Max)(V) | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 3.6 | |||
| Supply Current(Typ)(uA) | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 570 | |||
| Rating | Catalog | Catalog | Catalog | Automotive | Catalog | Catalog | Catalog | Catalog | |||
| Interface | Analog Output,Switch | Analog Output,Switch | Analog Output,Switch | Analog Output,Switch | Analog Output,Switch | Analog Output,Switch | Analog Output,Switch | I2C,SMBus | |||
| Accuracy Over Temp Range(Max)(C) | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 | ||||
| Output Type | Open Drain,Push Pull | Open Drain,Push Pull | Open Drain,Push Pull | Open Drain,Push Pull | Open Drain,Push Pull | Open Drain,Push Pull | Open Drain,Push Pull | ||||
| Package Group | WSON | WSON | WSON | WSON | WSON | WSON | WSON | WSON | |||
| SetPoint Type | Factory Programmed | Factory Programmed | Factory Programmed | Factory Programmed | Factory Programmed | Factory Programmed | Factory Programmed | ||||
| Special Features | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | Built-in Hysteresis,Hysteresis (5C),Temperature Sensor and Switch,Trip Test | One shot conversion control,Programmable Alert,Programmable conversion rate,Remote diode fault detection,Shutdown,Thermal diode input stage filtering | |||
| SetPoint Value(deg C) | Range (0 to 150),50, 60, 65, 70,75, 80, 85, 90,95, 100, 105, 110,115, 120, 125, 130,135, 140, 145, 150 | Range (0 to 150),50, 60, 65, 70,75, 80, 85, 90,95, 100, 105, 110,115, 120, 125, 130,135, 140, 145, 150 | Range (0 to 150),50, 60, 65, 70,75, 80, 85, 90,95, 100, 105, 110,115, 120, 125, 130,135, 140, 145, 150 | Range (0 to 150),130, 135 | Range (0 to 150),50, 60, 65, 70,75, 80, 85, 90,95, 100, 105, 110,115, 120, 125, 130,135, 140, 145, 150 | Range (0 to 150),50, 60, 65, 70,75, 80, 85, 90,95, 100, 105, 110,115, 120, 125, 130,135, 140, 145, 150 | Range (0 to 150),50, 60, 65, 70,75, 80, 85, 90,95, 100, 105, 110,115, 120, 125, 130,135, 140, 145, 150 | ||||
| Supply Voltage(Min)(V) | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 3 | |||
| Operating Temperature Range(C) | 0 to 150 | 0 to 150 | 0 to 150 | -40 to 150 | 0 to 150 | 0 to 150 | 0 to 150 | -40 to 140 | |||
| Sensor Gain(mV/Deg C) | -5.1 to -12.8 | -5.1 to -12.8 | -5.1 to -12.8 | -5.1 to -12.8 | -5.1 to -12.8 | -5.1 to -12.8 | -5.1 to -12.8 | ||||
| # Comparators | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||||
| Remote Temp Resolution(Max)(bits) | 13 | ||||||||||
| Temp Resolution(Max)(bits) | 11 | ||||||||||
| Local Sensor Accuracy(Max)(+/- C) | 2 | ||||||||||
| Remote Channel | 2 | ||||||||||
| Remote Sensor Accuracy(Max)(+/- C) | 1.1 | ||||||||||
| Remote Diode Temp Range for Listed Accuracy(C) | 60 to 100 | ||||||||||
| Remote Sensor Correction | Offset Correction Register |
