TE Connectivity 1586037-6

TE Connectivity 350809-1

1586314-1

TE Connectivity 1586314-1

TE Connectivity 350778-1

TE Connectivity 1-1586037-0

TE Connectivity 1586000-8

TE Connectivity 1586000-2

1-640550-0

TE Connectivity 1-640550-0

5767007-8

TE Connectivity 5767007-8

LMR1802G-LBTR

ROHM Semiconductor LMR1802G-LBTR

Price
RoHS Compliant
Lead Status No
Contact Mating Area Plating Thickness 2.03 – 5.08 80
PCB Thickness (Recommended) 1.6 1.6
Housing Material Nylon Nylon Nylon Nylon Nylon Nylon
PCB Mount Retention Without Without
Connector System Wire-to-Board Wire-to-Wire Wire-to-Wire Wire-to-Wire Wire-to-Board Wire-to-Wire Wire-to-Wire
Header Type Shrouded Shrouded
Row-to-Row Spacing 4.2 4.2 4.2 4.2
CSA File Number 208567 LR16455 208567 LR7189 208567 208567 208567
Agency/Standard Number E28476 E28476 E28476 E28476 E28476 E28476
Connector Mounting Type Board Mount Cable Mount Cable Mount Panel Board Mount Cable Mount Cable Mount
Packaging Method Box & Tray Package Bag Package Box & Tray Bag Bag
Connector & Contact Terminates To Printed Circuit Board Wire & Cable Wire & Cable Wire & Cable Printed Circuit Board Wire & Cable Wire & Cable
Number of Positions 6 5 2 10 8 2
Number of Rows 2 1 1 2 2 2
Contact Retention Without Without Without Without Without Without
Height 12.8 12.8 9.6 9.6
Accepts Wire Insulation Diameter Range .047 – .122 .06 – .094 .047 – .122 .047 – .122 .047 – .122
Operating Voltage 600 600 600 600 600 600 600
Centerline (Pitch) 4.2 6.35 6.35 4.2 4.2 4.2
Agency/Standard CSA CSA UL CSA CSA CSA CSA
Glow Wire Rating Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire Standard Part - Not Glow Wire
PCB Mount Alignment Without Without
Contact Type Pin Plug Pin Pin Pin Pin Pin
Contact Layout Inline Inline Inline Inline Matrix Inline
Length .543 22.2 .7087 .213
Mating Retention Type Latch Latch
Termination Post &Tail Length .138 .138
PCB Mount Orientation Vertical Vertical
Circuit Identification Feature With With With With
Circuit Application Power Power & Signal Power Power & Signal Power Power & Signal Power & Signal
Width 9.75 9.75 .937 .937
Insulation Diameter (Max) 2.39 2.39
UL Rating Recognized Recognized Recognized Recognized Recognized Recognized Recognized
Mating Alignment Type Keyed Keyed
Housing Type Plug Plug Receptacle Plug Plug Plug
Termination Method to Printed Circuit Board Through Hole - Solder Through Hole - Solder
Number of Power Positions 6 0 0 10
Selectively Loaded No No No No
Contact Current Rating (Max) 9 9 9
Contact Termination Area Plating Material Tin Pre-Tin Tin
UL Flammability Rating UL 94V-2 UL 94V-0 UL 94V-0 UL 94V-2 UL 94V-2 UL 94V-2
Mating Retention With With
Mating Alignment With With
Termination Post & Tail Length 3.5 3.5
Operating Temperature Range -40 – 221 -67 – 221 -40 – 221 -67 – 221 -40 – 221 -40 – 221 -40 – 221
Contact Mating Area Plating Material Tin Pre-Tin Tin
Housing Color Natural Natural Natural Natural Natural Natural
VDE Tested No Yes Yes No No No
Packaging Quantity 420 1 500 1 255 500 500
Sealable No No No No No No
Product Type Header Housing Contact Housing Header Housing Housing
CSA Rating Certified Certified
Assembly Integration Feature Without Without Without Without
Multiple Contact Types Without Without
For Use With Appropriate Universal MATE-N-LOK Cap or Header Universal MATE-N-LOK Plug
Termination Method to Wire & Cable Crimp Crimp Crimp Crimp
Contact Angle Straight
Termination Type Crimp
Wire/Cable Type Discrete Wire Discrete Wire Discrete Wire
Wire Insulation Support Without
Contact Design Formed Pin
Wire Contact Termination Area Plating Material Pre-Tin
Contact Retention in Housing With
Wire/Cable Size 24 – 18
For Multiple Crimp No
Contact Base Material Brass
UL File Number E28476
Number of Signal Positions 0
Panel Mount Feature With
Panel Thickness .76 – 2.29
Panel Mount Feature Type Patch & Tabs
Insertion Force 15 15
