MAX232D

Texas Instruments MAX232D

MAX3221IDBG4

Texas Instruments MAX3221IDBG4

MSP430F1232IPWR

Texas Instruments MSP430F1232IPWR

LM4132EMF-2.5/NOPB

Texas Instruments LM4132EMF-2.5/NOPB

TPS5430DDA

Texas Instruments TPS5430DDA

TPS5450DDA

Texas Instruments TPS5450DDA

TL431AILPR

Texas Instruments TL431AILPR

TL431BCDR

Texas Instruments TL431BCDR

MMBT4401LT1

onsemi MMBT4401LT1

MMBT5401LT3

onsemi MMBT5401LT3

Price $0.79 $3.58
RoHS Yes Compliant Compliant Compliant Compliant Compliant Yes Compliant Yes Not Compliant
Lead Status Yes Yes No No No No Yes No Yes No
ICC(Max)(mA) 10 1
Receivers Per Package 2 1
Rating Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog
Data Rate(Max)(kbps) 120 250
Operating Temperature Range(C) -40 to 85,0 to 70 -40 to 85,0 to 70 -40 to 85 -40 to 125 -40 to 125 -40 to 125 -40 to 125,-40 to 85,0 to 70 -40 to 125,-40 to 85,0 to 70
Package Group PDIP,SO,SOIC SSOP,TSSOP SOIC,TSSOP,VQFN SOT-23 SO PowerPAD SO PowerPAD PDIP,SC70,SO,SOIC,SOT-23,SOT-89,TO-92,TSSOP SC70,SOT-23,SOT-89,SO,TSSOP,SOIC,TO-92,PDIP
Drivers Per Package 2 1
ESD HBM(kV) 2 15
Package Size mm2 mm2 mm2 mm2 mm2 mm2
Main Supply Voltage(Nom)(V) 5 3.3,5
Approx. Price (US$) 0.35 | 1ku 0.65 | 1ku 1.87 | 1ku 0.78 | 1ku 1.85 | 1ku 2.00 | 1ku 0.07 | 1ku 0.11 | 1ku
Logic Voltage(Min)(V) 5 3.3
Power Saving Feature Auto-Powerdown
Special I/O N/A
Additional Features Watchdog,Temp Sensor,Brown Out Reset
Frequency(MHz) 8
Min VCC 1.8
ADC ADC10 - 8ch
Non-volatile Memory (KB) 8
AES N/A
BSL UART
DMA 0
Active Power (uA/MHz) 200
RAM(KB) 0.25
Multiplier N/A
Standby Power (LPM3-uA) 0.7
Timers - 16-bit 1
GPIO Pins(#) 22
I2C 0
Comparators(Inputs) 0
Timers - 32-bit 0
UART 1
CPU MSP430
Max VCC 3.6
SPI 1
Wakeup Time (us) 6
VO(V) 1.8,2.048,2.5,3,3.3,4.096 2.495 2.495
Shutdown Current(Typ)(uA) 3
Special Features Enable pin Enable Enable
Iout/Iz(Max)(mA) 20 100 100
Initial Accuracy(Max)(%) 0.05,0.1,0.2,0.4 1 0.5
Temp Coeff(Max)(ppm/ degree C) 10,20,30 92 92
Vin(Max)(V) 5.5 36 36
Iq(Max)(uA) 100
Vin(Min)(V) 2.2 5.5 5.5
LFN 0.1-10Hz(Typ)(Vpp) 170,190,240,285,310,350
Iq(Typ)(uA) 60
Pin/Package 5SOT-23 3SOT-23, 3SOT-89, 3TO-92, 5SOT-23, 6SC70, 8PDIP, 8SO, 8SOIC, 8TSSOP 3SOT-23, 3SOT-89, 3TO-92, 5SOT-23, 6SC70, 8PDIP, 8SO, 8SOIC, 8TSSOP
Vout(Max)(V) 31 31
Switching Frequency(Max)(kHz) 500 500
Duty Cycle(Max)(%) 87 89
Vout(Min)(V) 1.23 1.22
Type Converter Converter
Regulated Outputs(#) 1 1
Control Mode Voltage Mode Voltage Mode
Switching Frequency(Min)(kHz) 500 500
Iq(Typ)(mA) 3 3
Iout(Max)(A) 3 5
VO Adj(Min)(V) 2.495 2.495
VO Adj(Max)(V) 36 36
Temp Coeff(Typ)(ppm/ degree C) 34 34
Min Iz for Regulation(uA) 400 400
Reference Voltage Adjustable Adjustable
