SN74LS629N

Texas Instruments SN74LS629N

SN74LS640N

Texas Instruments SN74LS640N

SN74LS642N

Texas Instruments SN74LS642N

SN74LS652DW

Texas Instruments SN74LS652DW

SN74LS682DW

Texas Instruments SN74LS682DW

SN74LS684N

Texas Instruments SN74LS684N

SN74LS688DW

Texas Instruments SN74LS688DW

SN74LS75N

Texas Instruments SN74LS75N

SN74HCT04N

Texas Instruments SN74HCT04N

SN74HCT125N

Texas Instruments SN74HCT125N

Price $3.81 $1.19 $0.23
RoHS Yes Compliant Yes Yes Yes Yes Yes Yes Compliant Yes
Lead Status Yes No Yes Yes Yes Yes Yes Yes No Yes
Operating Temperature Range(C) 0 to 70 0 to 70 0 to 70 0 to 70 0 to 70 0 to 70 0 to 70 0 to 70 -40 to 85 -40 to 85
Approx. Price (US$) 2.47 | 1ku 0.71 | 1ku 3.47 | 1ku 4.29 | 1ku 0.88 | 1ku 2.71 | 1ku 0.94 | 1ku 0.77 | 1ku 0.07 | 1ku 0.09 | 1ku
Output Type TTL TTL TTL TTL TTL TTL TTL TTL CMOS CMOS
Technology Family LS LS LS LS LS LS LS LS HCT HCT
Rating Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog
Schmitt Trigger No No No No No No No No No No
VCC(Max)(V) 5.25 5.25 5.25 5.25 5.25 5.25 5.25 5.25 5.5 5.5
F @ Nom Voltage(Max)(Mhz) 35 35 35 35 35 35 35 35 25 25
Voltage(Nom)(V) 5 5 5 5 5 5 5 5 5 5
Package Group PDIP,SO,SOIC SO,SOIC,PDIP,SSOP PDIP,SO,SOIC SOIC PDIP,SO,SOIC PDIP,SO,SOIC PDIP,SO,SOIC PDIP,SO,SOIC PDIP,SO,SOIC,TSSOP PDIP,SOIC
Output Drive (IOL/IOH)(Max)(mA) 24/-1.2 -15/24 - /24 -15/24 24/-0.4 24/-0.4 24/-0.4 8/-0.4 -4/4 -6/6
Input Type TTL TTL TTL TTL TTL TTL TTL TTL TTL TTL
Package Size mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2
ICC @ Nom Voltage(Max)(mA) 55 0.09 0.09 0.165 70 65 68 12 0.02 0.08
tpd @ Nom Voltage(Max)(ns) 15 15 25 20 30 30 23 40 23 30
VCC(Min)(V) 4.75 4.75 4.75 4.75 4.85 4.85 4.85 4.75 4.5 4.5
Bits(#) 2 8 8 8 8 8 8 4 6 4
3-State Output No
