ADS7813UB

Texas Instruments ADS7813UB

ADS7817EC/250

Texas Instruments ADS7817EC/250

ADS7830IPWT

Texas Instruments ADS7830IPWT

ADS7869IPZTR

Texas Instruments ADS7869IPZTR

ADS7890IPFBT

Texas Instruments ADS7890IPFBT

ADS7953SRHBR

Texas Instruments ADS7953SRHBR

ADS8317IBDRBR

Texas Instruments ADS8317IBDRBR

ADS8329IBRSAR

Texas Instruments ADS8329IBRSAR

ADS8342IPFBT

Texas Instruments ADS8342IPFBT

ADS8354IPWR

Texas Instruments ADS8354IPWR

Price $4.86 $17.08
RoHS Compliant Yes Yes Compliant Compliant Not Compliant Yes Compliant Yes Compliant
Lead Status No Yes Yes No No No Yes No Yes No
Analog Voltage AVDD(Max)(V) 5.25 5.25 5.25 5.5 5.25 5.25 5.5 5.5 5.25 5.5
Operating Temperature Range(C) -40 to 85 -40 to 85 -40 to 85 -40 to 85 -40 to 85 -40 to 125 -40 to 85 -40 to 85 -40 to 85 -40 to 125
SNR(dB) 89 50 71 78 71.7 90 92 84.6 93
# Input Channels 1 1 8 12 1 16 1 1 4 2
Rating Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog Catalog
Approx. Price (US$) 22.37 | 1ku 2.05 | 1ku 1.58 | 1ku 15.62 | 1ku 11.50 | 1ku 4.05 | 1ku 5.00 | 1ku 7.20 | 1ku 16.84 | 1ku 9.50 | 1ku
Resolution(Bits) 16 12 8 12 14 12 16 16 16 16
Digital Supply(Min)(V) 4.75 4.75 2.7 2.7 2.7 1.7 2.7 1.65 2.7 1.65
SINAD(dB) 89 71 49 70 77 71.3 89.9 93 86 92.2
Sample Rate (max)(SPS) 40kSPS 200kSPS 70kSPS 1MSPS 1.25MSPS 1MSPS 250kSPS 1MSPS 250kSPS 700kSPS
Digital Supply(Max)(V) 5.25 5.25 5.25 5.5 5.25 5.25 5.5 5.5 5.5 5.5
Input Range(Min)(V) -10 0 0 0 0 0 0 0 -2.5 0
Package Group SOIC SOIC,VSSOP TSSOP TQFP TQFP TSSOP,VQFN SON,VSSOP QFN,TSSOP TQFP TSSOP,WQFN
Package Size mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2 mm2
INL(Max)(+/-LSB) 2 2 0.5 2.5 1.5 1 1.5 1.75 4 2.5
THD(Typ)(dB) -98 -83 -72 -78 -95 -82 -106 -102 -89 -100
Input Type Single-Ended Differential,Pseudo-Differential,Single-Ended Pseudo-Differential,Single-Ended Differential Pseudo-Differential,Single-Ended Single-Ended Differential Differential,Single-Ended Pseudo-Differential,Single-Ended Differential
Power Consumption(Typ)(mW) 35 2.3 0.75 250 45 11.5 10 15 3.6 45
Reference Mode Ext,Int Ext Ext,Int Ext,Int Ext,Int Ext Ext Ext Ext Ext,Int
Analog Voltage AVDD(Min)(V) 4.75 4.75 2.7 4.5 4.75 2.7 2.7 2.7 4.75 4.5
Input Range(Max)(V) 10 5.25 5.25 5.5 2.5 5.25 5.5 5.5 2.5 5.5
Integrated Features Oscillator N/A N/A N/A Oscillator N/A N/A Daisy-Chainable,Oscillator N/A N/A
Multi-Channel Configuration N/A N/A Multiplexed Simultaneous Sampling N/A Multiplexed N/A N/A Multiplexed Simultaneous Sampling
Architecture SAR SAR SAR SAR SAR SAR SAR SAR SAR SAR
Interface Serial SPI Serial I2C Parallel,SPI SPI SPI Serial SPI Parallel
